ControllerBuddy

<!--suppress HtmlDeprecatedAttribute --> <img src="icon/icon.svg" alt="ControllerBuddy Logo" align="right" width="128px"/>

Visit the ControllerBuddy Homepage to get started.
Join the ControllerBuddy Discord for support and community discussions.

📖 Description

ControllerBuddy is an advanced gamepad mapping software that supports the creation of input profiles for complex target applications such as flight simulators.

In addition to the simple mapping of buttons and axes of a physical game controller to keyboard and mouse input, ControllerBuddy also supports feeding input commands to a virtual joystick device (vJoy / uinput).

The goal of ControllerBuddy is to allow the user to control target applications exclusively with a gamepad without ever having to reach for a keyboard or mouse.

⬇️ Download and Installation

📜 Install-Script

For the easiest way to install and update, use the ControllerBuddy-Install-Script.
It automates all the steps below and much more!

📦 Flatpak

Linux users may want to use the ControllerBuddy-Flatpak.

🧑‍🔧 Manual Installation

🪟 Windows x86-64

1. First download and install vJoy 2.2.2.0 on your system.
2. Click here and download the latest build of ControllerBuddy for Windows as a ZIP archive.
3. Extract the ControllerBuddy directory from the archive to any desired location on your hard-drive.
4. Run ControllerBuddy.exe inside the extracted ControllerBuddy directory.

🐧 Linux x86-64 / aarch64

1. Allow access to uinput:

   echo 'KERNEL=="uinput", SUBSYSTEM=="misc", TAG+="uaccess", OPTIONS+="static_node=uinput"' | sudo tee /etc/udev/rules.d/60-controllerbuddy.rules


2. Load the uinput kernel module at boot:

   echo uinput | sudo tee /etc/modules-load.d/controllerbuddy.conf


3. Reboot
4. Click here and download the latest build of ControllerBuddy for Linux as a TGZ archive.
5. Extract the ControllerBuddy directory from the archive to any desired location on your hard-drive.
6. Run ControllerBuddy inside the extracted ControllerBuddy/bin directory.

✨ Features

• Map gamepad axes and buttons to highly customizable Actions:
  • Virtual joystick axis movements (absolute and relative)
  • Virtual joystick button presses
  • Keyboard inputs
  • Mouse inputs
  • Cycles of Actions
  • Mode switching
  • etc.
• Powerful user interface:
  • Allows the creation of mapping profiles
  • Configuration of settings
  • Support for light and dark UI themes
• In-game overlay:
  • Displays currently active Mode
  • Can show current position of virtual axes
  • On-Screen-Keyboard that can be controlled by gamepad
  • Customizable position and colors
• Two modes of operation:
  • Local
  • Client-Server (experimental! use only in trusted networks!)
• Supported gamepads:
  • Xbox 360 Controller
  • Xbox One Controller
  • Xbox Series X|S Controller
  • Dual Shock 3
  • Dual Shock 4
  • Dual Sense
  • etc. (to check if your controller is supported please refer to the SDL_GameControllerDB project)
• Supported operating systems:
  • Windows / Linux (local / client / server)
  • macOS (server only - no binaries provided!)
• Language support for:
  • English
  • German

🗃️ Profiles

🧩 Definitions

**Profiles ** are JSON-based configuration files that tailor ControllerBuddy to specific games. Once loaded, they can be edited and saved through the built-in interface.

To manage complex setups, Profiles organize your input mappings into **Modes **. Think of Modes as different layers or "shift-states" for your controller.

Within each Mode, you can map an axis or button to one or more Actions.
By assigning different Actions to the same control across multiple Modes, you enable ControllerBuddy to instantly remap your controller as you switch between layers.

[!TIP] The ControllerBuddy-Profiles repository contains a vast collection of official profiles for many different flight simulators.

🗺️ Structure

The general structure of a Profile looks as follows:

flowchart LR
    Profile[("Profile (.json file)")] ---- DefaultMode
    Profile --- BButton(B Button) & XButton(X Button)
    BButton --> BButtonModeAction[/Mode Action/] -. switch to .-> ModeA
    XButton --> XButtonModeAction[/Mode Action/] -. switch to .-> ModeB
    subgraph DefaultMode[Default Mode]
        direction LR
        DefaultModeXAxis(X Axis) --> DefaultModeXAxisAction1[/Action 1/] & DefaultModeXAxisAction2[/Action 2/]
        DefaultModeYAxis(Y Axis) --> DefaultModeYAxisAction[/Action/]
        DefaultModeAButton(A Button) --> DefaultModeAButtonAction1[/Action 1/] & DefaultModeAButtonAction2[/Action 2/]
        DefaultModeYButton(Y Button) --> CycleAction[/Cycle Action/] -. perform next .-> CycleActions
        DefaultModeXAxis ~~~ CycleAction
        DefaultModeYAxis ~~~ CycleAction
        DefaultModeAButton ~~~ CycleAction
        DefaultModeYButton ~~~ CycleAction
        subgraph CycleActions[Cycle]
            CycleAction1[/Action 1/] --> CycleAction2[/Action 2/] --> CycleAction3[/Action 3/] --> CycleAction1
        end
    end
    subgraph ModeA[Mode A]
        direction LR
        ModeAXAxis(X Axis) --> ModeAXAxisAction[/Action/]
        ModeAAButton(A Button) --> ModeAAButtonAction[/Action/]
    end
    subgraph ModeB[Mode B]
        direction LR
        ModeBXAxis(X Axis) --> ModeBXAxisAction1[/Action 1/] & ModeBXAxisAction2[/Action 2/]
    end
    style DefaultModeXAxis fill:#D5000055
    style ModeAXAxis fill:#D5000055
    style ModeBXAxis fill:#D5000055
    style DefaultModeAButton fill:#FFD60055
    style ModeAAButton fill:#FFD60055
    style DefaultModeYAxis fill:#2962FF55
    style BButton fill:#AA00FF55
    style XButton fill:#FF6D0055
    style DefaultModeYButton fill:#00C85355

⛓️ Mode Inheritance

When switching between Modes, any axes or buttons not explicitly redefined will inherit their behavior from the previously active Mode. This inheritance persists across multiple Mode levels, as illustrated by the following example:

Default Mode (Base) → Mode A (Layer 1) → Mode B (Layer 2)
If an axis or button is not mapped in Mode B, ControllerBuddy checks Mode A, and finally the Default Mode.

🔀 Switching Behaviors

Two different switching behaviors can be configured:

• Momentary (Default): The Mode remains active only while the button is held (similar to a Shift key).
• Toggle: Press once to activate, press again to deactivate (similar to Caps Lock).

🏛️ Architecture

🏠 Local Mode

flowchart
    subgraph Local[Local]
        PhysicalController[Physical Controller] --> ControllerBuddy[ControllerBuddy] --> VJoy[vJoy + Win32 / uinput] --> TargetApplication[Target Application]
    end

🌐 Client-Server Mode

flowchart LR
    subgraph Server[Server]
        PhysicalController[Physical Controller] --> ControllerBuddyServer[ControllerBuddy]
    end
    ControllerBuddyServer -. UDP .-> ControllerBuddyClient
    subgraph Client[Client]
        ControllerBuddyClient[ControllerBuddy] --> VJoy[vJoy + Win32 / uinput] --> TargetApplication[Target Application]
    end

🖼️ Screenshots

⌨️ Command Line Parameters

| Parameter | Arguments | Description | Available for scripting | |---------------------|-------------------------|------------------------------------------------------------------------------------------------------------|:-----------------------:| | ‑autostart | local / client / server | starts the specified mode of operation after launch | yes | | ‑export | file destination | exports a visualization of the current profile to the specified path | yes | | ‑gamecontrollerdb | file source | adds the SDL controller mappings from the specified file | yes | | ‑help | | prints the help and exits | no | | -host | hostname / IP address | sets the host address for outgoing network connections | yes | | -password | password | sets the password for all network connections | yes | | -port | port number | sets the server port for all network connections | ye
