Overview

High-performance Erlang client for the Redis key-value store.

hierdis presents a simple API similar to the synchronous API exposed by the well-known hiredis C client. This is done by exposing hiredis C client functionality to Erlang through the NIF interface.

Using this approach also allows hierdis to communicate with Redis via unix domain sockets, which by itself can provide a 50% increase in throughput over TCP.

Installation

Pre-requisites: You must already have Erlang R15B01 or later installed on your machine.

$ git clone git@github.com:nathanaschbacher/hierdis.git .
$ cd hierdis
$ ./rebar compile

This should automatically build the hiredis dependencies and move the headers and libraries to the priv/ directory.

Performance Comparison

On a MacBook Air equipped with a dual-core 2.0Ghz Core i7 CPU hierdis achieves over 3x the throughput and sees 5x lower latency compared to eredis using 1 byte values. When increasing the size of the stored values to 10 kb the performance of hierdis remained basically constant, and eredis performance cut in half.

hierdis (~40k ops/sec, ~0.06ms Avg. GET and PUT)

eredis (~12.5k ops/sec, ~0.30ms Avg. GET and PUT)

Tests were performed using basho_bench with identical configurations for both hierdis and eredis. Except for utilizing their respective basho_bench drivers. The GET/PUT balance was even, and the concurrency was set to 4 to match the number of logical cores on the CPU.

redis-server was flushed and restarted before each test run, and disk-persistence was disabled for each run as well.

The respective configurations and complete results can be found here hierdis_vs_eredis.zip

Usage

#####Get a Redis connection.

$ erl -pa ebin/

Eshell V5.9.1  (abort with ^G)
1> {ok,C} = hierdis:connect_unix("/tmp/redis.sock").
{ok,<<>>}

#####Issue single commands to Redis as an iolist.

2> hierdis:command(C, ["SET", "foo", "bar"]).
{ok,<<"OK">>}
3> hierdis:command(C, ["GET", "foo"]).
{ok,<<"bar">>}
4> hierdis:command(C, ["MSET" | ["key1", "1", "key2", "2", "key3", "3"]]).
{ok,<<"OK">>}
5> hierdis:command(C, ["GET", "key1"]).
{ok,<<"1">>}
6> hierdis:command(C, ["GET", "key3"]).
{ok,<<"3">>}
7> hierdis:command(C, ["MGET" | ["key1", "key2", "key3"]]).
{ok,[<<"1">>,<<"2">>,<<"3">>]}

#####Pipeline commands to Redis as a list of iolists.

8> hierdis:pipeline(C, [
8>     ["SET", "foo", "bar"],
8>     ["GET", "foo"],
8>     ["MSET" | ["key1", "1", "key2", "2", "key3", "3"]],
8>     ["GET", "key1"],
8>     ["GET", "key3"],
8>     ["MGET" | ["key1", "key2", "key3"]]
8> ]).
[{ok,<<"OK">>},
 {ok,<<"bar">>},
 {ok,<<"OK">>},
 {ok,<<"1">>},
 {ok,<<"3">>},
 {ok,[<<"1">>,<<"2">>,<<"3">>]}]

#####Execute a transaction pipeline against Redis as a list of iolists.

9> hierdis:transaction(C, [
9>     ["SET", "foo", "bar"],
9>     ["GET", "foo"],
9>     ["MSET" | ["key1", "1", "key2", "2", "key3", "3"]],
9>     ["MGET" | ["key1", "key2", "key3"]]
9> ]).
{ok,[<<"OK">>,<<"bar">>,<<"OK">>,[<<"1">>,<<"2">>,<<"3">>]]}
10> hierdis:transaction(C, [
10>     ["SET", "foo", "bar"],
10>     ["GET", "foo"],
10>     ["CRASHER!" | ["ka", "blooey"]],
10>     ["MGET" | ["key1", "key2", "key3"]]
10> ]).
{error,{redis_reply_error,"EXECABORT Transaction discarded because of previous errors."}}

#####Manually append commands and get replies.

11> hierdis:append_command(C, ["MULTI"]).
{ok,15}
12> hierdis:append_command(C, ["SET", "foo", "pipelined"]).
{ok,52}
13> hierdis:append_command(C, ["SET", "bar", "linedpipe"]).
{ok,89}
14> hierdis:append_command(C, ["EXEC"]).
{ok,183}
15> hierdis:get_reply(C).
{ok,<<"OK">>}
16> hierdis:get_reply(C).
{ok,<<"QUEUED">>}
17> hierdis:get_reply(C).
{ok,<<"QUEUED">>}
18> hierdis:get_reply(C).
{ok,[<<"OK">>,<<"OK">>,<<"OK">>,
     [<<"pipelined">>,<<"linedpipe">>,<<"ploplooned">>]]}

#Simple. Right?

License

(The MIT License)

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the 'Software'), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED 'AS IS', WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
