Concept

The StarTool executes commands for selecting and editing data in a Relion STAR file. The given order of commands defines the order of execution meaning that editing commands work on previously made selections (except when changing global properties as tablenames, column names etc.). Such edited STAR files can be written out as a new starfile and subsets (selections) can be exported as well.

Behind the scenes, the STAR file is loaded into an in-memory SQLite3 database. Selections and edits are executed in that database and only when writing back into a file, the data will be retrieved from the database. Therefore, the StarTool could be easily extended as an interface for solutions where STAR files are stored in an SQLite database.

Quick reference

These commands (ordered alphabetically) are available.

| Command | Description | |---|---| | <a href="#add_col">--add_col</a> | Adds a new column | | <a href="#delete">--delete</a> | Deletes selected data | | <a href="#delete_col">--delete_col</a> | Deletes a column | | <a href="#delete_table">--delete_table</a> | Deletes a data table | | <a href="#deselect">--deselect</a> | Unsets all seleections | | <a href="#info">--info</a> | Prints information about STAR file | | <a href="#math">--math</a> | Basic math operations with values and columns | | <a href="#merge">--merge</a> | Merge two or more files | | <a href="#query">--query</a> | Submit a user defined SQLite query | | <a href="#release">--release</a> | Unsets the current table in use (for multi table files) | | <a href="#rename_col">--rename_col</a> | Renames a colum | | <a href="#rename_table">--rename_table</a> | Renames a data table | | <a href="#replace">--replace</a> | Replaces values by a user defined value | | <a href="#replace_regex">--replace_regex</a> | Regular expression base replacing | | <a href="#replace_star">--replace_star</a> | Replace values with values from other STAR file | | <a href="#select">--select</a> | Select data by operator based conditions | | <a href="#select_regex">--select_regex</a> | Select data based on regular expressions | | <a href="#select_star">--select_star</a> | Select data based on matches with reference STAR file | | <a href="#silent">--silent</a> | Mutes program output | | <a href="#show">--show</a> | Prints currently selected data | | <a href="#sort">--sort</a> | Sorts selected data (ascending) | | <a href="#split_by">--split_by</a> | Splits data into batches | | <a href="#subset">--subset</a> | Selects defined data subsets | | <a href="#tros">--tros</a> | Sorts selected data (descending) | | <a href="#use">--use</a> | Defines a table to use (only for multi table STAR files) | | <a href="#write">--write</a> | Writes STAR file | | <a href="#write_selection">--write_selection</a> | Writes current selection to STAR file | | <a href="#writef">--writef</a> | Writes STAR file (force override) | | <a href="#writef_selection">--writef_selection</a> | Writes current selection to STAR file (force override) |

Setup

StarTool requires Python 2.7.

Unix based systems (including the partially eaten fruit)

Extract the two files startool.py and STLib.py to your location of choice. Run the Program as python /path/toStarTool/startool.py.

In case you want to have the tool available system wide, use a shell alias like alias stool="python /path/to/StarTool/startool.py $@".

Windows

Coming soon...

Syntax

General usage and input

python startool.py [inputfiles] [selectors/editors] [output]

Example: python startool.py a_file.star --select _rlnVoltage=300 --write_selection selection.star

Multiple files can be loaded by comma separation. The program internally will create tables with the scheme ‘starfilename_tablename’.

In order to make use of faster data handling, one can also use

python startool.py example.star:example.db

to load the STAR file into a local data base file. Changes made by editors will be directly affect that database file. Remember to remove that database file if you want to start over with the original data from your STAR file.

Information

<a name="info"><pre><b>--info</b></pre></a>

Prints the current starfiles/tables loaded and their labels and record numbers. This should always be used at the beginning to get an overview what data you actually have loaded.

Data display

<a name="show"><pre><b>--show</b></pre></a>

Prints the current content of the table in use. Selectors are applied.

Selecting subsets of data

These methods can be used to select certain subsets of your data. This is useful if you want to edit or extract only a certain part of the data.

<a name="select"><pre><b>--select _rlnLabel operator value</b></pre></a>

Selects a subset of the current table based on an operator comparison. Allowed are

<table> <tr> <td>=</td> <td>equal</td> </tr> <tr> <td>!=</td> <td>not equal </td> </tr> <tr> <td>\< </td> <td>smaller than (needs to be escaped)</td> </tr> <tr> <td>\></td> <td>greater than (needs to be escaped) </td> </tr> <tr> <td>\<= </td> <td>smaller or equal than (needs to be escaped) </td> </tr> <tr> <td>\>=</td> <td>greater or equal than (needs to be escaped) </td> </tr> </table>

Example: --select _rlnDefocusU\>=10000 will select all entries with defocus greater or equal to 1 um.

<a name="select_regex"><pre><b>--select_regex _rlnLabel=”regex”</b></pre></a>

Selects a subset of the current table based on a regular expression match. Allowed are regular ex- pressions.

Example: --select _rlnMicrographName=”.*\.mrcs$” will select all entries where _rlnMicrographName end with '.mrcs'.

<a name="select_star"><pre><b>--select_star reference.star:rlnA[variationA],_rlnB[variationB]</b></pre></a>

Selects a subset of the current table based on entries in reference.star. reference.star should only have one data table. The variation value '[x]' is optional and will only be interpreted for numerical columns (like coordinates, defocus etc.). Reference STAR files will be loaded temporarily and do not have to be loaded at the program start up.

Example: --select_star reference.star:_rlnImageName,_rlnCoordinateX[10],_rlnCoordinateY[10] will select all entries that match by _rlnMicrographName with reference.star and where _rlnCoordinateX/Y also matches allowing 10 px variation.

<a name="subset"><pre><b>--subset start:end</b></pre></a>

Selects a subset of records including the records given as numbers. For splitting Data into regular batches see also <a href="#split_by">--split_by</a>.

Example: --subset 3:244 will select data entries 3-244 (including 3 and 244).

<a name="deselect"><pre><b>--deselect</b></pre></a>

Unsets all selections.

<a name="use"><pre><b>--use tablename</b></pre></a>

By default, the program uses the table that was read in if there is only one. --use must be called, if multiple data tables are read from one or more starfiles (you may check by using --info). Calling --use will clear all other previously made selections.

<a name="release"><pre><b>--release</b></pre></a>

Releases the current table by unsetting the --use and --select* statements (changes made by editors will remain).

Global Editors

Global editors ignore selections made before since they only change global properties of data tables like tablename or column labels.

<a name="add_col"><pre><b>--add_col _rlnNewLabel</b></pre></a>

Adds a new column to the current data table in use.

<a name="rename_col"><pre><b>--rename_col _rlnLabelOld=_rlnLabelNew</b></pre></a>

Renames _rlnLabelOld to _rlnLabelNew in the current table in use.

<a name="delete_col"><pre><b>--delete_col _rlnUnwantedLabel</b></pre></a>

Removes _rlnUnwantedLabel (including data!) from the current data table in use.

<a name="delete_table"><pre><b>--delete_table tablename</b></pre></a>

Removes the whole table from the starfile (including data!). If the current table is removed, all selec- tors are reset.

<a name="rename_table"><pre><b>--rename_table tablenameNew</b></pre></a>

Renames the current table in use to tablenameNew. Be aware that renaming tables may screw up compatibility with Relion.

Local Editors

Loval editors directly affect the data that is currently selected (see <a href="#selecting-subsets-of-data">Selecting subsets of data</a>) <a name="sort"><pre><b>--sort _rlnlabel</b></pre></a>

Sorts the selected data by the given label (ascending).

<a name="tros"><pre><b>--tros _rlnlabel</b></pre></a>

Sorts the selected data by the given label (descending).

<a name="delete"><pre><b>--delete</b></pre></a>

Deletes the current selection from the data table in use.

<a name="replace"><pre><b>--replace _rlnWhatEver=3.1415</b></pre></a>

Replaces all values of the specified column with the given value. The column needs to exist in the current data table. This can also be used to fill empty columns with zeros (because Relion can not handle empty columns).

<a name="replace_regex"><pre><b>--replace_regex _rlnWhatEver='search'%'replace'</b></pre></a>

Replaces all values of the specified column matching the 'search' pattern with 'repl
