GCViewer 1.36

GCViewer is a little tool that visualizes verbose GC output generated by Sun / Oracle, IBM, HP and BEA Java Virtual Machines. It is free software released under GNU LGPL.

You can start GCViewer (gui) by simply double-clicking on gcviewer-1.3x.jar or running java -jar gcviewer-1.3x.jar (it needs a java 1.8 vm to run).

For a cmdline based report summary just type the following to generate a report (including optional chart image file): java -jar gcviewer-1.3x.jar gc.log summary.csv [chart.png] [-t PLAIN|CSV|CSV_TS|SIMPLE|SUMMARY] When logfile rotation (-XX:+UseGCLogFileRotation) is enabled, the logfiles can be read at once: java -jar gcviewer-1.3x.jar gc.log.0;gc.log.1;gc.log.2;gc.log.current summary.csv [chart.png] [-t PLAIN|CSV|CSV_TS|SIMPLE|SUMMARY]

Supported verbose:gc formats are:

• some support for OpenJDK 9 / 10 unified logging format -Xlog:gc:<file>, the following configurations will work
  • -Xlog:gc:file="path-to-file" (uses defaults)
  • -Xlog:gc=info:file="path-to-file":tags,uptime,level (minimum configuration needed)
  • -Xlog:gc*=trace:file="path-to-file":tags,time,uptime,level (maximum configuration supported, additional tags ok, but ignored; additional decorations will break parsing)
• Oracle JDK 1.8 -Xloggc:<file> [-XX:+PrintGCDetails] [-XX:+PrintGCDateStamps]
• Sun / Oracle JDK 1.7 with option -Xloggc:<file> [-XX:+PrintGCDetails] [-XX:+PrintGCDateStamps]
• Sun / Oracle JDK 1.6 with option -Xloggc:<file> [-XX:+PrintGCDetails] [-XX:+PrintGCDateStamps]
• Sun JDK 1.4/1.5 with the option -Xloggc:<file> [-XX:+PrintGCDetails]
• Sun JDK 1.2.2/1.3.1/1.4 with the option -verbose:gc
• IBM JDK 1.3.1/1.3.0/1.2.2 with the option -verbose:gc
• IBM iSeries Classic JVM 1.4.2 with option -verbose:gc
• HP-UX JDK 1.2/1.3/1.4.x with the option -Xverbosegc
• BEA JRockit 1.4.2/1.5/1.6 with the option -verbose:memory [-Xverbose:gcpause,gcreport] [-Xverbosetimestamp]

Best results for non unified gc logging Oracle JDKs are achieved with: -Xloggc:<file> -XX:+PrintGCDetails -XX:+PrintGCDateStamps. A few other options are supported, but most of the information generated is ignored by GCViewer (the javadoc introduction of https://github.com/chewiebug/GCViewer/blob/master/src/main/java/com/tagtraum/perf/gcviewer/imp/DataReaderSun1_6_0.java shows the details).

Hendrik Schreiber wrote GCViewer up to 1.29. What you are seeing here is based on his very good work. Links to detailed descriptions of many JVM parameters relevant to garbage collection can be found in the links section of https://github.com/chewiebug/GCViewer/wiki

Results of log analysis

There are two sections, where the results of the log analysis are shown. One is the left side with the chart, the other the data panel on the right side. In the following, the content of these sections is explained.

Chart

GCViewer shows a number of lines etc. in a chart (first tab). These are:

• Full GC Lines:
  • Black vertical line at every Full GC
• Inc GC Lines:
  • Cyan vertical line at every Incremental GC
• GC Times Line:
  • Green line that shows the length of all GCs
• GC Times Rectangles:
  • black rectangle at every Full GC
  • blue rectangle at every initial mark event
  • orange rectangle at every remark event
  • red rectangle at every vm operation event ("application stopped...")
  • Grey rectangle at every 'normal' GC
  • Light grey rectangle at every Incremental GC
• Total Heap:
  • Red line that shows heap size
• Tenured Generation:
  • Magenta area that shows the size of the tenured generation (not available without PrintGCDetails)
• Young Generation:
  • Orange area that shows the size of the young generation (not available without PrintGCDetails)
• Used Heap:
  • Blue line that shows used heap size
• Initial mark level:
  • Yellow line that shows the heap usage at "initial-mark" event (only available when the gc algorithm uses concurrent collections, which is the case for CMS and G1)
• Concurrent collections
  • Cyan vertical line for every begin (concurrent-mark-start) and pink vertical line for every end (CMS-concurrent-reset / G1: concurrent-cleanup-end) of a concurrent collection cycle

Event details

In the second tab it shows details about the events it parsed: E.g. events like the following

24.187: [GC 24.188: [ParNew: 93184K->5464K(104832K), 0.0442895 secs]
93184K->5464K(1036928K), 0.0447149 secs]
[Times: user=0.39 sys=0.07, real=0.05 secs]

are shown in one line as GC ParNew: <number of events parsed>, <min duration>, <max duration>...

Events like these

4183.962: [Full GC 4183.962: [CMS: 32957K->40326K(932096K), 2.3313389 secs]
76067K->40326K(1036928K), [CMS Perm : 43837K->43453K(43880K)], 2.3339606 secs]
[Times: user=2.33 sys=0.01, real=2.33 secs]

are shown as Full GC; CMS; CMS Perm <number of events parsed> ...

So for every line the text is extracted (not always every part of it). This allows a user which is familiar with the text log files to find out more details about the events that occurred.

median, 75th...

These columns show the median, 75th percentile etc.

Gc pauses

This are shows all stop-the-world pauses, that are not full gc pauses.

Full gc pauses

In this area all pauses are shown, which GCViewer considers as "full gc" pauses. The current definition of a "full gc" is: Either the gc algorithm prints "full gc" in its event name, or more than one generation (young, old, permgen / metaspace) were involved during collection.

VM operations overhead (safepoint pauses)

This area is only shown, if the gc log was written with the option -XX:+PrintGCApplicationStoppedTime. To understand the meaning of this metric, it is important to know about safepoints (see e.g. http://blog.ragozin.info/2012/10/safepoints-in-hotspot-jvm.html).

If GCViewer finds gc log lines like the following: 2017-03-29T14:37:12.812+0200: 8.832: [GC (Allocation Failure)
[PSYoungGen: 29146K->3457K(29184K)] 78228K->52539K(116736K), 0.0009340 secs]
[Times: user=0.00 sys=0.00, real=0.00 secs] 2017-03-29T14:37:12.813+0200: 8.833: Total time for which application
threads were stopped: 0.0010682 seconds, Stopping threads took: 0.0000155 seconds

GCViewer will report one event in the "Gc pauses" area and one in this area. The pause duration reported for "Total time..." will be 0.0001342s (0.0010682 (duration of safepoint pause) - 0.0009340 (duration of gc pause)) So GCViewer only calculates the additional overhead needed for the whole safepoint on top of the gc pause.

If the event immediately before the "Total time..." event was not a any kind of gc pause, but another "Total time..." event, then the whole pause for "Total time..." will be recorded for this event. In this case the safepoint was not caused by a gc pause.

Concurrent GCs

This are contains information about concurrent collection cycles, if the gc algorithm used them. The time reported here is spent while the application threads are running. It is possible to read here, how long concurrent gc operations took until they finished.

Parser

In the third tab the output of the parser is shown. If there were warnings during the parsing process or other output, you can check there.

Data Panel

GCViewer provides some metrics to help you interpret the chart. Note that some metrics based on averages are shown along with their standard deviation. If it is obvious that the standard deviation is fairly big in comparison to the average, the values are grayed out, indicating that actual values are much smaller or bigger than the average.

Summary

• Footprint:
  • Maximal amount of memory allocated
• Max heap after conc GC:
  • Max used heap after concurrent gc.
• Max tenured after conc GC:
  • Max used tenured heap after concurrent gc (followed by % of max tenured / % of max total heap).
• Max heap after full GC:
  • Max used heap after full gc. Indicates max live object size and can help to determine heap size.
• Freed Memory:
  • Total amount of memory that has been freed
• Freed Mem/Min:
  • Amount of memory that has been freed per minute
• Total Time:
  • Time data was collected for (only if timestamp was present in log)
• Acc Pauses:
  • Sum of all pauses due to GC
• Throughput:
  • Time percentage the application was NOT busy with GC
• Full GC Performance:
  • Performance of full collections. Note that all collections that include a collection of the tenured generation or are marked with "Full GC" are considered Full GC.
• GC Performance:
  • Performance of minor collections. These are collections that are not full according to the definition above.

Memory

• Total heap (usage / alloc max):
  • Max memory usage / allocation in total heap (the last is the same as "footprint" in Summary)
• Tenured heap (usage / alloc max):
  • Max memory usage / allocation in tenured space
• Young heap (usage / alloc max):
  • Max memory usage / allocation in young space
• Perm heap (usage / alloc max):
  • Max memory usage / allocation in perm space
• Max tenured after conc GC:
  • see in "summary" section
• Avg tenured after conc GC:
  • average size of tenured heap after concurrent collection
• Max heap after conc GC:
  • see in "summary" section
• Avg heap after conc GC:
  • average size of concurrent heap after concurrent collection
• Max heap after full GC:
  • see in "summary" section
• Avg after full GC:
  • The average heap memory consumption after a full collection
• Avg after GC:
  • The averag
