An easy ATT&CK-based Sysmon hunting tool

Requirements

1. Elasticsearch

2. Neo4j

3. Python 2.7.x

4. 3rd party python library dependency

   pip install -r requirements.txt

Configuration

See conf/example.conf

es_host=http://localhost:9200			# Elasticsearch host uri
winlogbeat_index=winlogbeat-*			# winlogbeat index prefix
neo4j_host=bolt://localhost:7687		# Neo4j database host
neo4j_user=neo4j							# Neo4j login username
neo4j_pwd=								# Neo4j login password
attck_yaml=misc/attck.yaml				# rules file

Usage

Data process & import

Processing Sysmon logs to customized structured data, filtering abnormal behaviors based on YAML rules, then import to databases.

Sysmon logs supports two ways to collect.

• manully, using logparser transfer .evtx to csv.

    logparser.exe -i:evt -o:csv "select TimeGenerated, SourceName, ComputerName, SID, EventID, Strings from Microsoft-Windows-Sysmon%4Operational.evtx


• with winlogbeat collect to elasticsearch.

Usage for agent.py:

For examples:

python agent.py -c conf/example.conf -t csv -i test/empire.csv
python agent.py -c conf/example.conf -t winlogbeat -start 2019-07-19 -end 2019-07-19

SysmonHunter tool

Execute command below and open http://localhost:5000/ in browser.

python server.py -c conf/example.conf

Conclusion

More details include in the pptx under docs.
