Davraz

Try it NOW! https://canbax.github.io/davraz/

A graph visualization and exploration tool. Currently support visualizing Tiger Graph and Neo4j databases. You can watch introductory video

I was a virtual attendee at the Graph+AI World 2020! Graph+AI World Day 2 Keynote #GraphAIWorld https://www.tigergraph.com/graphaiworld/ You can directly watch my presentation in the event from here

Screenshots

Connect to a TigerGraph instance.

https://user-images.githubusercontent.com/8426741/167489419-1a5ef6dc-1b16-4ce9-9cfb-e50b043a473c.mp4

Connect to a local Neo4j instance.

https://user-images.githubusercontent.com/8426741/173191229-3e1d5d43-0221-4ba1-a4ce-d0635d36fce4.mp4

"Load", "Save", ... from "File" menu

https://user-images.githubusercontent.com/8426741/168469340-ffc320a8-f354-47e2-ba15-6a532e4d1d66.mp4

"Delete Selected", "Hide Selected", ... from "Edit" menu

https://user-images.githubusercontent.com/8426741/168469711-9c9e8192-594b-4c7d-be96-56fcd930cac0.mp4

"Sample Data" and "Clear Data" from "Data" menu

https://user-images.githubusercontent.com/8426741/169713544-d80cb3a2-47b1-4353-b45d-a1d40a63be85.mp4

From "Layout" menu, you can run an incremental or randomized layout. There are many different layout types but the default is fCoSE algorithm.

https://user-images.githubusercontent.com/8426741/169894364-1b580bc4-8e29-4fb3-b617-78584c6fa86e.mp4

From "Highlight" menu, elements can be emphasized to distinguish from others.

https://user-images.githubusercontent.com/8426741/169894862-12f0ad6d-3ff1-4576-b33f-13db20a370c7.mp4

From "Compound" menu, compound elements can be created or removed.

https://user-images.githubusercontent.com/8426741/169895099-7ea9f1b6-7b8a-4610-89c6-22889c6807e7.mp4

From "Table" menu, whole data or a part of the existing data can be shown as table(s).

https://user-images.githubusercontent.com/8426741/169895482-1400933c-40f9-4eef-851b-992f15e9320a.mp4

From "Cluster" menu, you can run "Markov Clustering" algorithm or cluster degree-1 nodes.

https://user-images.githubusercontent.com/8426741/169896671-bd270f71-a985-4497-9c09-413cca9245a0.mp4

<p align="center"> <img src="doc/img/compound_nodes.png" width="600"/> </p> <p align="center"> Support for compound nodes </p> <p align="center"> <img src="doc/img/File Explorer like windows.gif" width="600"/> </p> <p align="center"> Windows very similar to file explorer of an operating system </p> <p align="center"> <img src="doc/img/animated_edges_on_table_hover.gif" width="600"/> </p> <p align="center"> Animated edges when hovered on table </p> <p align="center"> <img src="doc/img/show_results_of_installed_query_as_json.png" width="600"/> </p> <p align="center"> Show results of a query as JSON at the same time </p>

YAAAY!

This project got a 1st Place Reward in TigerGraph 2020 Graphathon

todo (or might todo)

• adding/updating graph elements
• client-side filterig with raw cytoscape.js
• badges on the nodes
• show statistics
• graph theoretical properties

For Developers

Built with Angular CLI version 10.0.4. Use npm i to install dependencies. ng s to run in development mode. I also use angular-cli-ghpages for deploying my app to github-pages branch using the command ng deploy --base-href=/davraz/. Thanks for this useful library.
