omill

An LLVM pass library for lowering remill-lifted IR to recompilable native code. Targets Windows x64 (PE) binaries using the Win64 ABI.

Overview

omill transforms remill's semantics-preserving lifted IR — which operates on an explicit State struct and memory intrinsics — into clean, native LLVM IR suitable for recompilation. The pipeline progressively:

Lowers remill intrinsics (flags, memory, atomics, hyper calls) to native LLVM operations
Optimizes State access — dead store/flag elimination, promotes State fields to SSA, eliminates memory pointers
Recovers control flow — lowers __remill_function_call, __remill_function_return, __remill_jump to native branches/calls, then recovers the CFG
Resolves dispatch targets — folds program counters, resolves IAT calls, iteratively resolves indirect branches via constant folding
Recovers ABI — calling convention analysis, stack frame recovery, function signature recovery, State struct elimination
Deobfuscation (optional) — constant memory folding, stack data outlining, import hash resolution, lazy import resolution, dead path elimination

Limitations

Platform Support: Currently only supports Windows x64 (PE) files using the Win64 ABI.
Project Scope: omill is optimized for deobfuscating complicated functions with relatively simple control flow.
Not Recommended For:
- Full binary lifting or recompilation (focuses on specific functions and their reachable targets).
- Virtualized code (VM-based obfuscation like VMProtect or Themida).
- Packed or compressed files (binaries must be unpacked or in a state where code is statically accessible).
Status: Deobfuscation capabilities are improving weekly, with expanding support for more complex obfuscation methods.

Requirements

LLVM 21 (tested with prebuilt install at C:/Program Files/LLVM21)
CMake >= 3.21
Ninja (recommended generator)
C++17 compiler (Clang 21)

Building

Base build (no remill)

cmake -B build -G Ninja \
  -DLLVM_DIR="C:/Program Files/LLVM21/lib/cmake/llvm" \
  -DOMILL_ENABLE_TOOLS=ON \
  -DOMILL_ENABLE_TESTING=ON

cmake --build build

With remill (enables e2e tests)

First, build remill's dependencies:

cmake -G Ninja \
  -S third_party/remill/dependencies \
  -B third_party/remill/dependencies/build \
  -DUSE_EXTERNAL_LLVM=ON

cmake --build third_party/remill/dependencies/build

Then build omill with remill enabled:

cmake -B build-remill -G Ninja \
  -DLLVM_DIR="C:/Program Files/LLVM21/lib/cmake/llvm" \
  -DOMILL_ENABLE_TOOLS=ON \
  -DOMILL_ENABLE_TESTING=ON \
  -DOMILL_ENABLE_REMILL=ON \
  -DCMAKE_PREFIX_PATH="$(pwd)/third_party/remill/dependencies/install"

cmake --build build-remill

CMake options

Usage

As a library

#include "omill/Omill.h"

llvm::ModulePassManager MPM;
omill::PipelineOptions opts;
opts.lower_intrinsics = true;
opts.optimize_state = true;
opts.lower_control_flow = true;
opts.recover_abi = true;
opts.resolve_indirect_targets = true;

omill::buildPipeline(MPM, opts);

llvm::ModuleAnalysisManager MAM;
llvm::FunctionAnalysisManager FAM;
// ... register standard + omill analyses ...
omill::registerAnalyses(FAM);
omill::registerModuleAnalyses(MAM);

MPM.run(*Module, MAM);

omill-opt CLI

omill-opt is a standalone tool for running the pipeline on bitcode files:

omill-opt input.bc -o output.bc
omill-opt input.bc -o output.bc --deobfuscate --resolve-targets --recover-abi

ollvm-obf CLI

ollvm-obf applies OLLVM-style obfuscation to LLVM bitcode, useful for generating test inputs for the deobfuscation pipeline:

ollvm-obf input.bc -o output.bc --flatten --substitute --string-encrypt --const-unfold --vectorize --seed=2976579765

Supported transforms: control flow flattening, instruction substitution, string encryption, constant unfolding, and i32 vectorization (SSE2). Vectorization supports stack-data mutation (--vectorize-data, default on) and optional bitwise add/sub lowering (--vectorize-bitwise). All transforms are deterministic by default via a stable base seed (--seed).

omill-lift CLI (requires remill)

omill-lift lifts functions starting from a specific virtual address (VA) in a Windows x64 PE file to LLVM IR, then runs the omill pipeline:

omill-lift input.exe --va 0x140001000 -o lifted.ll --deobfuscate --resolve-targets

Available options:

--va <hex>: Start address for lifting (required).
--deobfuscate: Enable deobfuscation passes (MBA simplification, dead path elimination, etc.).
--resolve-targets: Enable iterative indirect branch resolution via Z3/SCEV.
--refine-signatures: Enable parameter type refinement after ABI recovery.
--no-abi: Skip ABI recovery (keep State struct and remill intrinsics).
--event-jsonl <path|->: Emit structured lifecycle events as JSONL.
--event-detail <basic|detailed>: Control event granularity for --event-jsonl.

omill-lift-ui (Qt desktop UI)

omill-lift-ui is a Windows x64 desktop frontend for omill-lift that runs jobs via subprocesses, ingests --event-jsonl streams, and provides queue/session controls (start, cancel, retry, duplicate, reorder, enable/disable), phase timeline, logs, and artifact tracking.

If Qt6 is missing, CMake can auto-fetch prebuilt Qt via aqt:

-DOMILL_AUTO_FETCH_QT=ON (default)
-DOMILL_QT_VERSION=6.8.2
-DOMILL_QT_ARCH=win64_msvc2022_64
-DOMILL_QT_MODULES= (optional extra modules, semicolon-separated)

Architecture

Pass pipeline

The pipeline is organized into stages that progressively lower remill IR:

Consolidated passes

The pipeline uses 4 bitmask-configurable passes that each consolidate multiple related transformations, reducing IR traversal overhead:

LowerRemillIntrinsicsPass — 11 intrinsic categories (flags, barriers, memory, atomics, hyper calls, error/missing, return, call, jump, undefined, resolved dispatch) selected via LowerCategories bitmask
OptimizeStatePass — 5 state optimization phases (dead flags, dead stores, redundant bytes, promote-to-SSA, roundtrip elimination) selected via OptimizePhases bitmask
ResolveAndLowerControlFlowPass — 3 resolution phases (constant-PC dispatch, jump table recovery, symbolic/SCEV solving) selected via ResolvePhases bitmask
SimplifyVectorReassemblyPass — 4 XMM pattern matchers (constant vector folding, partial write collapse, byte reassembly coalescing, flag computation simplification)

Analyses

RemillIntrinsicAnalysis — identifies and classifies remill intrinsic calls
StateFieldAccessAnalysis — tracks which State struct fields are read/written
CallGraphAnalysis — builds inter-procedural call graph with SCC computation
CallingConventionAnalysis — determines Win64 calling conventions from register usage (XMM0-3 param detection, callee-saved GPR filtering)
BinaryMemoryMap — provides constant memory contents from the original binary for folding
LiftedFunctionMap — maps program counter addresses to lifted sub_<hex> functions
ExceptionInfo — recovers structured exception handling metadata

Project structure

omill/
├── include/omill/          # Public headers
│   ├── Analysis/           # Analysis passes
│   ├── Passes/             # Transformation passes
│   └── Omill.h             # Pipeline builder API
├── lib/                    # Implementation
│   ├── Analysis/
│   ├── Passes/
│   └── Pipeline.cpp        # Pipeline construction
├── tools/
│   ├── omill-opt/          # Standalone optimizer tool
│   ├── omill-lift/         # Lifter tool (requires remill)
│   └── ollvm-obf/          # OLLVM-style obfuscation tool
├── tests/
│   ├── unit/               # Unit tests (266 tests)
│   └── e2e/                # End-to-end tests (require remill)
├── test_obf/               # Obfuscation round-trip test suite
├── third_party/
│   └── remill/             # Remill submodule (binsnake fork)
└── cmake/
    └── options.cmake       # Build options

Testing

# Run all tests
ctest --test-dir build

# Run unit tests only
ctest --test-dir build -R unit

# Run e2e
