A minimalist, general-purpose programming language based on meta-programming and parse tree rewrites
Install / Use
/learn @c3d/XlREADME
XL - An extensible language
WARNING: XL is a work in progress. Even if there are some bits and pieces that happen to already work, XL is presently not suitable for any serious programming. Examples given below may sometimes simply not work. Take it as a painful reminder that the work is far from finished, and, who knows, as an idea for a contribution. See HISTORY for how we came to the present mess, and Compiler status for information about what is expected to work, and Compiler overview for a quick overview of the compiler internals.
XL is an extensible programming language designed to accomodate a variety of programming needs with ease. Being extensible means that the language is designed to make it very easy for programmers to adapt the language to suit their needs, for example by adding new programming constructs. In XL, extending the language is a routine operation, much like adding a function or creating a class in more traditional programming languages.
As a validation of this bold claim, XL has a single fundamental operator,
the definition operator,
which you write [Pattern] is [Implementation, where] [Pattern] is
a program pattern, like X+Y, and [Implementation] explains how to
translate that pattern, for example Add X, Y.
Everything that is built-in in most other programming languages, from basic data types to arithmetic to conditionals to loops is provided by the standard library in XL. You can replace these constructs if you want, or add your own. Adding a new kind of loop is not more difficult in XL than adding a function, and it uses the same syntax.
- Simple examples
- Dialects and use cases
- If you come from another language
- One operator to rule them all
- Syntax: Look, Ma, no keywords!
- XL as a functional language
- Subtelty #1: Expression vs statement
- Subtelty #2: Infix vs. Prefix
- Subtelty #3: Delayed evaluation
- Subtelty #4: Closures
For more information, please consult the XL handbook, also available in asciidoc format and PDF format
WARNING This documentation, like the compiler, is work in progress and presently extremely messy, incomplete and inaccurate.
A few simple examples
A program computing the factorial of numbers between 1 and 5 would be written as follows:
0! is 1
N! is N * (N-1)!
for I in 1..5 loop
print "The factorial of ", I, " is ", I!
As a testament to its extensible nature, fundamental operations in XL
are defined in the standard library, including operations that would
be implemented using keywords in more traditional languages. For
example, the if statement in XL is defined by the following code:
if [[true]] then TrueClause else FalseClause is TrueClause
if [[false]] then TrueClause else FalseClause is FalseClause
if [[true]] then TrueClause is TrueClause
if [[false]] then TrueClause is false
Similarly, the while loop is defined as follows:
while Condition loop Body is
if Condition then
Body
while Condition loop Body
The standard library also provides implementations for usual
operations. For example, if you evaluate 1+3, this is done through a
definition for + on integer values that looks like the following
(where ... denotes some implementation-dependent code):
X:integer + Y:integer is ...
Dialects and use cases
Two dialects of XL further demonstrate the extensibility of the language
-
Tao3D focuses on real-time 3D animations and can be used as a scriptable presentation software, or as someone once described it, a sort of real-time 3D LaTeX Lisp. In Tao3D, you describe a slide with a program that looks like the following code:
import Slides slide "A simple slide example", * "This looks like some kind of markdown language" * "But code makes it powerful: your mouse is on the " & position position is if mouse_x < 0 then "left" else "right"The examples above use the new syntax in XL, with
isas its definition operator. Older variants of the language used->instead. If you downloaded a pre-built binary of Tao3D, chances are that you need to replaceiswith->for the code above to work as intended. -
ELFE, formerly ELIOT (Extensible Language for the Internet of things) was an experiment on how to write distributed software that looks like a single program, for example to control swarms of devices in the context of the Internet of Things. An example of a simple ELFE program would be:
WORKER is "worker.mycorp.com" MIN_TEMP is 25 MAX_TEMP is 55 invoke WORKER, every 2s, reply display temperature display Temp:real is print "The temperature of ", WORKER, " is ", Temp
The present branch,
bigmerge, is an ongoing effort to reconverge the various dialects of XL. At the moment, it should pass most of the ELFE-level tests, although this is not actively tested. Getting it to support Tao3D is somewhat more difficult and may take some time.
If you come from another language
If you are familiar with other programming languages, here are a few things that may surprise you about XL.
- There are no keywords. In C,
ifis a keyword. In XL, it's just a name. - The language is designed primarily to be readable and writable by humans. For example, there are special parsing rules to match how we read the code.
- The language is homoiconic, i.e. programs are data, like in Lisp. This forms the basis of XL extensibility.
- Evaluation is defined entirely in terms of rewrites of a very simple abstract. syntax tree that represents the program being evaluated.
- The precedence of all operators is dynamic, in the sense that it's loaded from a configuration file
- The language is primarily defined by its own standard library, rather than by special rules in the compiler.
Semantics: One operator to rule them all
XL has one fundamental operator, is, the definition operator.
This operator can be read as transforms into, i.e. it transforms the
code that is on the left into the code that is on the right.
pi is 3.1415926
words is "xylophage", "zygomatic", "barfitude"
abs X is if X < 0 then -X else X
X ≠ Y is not X = Y
0! is 1
N! when N > 0 is N * (N-1)!
A in B..C is A >= B and A <= C
X * 1 is X
X + 0 is X
loop Body is Body; loop Body
type complex is polar or cartesian
type cartesian is cartesian(re:number, im:number)
type polar is polar(mod:number, arg:number)
Note that types in XL indicate the shape of parse trees. In other
words, the cartesian type above will match any parse tree that takes
the shape of the word cartesian followed by two numbers, like for
example cartesian(1,5).
adder N is (X is N + X)
add3 is adder 3
// This will compute 8
add3 5
This makes XL a truly functional language.
</details> <details> <summary>It can define maps associating a key to a value</summary>my_map is
0 is 4
1 is 0
8 is "World"
27 is 32
N when N < 45 is N + 1
// The following is "World"
my_map 8
// The following is 32
my_map[27]
// The following is 45
my_map (44)
This provides a functionality roughly equivalent to std::map in
C++. However, it's really nothing more than a regular function with a
number of special cases. The compiler can optimize some special kinds
of mapping to provide an efficient implementation.
// An (inefficient) implementation of a generic 1-based array type
type array [1] of T is
Value : T
1 is Value
type array [N] of T when N > 1 is
Head : array[N-1] of T
Tail : T
I when I<N is Head[I]
I when I=N is Tail
A : array[5] of integer
for I in 1..5 loop
A[I] := I * I
min X is X
min X, Y is { Z is min Y; if X < Z then X else Z }
// Computes 4
min 7, 42, 20, 8, 4, 5, 30
In short, the single is operator covers all kinds of declarations
that are found in other languages, using a single, easy to read
