INTRODUCTION

CDStore builds on an augmented secret sharing scheme called convergent dispersal, which supports deduplication by using deterministic content-derived hashes as inputs to secret sharing. It combines convergent dispersal with two-stage deduplication to achieve both bandwidth and storage savings and be robust against side-channel attacks.

REQUIREMENTS

CDStore is built on Ubuntu 12.04.3 LTS with gcc version 4.6.3.

This software requires the following libraries:

• OpenSSL (https://www.openssl.org/source/openssl-1.0.2a.tar.gz)
• GF-Complete (https://github.com/ceph/gf-complete/archive/master.zip)
• boost C++ library (http://sourceforge.net/projects/boost/files/boost/1.58.0/boost_1_58_0.tar.gz)
• LevelDB (https://github.com/google/leveldb/archive/master.zip)

The GF-Complete and LevelDB are packed in /client/lib/ and /server/lib/ respectively.

INSTALLATION

For linux user you can install the LevelDB dependency, OpenSSL and Boost by the following:

• sudo apt-get install libssl1.0.0 libboost-all-dev libsnappy-dev

CONFIGURATION

• Configure the server (CDStore requires at least 4 storage server)

  • Make sure there are three directories under /server/meta
  • "DedupDB" for levelDB logs
  • "RecipeFiles" for temp recipe files
  • "ShareContainers" for share local cache
  • Start a server by "./SERVER [port]"

• Configure the client

  • In the configure file /client/config, specify the storage nodes line by line with [IP]:[port]

  Example: you have run 4 servers with "./SERVER [port]" on machines: - 192.168.0.30 with port 11030 - 192.168.0.31 with port 11031 - 192.168.0.32 with port 11032 - 192.168.0.33 with port 11033

   you need to specify the ip and port in config with following format:

   	192.168.0.30:11030
   	192.168.0.31:11031
   	192.168.0.32:11032
   	192.168.0.33:11033

   (the actual order doesn't matter)


  • (Optional) In the configure class of client, /client/util/conf.hh

    • set chunk and secure parameters following the comments
    • set the number of storage nodes according to your running servers

MAKE

To make a client, on the client machine:

 * Go to /client/lib/, type "make" to make gf_complete
 * Back to /client/, type "make" to get the executable CLIENT program

To make a server, on each storage node:

 * Go to /server/lib/leveldb/, type "make" to make levelDB
 * Back to /server/, type "make" to get the executable SERVER program

EXAMPLE

• After successful make

  usage: ./CLIENT [filename] [userID] [action] [secutiyType]

  • [filename]: full path of the file;
  • [userID]: user ID of current client;
  • [action]: [-u] upload; [-d] download;
  • [securityType]: [HIGH] AES-256 & SHA-256; [LOW] AES-128 & SHA-1

• To upload a file "test", assuming from user "0" using AES-256 & SHA-256

  ./CLIENT test 0 -u HIGH

• To download a file "test", assuming from user "1" using AES-128 & SHA-1

  ./CLIENT test 1 -d LOW

MAINTAINER

• Current maintainer

  • Chuan QIN, the Chinese University of Hong Kong, chintran27@gmail.com

• Original maintainer

  • Mingqiang Li, Lenovo Hong Kong, mingqianglicn@gmail.com
