About

CAN BUS tools in Python 3.

• DBC, KCD, SYM, ARXML 3&4 and CDD file parsing.

• CAN message encoding and decoding.

• Simple and extended signal multiplexing.

• Diagnostic DID encoding and decoding.

• candump output decoder.

• Node tester_.

• C source code generator.

• CAN bus monitor.

• Graphical plots of signals.

Project homepage: https://github.com/cantools/cantools

Documentation: https://cantools.readthedocs.io

Installation

.. code-block:: bash

python3 -m pip install cantools

Example usage

Scripting

The example starts by parsing a small DBC-file_ and printing its messages and signals.

.. code-block:: python

import cantools from pprint import pprint db = cantools.database.load_file('tests/files/dbc/motohawk.dbc') db.messages [message('ExampleMessage', 0x1f0, False, 8, 'Example message used as template in MotoHawk models.')] example_message = db.get_message_by_name('ExampleMessage') pprint(example_message.signals) [signal('Enable', 7, 1, 'big_endian', False, 1.0, 0, 0.0, 0.0, '-', False, None, {0: 'Disabled', 1: 'Enabled'}, None), signal('AverageRadius', 6, 6, 'big_endian', False, 0.1, 0, 0.0, 5.0, 'm', False, None, None, ''), signal('Temperature', 0, 12, 'big_endian', True, 0.01, 250, 229.53, 270.47, 'degK', False, None, None, None)]

The example continues encoding_ a message and sending it on a CAN bus using the python-can_ package.

.. code-block:: python

import can can_bus = can.interface.Bus('vcan0', bustype='socketcan') data = example_message.encode({'Temperature': 250.1, 'AverageRadius': 3.2, 'Enable': 1}) message = can.Message(arbitration_id=example_message.frame_id, is_extended_id=example_message.is_extended_frame, data=data) can_bus.send(message)

Alternatively, a message can be encoded using the encode_message()_ method on the database object.

The last part of the example receives and decodes_ a CAN message.

.. code-block:: python

message = can_bus.recv() db.decode_message(message.arbitration_id, message.data) {'AverageRadius': 3.2, 'Enable': 'Enabled', 'Temperature': 250.09}

See examples_ for additional examples.

Command line tool

The decode subcommand ^^^^^^^^^^^^^^^^^^^^^

Decode CAN frames captured with the Linux program candump.

.. code-block:: text

$ candump vcan0 | python3 -m cantools decode tests/files/dbc/motohawk.dbc vcan0 1F0 [8] 80 4A 0F 00 00 00 00 00 :: ExampleMessage( Enable: 'Enabled' -, AverageRadius: 0.0 m, Temperature: 255.92 degK ) vcan0 1F0 [8] 80 4A 0F 00 00 00 00 00 :: ExampleMessage( Enable: 'Enabled' -, AverageRadius: 0.0 m, Temperature: 255.92 degK ) vcan0 1F0 [8] 80 4A 0F 00 00 00 00 00 :: ExampleMessage( Enable: 'Enabled' -, AverageRadius: 0.0 m, Temperature: 255.92 degK )

Alternatively, the decoded message can be printed on a single line:

.. code-block:: text

$ candump vcan0 | python3 -m cantools decode --single-line tests/files/dbc/motohawk.dbc vcan0 1F0 [8] 80 4A 0F 00 00 00 00 00 :: ExampleMessage(Enable: 'Enabled' -, AverageRadius: 0.0 m, Temperature: 255.92 degK) vcan0 1F0 [8] 80 4A 0F 00 00 00 00 00 :: ExampleMessage(Enable: 'Enabled' -, AverageRadius: 0.0 m, Temperature: 255.92 degK) vcan0 1F0 [8] 80 4A 0F 00 00 00 00 00 :: ExampleMessage(Enable: 'Enabled' -, AverageRadius: 0.0 m, Temperature: 255.92 degK)

The plot subcommand ^^^^^^^^^^^^^^^^^^^

The plot subcommand is similar to the decode subcommand but messages are visualized using matplotlib_ instead of being printed to stdout.

.. code-block:: bash

$ candump -l vcan0
$ cat candump-2021-01-04_180521.log
(1609779922.655421) vcan0 00000343#B204B9049C049C04
(1609779922.655735) vcan0 0000024A#120527052E051905
(1609779923.657524) vcan0 00000343#C404C404CB04C404
(1609779923.658086) vcan0 0000024A#8B058B058B059205
(1609779924.659912) vcan0 00000343#5C04790479045504
(1609779924.660471) vcan0 0000024A#44064B0659064406
(1609779925.662277) vcan0 00000343#15040704F203F203
(1609779925.662837) vcan0 0000024A#8B069906A706A706
(1609779926.664191) vcan0 00000343#BC03B503A703BC03
(1609779926.664751) vcan0 0000024A#A006A706C406C406

$ cat candump-2021-01-04_180521.log | python3 -m cantools plot tests/files/dbc/abs.dbc

.. image:: https://github.com/cantools/cantools/raw/master/docs/plot-1.png

If you don't want to show all signals you can select the desired signals with command line arguments. A * can stand for any number of any character, a ? for exactly one arbitrary character. Signals separated by a - are displayed in separate subplots. Optionally a format can be specified after a signal, separated by a colon.

.. code-block:: bash

$ cat candump-2021-01-04_180521.log | python3 -m cantools plot tests/files/dbc/abs.dbc '*33.*fl:-<' '*33.*fr:->' - '*33.*rl:-<' '*33.*rr:->'

.. image:: https://github.com/cantools/cantools/raw/master/docs/plot-2-subplots.png

Signals with a different range of values can be displayed in the same subplot on different vertical axes by separating them with a comma.

.. code-block:: bash

$ cat candump-2021-01-04_180521.log | cantools plot --auto-color tests/files/dbc/abs.dbc --
--ylabel 'Bremse 33' '_33.fl:-<' '_33.fr:>' '_33.rl:3' '_33.rr:4' ,
--ylabel 'Bremse 2' '_2.fl:-<' '_2.fr:>' '_2.rl:3' '_2.rr:4'

.. image:: https://github.com/cantools/cantools/raw/master/docs/plot-2-axes.png

Matplotlib comes with different preinstalled styles that you can use:

.. code-block:: bash

$ cat candump-2021-01-04_180521.log | cantools plot tests/files/dbc/abs.dbc --style seaborn

.. image:: https://github.com/cantools/cantools/raw/master/docs/plot-seaborn.png

You can try all available styles with

.. code-block:: bash

$ cantools plot --list-styles . | sed -n '/^- /s/^- //p' | while IFS= read -r style; do cat candump-2021-01-04_180521.log | cantools plot tests/files/dbc/abs.dbc --style "$style" --title "--style '$style'" done

For more information see

.. code-block:: bash

$ python3 -m cantools plot --help

Note that by default matplotlib is not installed with cantools. But it can be by specifying an extra at installation:

.. code-block:: bash

$ python3 -m pip install cantools[plot]

The dump subcommand ^^^^^^^^^^^^^^^^^^^

Dump given database in a human readable format:

.. code-block:: text

$ python3 -m cantools dump tests/files/dbc/motohawk.dbc ================================= Messages =================================

 ------------------------------------------------------------------------

 Name:       ExampleMessage
 Id:         0x1f0
 Length:     8 bytes
 Cycle time: - ms
 Senders:    PCM1
 Layout:

                         Bit

            7   6   5   4   3   2   1   0
          +---+---+---+---+---+---+---+---+
        0 |<-x|<---------------------x|<--|
          +---+---+---+---+---+---+---+---+
            |                       +-- AverageRadius
            +-- Enable
          +---+---+---+---+---+---+---+---+
        1 |-------------------------------|
          +---+---+---+---+---+---+---+---+
        2 |----------x|   |   |   |   |   |
    B     +---+---+---+---+---+---+---+---+
    y               +-- Temperature
    t     +---+---+---+---+---+---+---+---+
    e   3 |   |   |   |   |   |   |   |   |
          +---+---+---+---+---+---+---+---+
        4 |   |   |   |   |   |   |   |   |
          +---+---+---+---+---+---+---+---+
        5 |   |   |   |   |   |   |   |   |
          +---+---+---+---+---+---+---+---+
        6 |   |   |   |   |   |   |   |   |
          +---+---+---+---+---+---+---+---+
        7 |   |   |   |   |   |   |   |   |
          +---+---+---+---+---+---+---+---+

 Signal tree:

   -- {root}
      +-- Enable
      +-- AverageRadius
      +-- Temperature

 Signal choices:

   Enable
       0 Disabled
       1 Enabled

 ------------------------------------------------------------------------

The list subcommand ^^^^^^^^^^^^^^^^^^^

Print all information of a given database in a human readable format. This is very similar to the "dump" subcommand, but the output is less pretty, slightly more comprehensive and easier to parse by shell scripts:

.. code-block:: bash

$ python3 -m cantools list -a tests/files/dbc/motohawk.dbc
ExampleMessage:
  Comment[None]: Example message used as template in MotoHawk models.
  Frame ID: 0x1f0 (496)
  Size: 8 bytes
  Is extended frame: False
  Signals:
    Enable:
      Type: Integer
      Start bit: 7
      Length: 1 bits
      Unit: -
      Is signed: False
      Named values:
        0: Disabled

The generate C source subcommand ^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^

Generate C source code from given database.

The generated code contains:

• Message structs_.

• Message pack_ and unpack_ functions.

• Signal encode_ and decode_ functions.

• Frame id, length, type, cycle time and signal choices defines_.

Known limitations:

• The maximum signal size is 64 bits, which in practice is never exceeded.

Below is an example of how to generate C source code from a database. The database is tests/files/dbc/motohawk.dbc.

.. code-block:: text

$ python3 -m cantools generate_c_source tests/files/dbc/motohawk.dbc Successfully generated motohawk.h and motohawk.c.

See motohawk.h_ and motohawk.c_ for the contents of the generated files.

In this example we use --use-float so floating point numbers in the generated code are single precision (`
