DevOpsMetrics

A tool to measure software delivery performance by calculating the four DORA Metrics

Install on kubernetes

1. fill missing values in values.yaml
2. run helm upgrade --install devopsmetrics ./deployment/devopsmetrics/ --values ./deployment/devopsmetrics/values.yaml

chart includes influxDB instance + grafana dashboard

configuration

In default Configuration the API will be exposed: <host>:30303/api

Swagger Documentation: <host>:30303/swagger

Grafana instance: <host>:30304

import grafana dashboard

1. Open Grafana UI <host>:30304
2. Login with admin as username and password
3. change credentials if needed
4. select Create (+) > import
5. put id 16645 in the "import from grafana.com" field OR import via JSON
6. click load
7. as datasource select "InfluxDB"

You should now see the Dashboard without data.

Setup on GitHub

Create Personal access token

optional if the Repository is public and on the regular GitHub server

1. Go to your account settings > Developer settings > Personal acess tokens > Generate new token
2. Expiration should be no expiration or a new token has to be created regularly
3. repo scope should be selected

Create Webhook

1. Go to the page of the repository that should be tracked
2. Go to Settings > Webhooks > Add webhook
3. For Payload URL paste: https://<your_host>/api/github-hook/
4. For content type select application/json
5. For Secret paste your API_KEY that you set in your ENV-Vars
6. Select Let me select individual events
7. Check Deployment statuses, Issues and Pushes

Start Container

Build: docker build . -t justusernst/devopsmetrics

Run: docker run --name devopsmetrics --env-file <your_env_file> -p <PORT>:8080 -d justus-e/devopsmetrics

Environment Variables

| var | description | example | |:------------------|:------------------------------------------------------------------------------------------------------------------------------------|:-----------------------------| | PORT | optional - Port on which the API should be listening (default: 8080) | 8080 | | API_KEY | required - Authorization Key for this Api required to access all Endpoints | 'SoMeRand0MS3curE5trinG' | | INFLUX_URL | required - URL of the InfluxDB instance that should be used | 'http://localhost:8086' | | INFLUX_TOKEN | required - Token to access InfluxDB (can be generated in the InfluxDB UI) | 'AmfWLq5PbC_89NkpO[...]' | | INFLUX_ORG | required - Organization name of the InfluxDB instance | 'DevOpsMetrics' | | INFLUX_BUCKET | required - Name of the InfluxDB bucket where the events should be stored | 'events' | | GITHUB_URL | optional - GitHub URL of GitHub Server where the tracked Repo is stored (default: 'https://api.github.com') | 'https://api.github.com' | | GITHUB_USER | optional - Needed if Repository is private or on an Enterprise Server | 'justus-e' | | GITHUB_OAUTH | optional - Needed if Repository is private or on an Enterprise Server (can be generated in the GitHub UI) | 'ghp_bitz8n81coxxnYvZ[...]' | | TEST_MODE | optional - If set to true, the app will start in Test mode, operating on a separate randomly generated Dataset (default: false) | true |

Local Dev

Run locally: npm run dev

Api Docs: http://<your_host>/swagger

Links

Docker Image: https://hub.docker.com/r/justusernst/devopsmetrics

Grafana Dashboard: https://grafana.com/grafana/dashboards/16645
