Neptune OS: a Windows NT personality for the seL4 microkernel

Neptune OS is a Windows NT personality for the seL4 microkernel. It implements what Microsoft calls the "NT Executive", the upper layer of the Windows kernel NTOSKRNL.EXE, as a user process under the seL4 microkernel. The NT Executive implements the so-called NT Native API, the native system call interface of Windows upon which the more familiar Win32 API is built. These are exposed to the user mode via stub functions in NTDLL.DLL with names such as NtCreateProcess. The NT Executive is also responsible for exposing a programming interface to device drivers. Said interface includes functions like IoConnectInterrupt and IoCallDriver. Our architecture enables device drivers to run in separate userspace processes and communicate with the NT Executive process via standard seL4 IPC primitives.

The eventual goal of the Neptune OS project is to implement enough NT semantics such that a ReactOS user land can be ported under Neptune OS, as well as most ReactOS kernel drivers. In theory we should be able to achieve binary compatibility with native Windows executables provided that our implementation of the NT Native API is sufficiently faithful. We should also be able to achieve a high degree of source code portability with Windows device drivers and file system drivers, although we do not aim for complete, line-for-line source code compatibility due to the architectural differences with Windows/ReactOS that make this goal non-realistic. Please see the Documentation section for more information.

Project Status

The current status of the project is that we have implemented enough NT Executive components to support a reasonably complete storage driver and file system driver stack with read-ahead and write-back caching support. This includes the storage class driver pair (classpnp.sys and disk.sys), the storport.sys port driver, two storage miniport drivers for AHCI (storahci.sys, from Microsoft) and NVME (stornvme.sys, from Open Fabrics Alliance) drives, as well as the partition manager (partmgr.sys) and mount manager (mountmgr.sys). We also have a floppy controller driver fdc.sys for the standard floppy controller on the PC. So far only one file system driver, the FAT12/16/32 file system driver fatfs.sys, has been ported, but more is planned in the future (in particular, ext2fsd so we can support ext2/3/4). Together with a basic keyboard driver stack (keyboard class driver kbdclass.sys and the PS/2 port driver i8042prt.sys), these allow us to run a basic command prompt ntcmd.exe, taken from the ReactOS project, that supports most of the common shell commands, such as pwd, cd, copy, move, del, mount, and umount. We also include a beep.sys driver which makes an annoying sound on the PC speaker.

The entire system fits in a floppy and can be downloaded from Release v0.3.0003. You can watch a short demo on YouTube. You can also build it yourself. See the section on Building.

Planned Features

Due to the lack of high quality open-source Windows device drivers, the main goal of the next release is to design a subsystem which allows reusing of the Linux kernel device drivers. The basic idea is building the Linux kernel as a library using the work done in the LKL project, and writing a shim that facilitates communication between the NT Executive process and the Linux device driver library using the standard IRP driver interface. For more details, see issue #19.

Minimal System Requirements

For i386 systems:

1. CPU: At least a Pentium 2 or equivalent: the default clang target is i686 which can generate instructions not implemented by 386, 486, and Pentium. Also, on x86 the seL4 kernel assumes that the processor supports global pages (bit PGE in CR4). This is only supported in Pentium Pro (i686) and later. There is no way to disable this at compile time (see assembly routine enable_paging in sel4/src/arch/x86/32/head.S).
2. RAM: 32MB should be safe, can probably go lower.
3. BIOS or UEFI-based firmware, with a conformant ACPI implementation. This is more of a seL4 requirement as it needs at least ACPI 3.0 for detecting the number of CPU cores. Note that most early 32-bit era PCs don't necessarily have a conformant ACPI (let alone ACPI 3.0) implementation, so this pretty much restricts you to Core 2 Duo era machines. Thinkpad X60 is a 32-bit laptop that has been tested to work.
4. VGA-compatible graphics controller. If you are booting under UEFI, the GOP linear framebuffer is used to render the text console. Similarly, if you use coreboot as your boot firmware and have enabled its builtin graphics initialization routines, its linear framebuffer will also be used to render our text console. Otherwise, the VGA text console will be used.
5. PS2 keyboard. Many BIOSes offer PS2 emulation for USB keyboards so connecting a USB keyboard might also work.

For amd64 systems the CPU and RAM requirements are slightly different:

1. CPU: At least Intel Ivy Bridge or equivalent: the default seL4 kernel is built with the fsgsbase instruction enabled. This is only supported on Ivy Bridge and later. To run amd64 builds on earlier CPUs you can disable fsgsbase instruction in private/ntos/cmake/sel4.cmake. Also we require cmpxchg16b, which is available since Nehalem, and quite possibly earlier (earlier Core 2 processors might need a microcode update).
2. RAM: 128MB should be safe, can probably go lower.

For amd64 machines, Thinkpad X230, T420, X2100 (from 51NB), and the GPD Micropc (1st gen) have all been tested to work.

Building and running

You will need to build under Linux (macOS can potentially work, but I have not tested it). You will need the following Python dependencies, and probably more.

jinja2
future
ply
setuptools
six
lxml

You will also need cmake, clang, llvm and lld as a basic toolchain. clang is a native cross compiler that can generate both ELF and PE targets. GCC is not supported but in theory can be made to work. You will need both an ELF toolchain and a PE toolchain (and probably a ton of patience) if you want to make GCC work. You also need the windmc which is the PE message resource compiler from mingw. Have a look at build.sh for the build script. I use Arch Linux (btw) so the toolchain versions that have been tested to work are whichever versions Arch Linux happened to have at the time I ran pacman -Syu, but from experience most recent versions of clang/LLVM should all work. You also need the cpio utility for building the initcpio. Finally, for the boot floppy and boot iso you will need the following tools: syslinux (for boot floppy), grub and xorriso (for boot iso), and mtools (for both).

It is recommended to use a language server-enabled IDE to browse the source code. The tested setup is the lsp-mode package on emacs with clangd as the language server. The build.sh script will generate the compile_commands.json file for clangd. You will need to install jq for this purpose.

Clone the project first (make sure you use git clone --recurse-submodules since we include the seL4 kernel as a submodule) and then run

./build.sh [amd64] [release]

If you don't specify amd64, then it's an i686 build. If you don't specify release, then it's a debug build. To create boot floppies, type

./mkfloopy.sh [amd64] [release]

To create boot isos, type

./mkiso.sh [amd64] [release]

To emulate using QEMU, run

./run.sh [direct|iso|uefi] [amd64] [release] [extra-qemu-args]

If you specify direct, then QEMU will load the seL4 kernel and the NTOS image directly (using -kernel and -initrd). If you specify iso or uefi, it will load the boot iso built by mkiso.sh. The uefi option will also configure QEMU to load the UEFI firmware, which provides a nice high definition framebuffer console. Otherwise, the boot floppy created by mkfloppy.sh is used. Extra arguments are passed to QEMU. For instance, to run the i386 release build with PC speaker enabled in QEMU you can pass the following (this assumes you are using a recent QEMU version and have pulseaudio)

./run.sh release -machine pcspk-audiodev=snd0 -audiodev pa,id=snd0

To emulate an AHCI drive under QEMU, add the following extra QEMU arguments:

-drive file=disk.img,if=none,id=disk0 -device ich9-ahci,id=ahci0 -device ide-hd,drive=disk0,bus=ahci0.0

Replace disk.img with the path to your disk image. You may need to add -boot a so QEMU will boot from the floppy disk. To emulate an NVME drive under QEMU, add the following extra QEMU arguments:

-drive file=disk.img,format=raw,if=none,id=drv0 -device nvme,serial=deadbeef,drive=drv0,id=nvme0

Debugging

By default, the debug build is built with serial port logging enabled. The default IO port for the serial terminal that the seL4 kernel uses to output the debug logs is 0x3f8 and can be configured in the boot command line using console_port=0x### and debug_port=0x###. If your machine does not have a built-in serial port (a common case for laptops), you can use a PCI(E) serial card or a Cardbus (expresscard) serial card. The form factor does not matter, as long as the device shows up as a PCI device when the firmware enumerates the PCI bus. The PCI(E) serial card must support IO port decoding. A tested PCI(E) serial bridge chip is Asix Electronics AX99100. You can find products based on this chip in the form of PC
