DISTEVAL: Protein distance evaluation

Project abstract

Background: Protein inter-residue contact and distance prediction are two key intermediate steps essential to accurate protein structure prediction. Distance prediction comes in two forms: real-valued distances and 'binned' distograms, which are a more finely grained variant of the binary contact prediction problem. The latter has been introduced as a new challenge in the 14<sup>th</sup> Critical Assessment of Techniques for Protein Structure Prediction (CASP14) 2020 experiment. Despite the recent proliferation of methods for predicting distances, few methods exist for evaluating these predictions. Currently only numerical metrics, which evaluate the entire prediction at once, are used. These give no insight into the structural details of a prediction. For this reason, new methods and tools are needed.
Results: We have developed a web server for evaluating predicted inter-residue distances. Our server, DISTEVAL, accepts predicted contacts, distances, and a true structure as optional inputs to generate informative heatmaps, chord diagrams, and 3D models. All of these outputs facilitate visual and qualitative assessment. The server also evaluates predictions using other metrics such as mean absolute error, root mean squared error, and contact precision.
Conclusions: The visualizations generated by DISTEVAL complement each other and collectively serve as a powerful tool for both quantitative and qualitative assessments of predicted contacts and distances, even in the absence of a true 3D structure.

Webserver

http://deep.cs.umsl.edu/disteval/

Distance/contact evaluation using `disteval.py`

Download

Download from https://github.com/ba-lab/disteval/releases

Prerequisites

[x] Python3
[x] Numpy
[x] Scikit-learn

Test

Example 0. See help

python3 ./disteval.py -h

Example 1. Evaluate a predicted RR contacts file

python3 ./disteval.py -n ./test/1guuA.pdb -c ./test/1guuA.contact.rr

Expected output:

Evaluating contacts..
min-seq-sep: 12 xL: Top-L/5 {'precision': 1.0, 'count': 9}
min-seq-sep: 12 xL: Top-L   {'precision': 1.0, 'count': 9}
min-seq-sep: 12 xL: Top-NC  {'precision': 1.0, 'count': 9}
min-seq-sep: 24 xL: Top-L/5 {'precision': 1.0, 'count': 1}
min-seq-sep: 24 xL: Top-L   {'precision': 1.0, 'count': 1}
min-seq-sep: 24 xL: Top-NC  {'precision': 1.0, 'count': 1}

Example 2. Evaluate a predicted distance map

python3 ./disteval.py -n ./test/1guuA.pdb -d ./test/1guuA.predicted.npy

Expected output:

Evaluating distances..
min-seq-sep: 12 xL: Top-L/5 {'mae': 0.9403, 'mse': 1.5143, 'rmse': 1.2306, 'count': 10}
min-seq-sep: 12 xL: Top-L   {'mae': 1.7522, 'mse': 5.6841, 'rmse': 2.3841, 'count': 50}
min-seq-sep: 12 xL: Top-NC  {'mae': 1.9263, 'mse': 6.6872, 'rmse': 2.586, 'count': 603}
min-seq-sep: 24 xL: Top-L/5 {'mae': 1.8154, 'mse': 4.6469, 'rmse': 2.1557, 'count': 10}
min-seq-sep: 24 xL: Top-L   {'mae': 2.1541, 'mse': 8.1816, 'rmse': 2.8603, 'count': 50}
min-seq-sep: 24 xL: Top-NC  {'mae': 2.4536, 'mse': 9.6231, 'rmse': 3.1021, 'count': 295}
Evaluating contacts..
min-seq-sep: 12 xL: Top-L/5 {'precision': 0.9, 'count': 10}
min-seq-sep: 12 xL: Top-L   {'precision': 0.6, 'count': 30}
min-seq-sep: 12 xL: Top-NC  {'precision': 0.6, 'count': 30}
min-seq-sep: 24 xL: Top-L/5 {'precision': 0.5, 'count': 10}
min-seq-sep: 24 xL: Top-L   {'precision': 0.38462, 'count': 13}
min-seq-sep: 24 xL: Top-NC  {'precision': 0.38462, 'count': 13}

Example 3. Evaluate trRosetta prediction

python3 ./disteval.py -n ./test/1guuA.pdb -r ./test/1guuA.npz

Expected output:

Evaluating distances..
min-seq-sep: 12 xL: Top-L/5 {'mae': 0.5485, 'mse': 0.5375, 'rmse': 0.7331, 'count': 10}
min-seq-sep: 12 xL: Top-L   {'mae': 0.6789, 'mse': 0.7678, 'rmse': 0.8762, 'count': 50}
min-seq-sep: 12 xL: Top-NC  {'mae': 1.2951, 'mse': 3.8733, 'rmse': 1.9681, 'count': 741}
min-seq-sep: 24 xL: Top-L/5 {'mae': 0.537, 'mse': 0.4237, 'rmse': 0.6509, 'count': 10}
min-seq-sep: 24 xL: Top-L   {'mae': 0.6691, 'mse': 0.6725, 'rmse': 0.8201, 'count': 50}
min-seq-sep: 24 xL: Top-NC  {'mae': 1.2281, 'mse': 3.2863, 'rmse': 1.8128, 'count': 351}

Evaluating contacts..
min-seq-sep: 12 xL: Top-L/5 {'precision': 1.0, 'count': 10}
min-seq-sep: 12 xL: Top-L   {'precision': 0.8, 'count': 30}
min-seq-sep: 12 xL: Top-NC  {'precision': 0.8, 'count': 30}
min-seq-sep: 24 xL: Top-L/5 {'precision': 1.0, 'count': 10}
min-seq-sep: 24 xL: Top-L   {'precision': 0.84615, 'count': 13}
min-seq-sep: 24 xL: Top-NC  {'precision': 0.84615, 'count': 13}

Example 4. Evaluate a CASP14 RR file

wget http://deep.cs.umsl.edu/disteval/static/data/casp14/T1024/RaptorX_RR1
wget http://deep.cs.umsl.edu/disteval/static/data/casp14/casp14_pdbs/T1024.pdb
python3 ./disteval.py -n ./T1024.pdb -c ./RaptorX_RR1

Expected output:

Evaluating distances..
min-seq-sep: 12 xL: Top-L/5 {'mae': 1.7837, 'mse': 4.9053, 'rmse': 2.2148, 'count': 78}
min-seq-sep: 12 xL: Top-L   {'mae': 2.4797, 'mse': 13.0069, 'rmse': 3.6065, 'count': 392}
min-seq-sep: 12 xL: Top-NC  {'mae': 3.6061, 'mse': 16.4059, 'rmse': 4.0504, 'count': 5459}
min-seq-sep: 24 xL: Top-L/5 {'mae': 1.7837, 'mse': 4.9053, 'rmse': 2.2148, 'count': 78}
min-seq-sep: 24 xL: Top-L   {'mae': 2.4398, 'mse': 12.8404, 'rmse': 3.5834, 'count': 392}
min-seq-sep: 24 xL: Top-NC  {'mae': 3.6114, 'mse': 16.4634, 'rmse': 4.0575, 'count': 4906}
Evaluating contacts..
min-seq-sep: 12 xL: Top-L/5 {'precision': 0.9359, 'count': 78}
min-seq-sep: 12 xL: Top-L   {'precision': 0.82143, 'count': 392}
min-seq-sep: 12 xL: Top-NC  {'precision': 0.68562, 'count': 633}
min-seq-sep: 24 xL: Top-L/5 {'precision': 0.9359, 'count': 78}
min-seq-sep: 24 xL: Top-L   {'precision': 0.80357, 'count': 392}
min-seq-sep: 24 xL: Top-NC  {'precision': 0.68631, 'count': 577}

Evaluation through 3D modeling using `disteval.py`

Prerequisites

[x] Install csh
```
sudo apt install csh
```
[x] Download 'dssp-2.0.4-linux-amd64' from https://osf.io/qydjv/
```
chmod +x dssp-2.0.4-linux-amd64
```

[x] Download TM-score from https://zhanglab.ccmb.med.umich.edu/TM-score/TMscore.gz

wget https://zhanglab.ccmb.med.umich.edu/TM-score/TMscore.gz
gunzip TMscore.gz
chmod +x TMscore

[x] DISTFOLD
- Follow instructions here to download DISTFOLD, an updated version of CONFOLD.

Test

Example 1. Predicted contacts (RR file) & Secondary structure

python3 disteval.py -f ./test/1guuA.fasta -n ./test/1guuA.pdb -c ./test/1guuA.contact.rr -s ./test/1guuA.ss -o ./build-1guuA  -b

Expected output:

TM-score RMSD    GDT-TS MODEL
0.297    10.100  0.385  1guuA_11.pdb
0.320     7.729  0.460  1guuA_8.pdb
...
0.465     3.935  0.630  1guuA_model1.pdb
0.483     5.776  0.600  1guuA_model2.pdb
0.550     4.534  0.665  1guuA_5.pdb

Example 2. Predicted distance map (up to 12Å) without local distances & Secondary structure

python3 disteval.py -f ./test/1guuA.fasta -n ./test/1guuA.pdb -d ./test/1guuA.predicted.npy -s ./test/1guuA.ss -o ./build-1guuA -b -m 6 -t 12

Expected output:

TM-score RMSD    GDT-TS MODEL
0.107    37.610  0.155  extended.pdb
0.630     3.016  0.745  1guuA_11.pdb
...
0.681     2.528  0.785  1guuA_6.pdb
0.681     2.489  0.790  1guuA_9.pdb

Example 3. Predicted distance map (up to 12Å) including local distances

python3 disteval.py -f ./test/1guuA.fasta -n ./test/1guuA.pdb -d ./test/1guuA.predicted.npy -s ./test/1guuA.ss -o ./build-1guuA -b -m 2 -t 12

Expected output:

TM-score RMSD    GDT-TS MODEL
0.107    37.610  0.155  extended.pdb
0.253    10.230  0.340  1guuA_11.pdb
...
0.681     3.349  0.775  1guuA_13.pdb
0.684     2.330  0.795  1guuA_3.pdb

Example 4. Reconstruction using a native (true) distance map

python3 disteval.py -f ./test/1guuA.fasta -n ./test/1guuA.pdb -o ./build-1guuA -p -b -m 2 -t 18

Expected output:

TM-score RMSD    GDT-TS MODEL
0.107    37.610  0.155  extended.pdb
...
0.987     0.265  1.000  1guuA_model2.pdb
0.991     0.214  1.000  1guuA_16.pdb

Example 5. Distances predicted by trRosetta method

python3 disteval.py -f ./test/1guuA.fasta -n ./test/1guuA.pdb -r ./test/1guuA.npz -o ./build-1guuA -b -m 2 -t 12

Expected output:

TM-score RMSD    GDT-TS MODEL
0.107    37.610  0.155  extended.pdb
0.268     9.724  0.375  1guuA_14.pdb
...
0.876     0.979  0.940  1guuA_model1.pdb
0.880     1.151  0.950  1guuA_16.pdb

Paper

2021, "DISTEVAL: a web server for evaluating predicted protein distances", BMC Bioinformatics
