<div align="center"> <img src="resources/icon.svg" width="300" height="300"> <br> <h2>PCIem</h2> </div> <div align="center"> A Linux kernel framework enabling synthetic userspace PCIe device emulation. | <a href="https://cakehonolulu.github.io/docs/pciem">Documentation</a> </div>

What is PCIem?

PCIem is a framework that creates virtual PCIe devices in the Linux kernel by leveraging a few novel techniques to populate synthetic cards as legitimate PCI devices to the host OS.

To brief what PCIem is: a framework for (Albeit not limited to) developing and testing PCIe device drivers without requiring actual hardware on the host.

Comparison with libfvio-user

PCIem and libfvio-user are two different solutions for different needs, there may be confusion when comparing both so herein the differences (See figure 1 for more).

The main one is that libvfio-user usually relies on a client (That implements the vfio-user protocol), usually QEMU (Through KVM, using VM exits) to expose the emulated PCIe device to the guest. You write your vfio server (With a callback mechanism usually) which then interacts with the client.

What PCIem does instead is, expose the device directly on the host; no KVM, no guests, no virtual machines, nothing. The device appears on the host's PCIe bus as if it was physically connected.

Figure 1: Comparison between frameworks

</div>

Architecture

graph LR
    subgraph Kernel ["Host Linux Kernel"]
        direction TB

        RealDriver["Real PCIe Driver"]

        subgraph Framework ["PCIem Framework"]
            direction TB
            Config["PCI Config Space"]
            BARs["BARs"]
            IRQ["Interrupts"]
            DMA["DMA / IOMMU"]
        end

    end

    Interface(("/dev/pciem"))

    subgraph User ["Linux Userspace"]
        direction TB
        Shim["Device Emulation"]
    end

    Framework <==> Interface
    Interface <==> Shim

Current Features

BAR creation: Programmatically create and monitor BAR regions.
BAR MMIO tracing: MMIO read/write detection and notification to avoid polling for accesses.
Interrupts support: Legacy/MSI/MSI-X interrupt injection.
PCI capability framework: PCI capabilities system (Linked-list underneath).
DMA system: IOMMU-aware DMA accesses from/to userspace device.
- P2P support (Preliminar!): Peer-to-peer DMA between devices with whitelist-based access control.
Userspace: Implement your PCIe devices entirely in userspace.

Minimum supported environment

Linux Kernel Version: 6.6
C Compiler: gcc-12
Architecture: amd64/i386, aarch64, riscv

aarch64 note: Tested w/Raspberry Pi 4b, device-tree (No ACPI)

riscv note: Tested w/VisionFive 2 (Device-tree) and Muse Pi Pro (Device-tree and ACPI)

CI Status

| Distribution | <img src="https://img.shields.io/badge/-amd64-ED1C24?style=flat-square&logo=amd&logoColor=white"/> <img src="https://img.shields.io/badge/-i386-0071C5?style=flat-square&logo=intel&logoColor=white"/> | <img src="https://img.shields.io/badge/-aarch64-0091BD?style=flat-square&logo=arm&logoColor=white"/> | <img src="https://img.shields.io/badge/-riscv-283272?style=flat-square&logo=riscv&logoColor=white"/> | | :--- | :---: | :---: | :---: | | Ubuntu Latest | <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=amd64%20build%20(Ubuntu%20latest)&style=flat-square&logo=ubuntu&logoColor=white&label=build&labelColor=E95420"/> <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=amd64%20QEMU%20Test%20(Ubuntu%20Latest)&style=flat-square&logo=qemu&logoColor=white&label=qemu&labelColor=E95420"/> | - | - | | Ubuntu 24.04 LTS | <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=amd64%20build%20(Ubuntu%20LTS)&style=flat-square&logo=ubuntu&logoColor=white&label=build&labelColor=E95420"/> <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=amd64%20QEMU%20Test%20(Ubuntu%2024.04%20LTS)&style=flat-square&logo=qemu&logoColor=white&label=qemu&labelColor=E95420"/> | <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=aarch64%20build%20(Ubuntu%20latest)&style=flat-square&logo=ubuntu&logoColor=white&label=build&labelColor=E95420"/> <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=aarch64%20QEMU%20Test%20(Ubuntu%20LTS)&style=flat-square&logo=qemu&logoColor=white&label=qemu&labelColor=E95420"/> | <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=riscv%20build%20(Ubuntu%20latest)&style=flat-square&logo=ubuntu&logoColor=white&label=build&labelColor=E95420"/> <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=riscv%20QEMU%20Test%20(Ubuntu%20LTS)&style=flat-square&logo=qemu&logoColor=white&label=qemu&labelColor=E95420"/> | | Debian Stable | <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=amd64%20build%20(Debian%20stable)&style=flat-square&logo=debian&logoColor=white&label=build&labelColor=A81D33"/> <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=amd64%20QEMU%20Test%20(Debian%20Stable)&style=flat-square&logo=qemu&logoColor=white&label=qemu&labelColor=A81D33"/> | - | - | | Fedora Latest | <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=amd64%20build%20(Fedora%20Latest)&style=flat-square&logo=fedora&logoColor=white&label=build&labelColor=294172"/> <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=amd64%20QEMU%20Test%20(Fedora%20Latest)&style=flat-square&logo=qemu&logoColor=white&label=qemu&labelColor=294172"/> | - | - | | openSUSE Tumbleweed | <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=amd64%20build%20(openSUSE%20Tumbleweed)&style=flat-square&logo=opensuse&logoColor=white&label=build&labelColor=2D5F0F"/> <img src="https://img.shields.io/github/actions/workflow/status/cakehonolulu/pciem/ci.yml?job=amd64%20QEMU%20Test%20(openSUSE%20Tumbleweed)&style=flat-square&logo=qemu&logoColor=white&label=qemu&labelColor=2D5F0F"/> | - | - |

Examples

Bochs BGA (drm) Card

A Bochs BGA-compatible (bochs-drm) card that can be driven by userspace utilities such as Weston; uses SDL3.

https://github.com/user-attachments/assets/d2f7abe4-aef4-4d3a-a30b-ab7ec793faed

NVME Controller

NVME controller with 1GB of storage attached to. User can freely format, mount, create and remove files from the memory.

https://github.com/user-attachments/assets/29ce370a-7317-4fd4-9d1d-c3e868e1083d

Intel HDA Card

ICH6-compatible emulation model that can play samples in conjunction with pipewire.

NOTE: Slight audio crackling only heard on recording, works fine otherwise

https://github.com/user-attachments/assets/7264a18c-6fcb-46c4-acde-9531b0be7ff6

Intel E1000 Card

A pretty naive implementation of the E1000 card. Supports communications redirection to/from your real NIC. Can also use Wi-Fi but it's less stable.

https://github.com/user-attachments/assets/b6b9862c-349c-49da-8a79-4769dfa31915

<details> <summary>Legacy example(s)</summary> <h2>ProtoPCIem card</h2>

The card is programmed entirely in QEMU (State machine for the card, basically), which does all the userspace initialization and command handling from the real driver running in the host.

Can run software-rendered DOOM (Submits finished frames with DMA to the card which QEMU displays) and also simple OpenGL 1.X games (On the screenshots, tyr-glquake and xash3d; thanks to a custom OpenGL state machine implemented entirely in QEMU that software-renders the command lists and updates the internal state accordingly).

<details> <summary>Screenshots</summary> <p align="center"> <img width="1903" height="1029" alt="imagen" src="https://github.com/user-attachments/assets/16f64475-ee51-4f79-ae17-b06363f0b12a" /> </p> <p align="center"> <img width="1757" height="893" alt="imagen" src="https://github.com/user-attachments/assets/4ad00e14-83e5-4e1f-b374-fbaa92def4e3" /> </p> <p align="center"> <img width="1227" height="846" alt="imagen" src="https://github.com/user-attachments/assets/d21a7d84-f857-4790-bdc6-7bf2714e9eda" /> </p> </details> </p> </details>

License

PCIem kernel components: GPLv2
Examples: dual MIT/GPLv2.

References

Blog post: https://cakehonolulu.github.io/introducing-pciem/
Hackernews post: https://news.ycombinator.com/item?id=46689065
PCI Express specification: https://pcisig.com/specifications
