AyresWiFiManager (AWM)

⭐ If you find this project useful, please consider giving it a star. Thank you.

Release License Issues

</div> <div align="center" style="background-color: #f0f0f0; border: 2px solid #336699; padding: 15px; border-radius: 10px;"> <table> <tr> <td style="padding: 5px;"> <img src="https://res.cloudinary.com/dxunooptp/image/upload/v1756089447/awm01_vyzkbw.png" alt="Screenshot 1" width="250"> </td> <td style="padding: 5px;"> <img src="https://res.cloudinary.com/dxunooptp/image/upload/v1756089447/awm02_mvzmxr.png" alt="Screenshot 2" width="250"> </td> <td style="padding: 5px;"> <img src="https://res.cloudinary.com/dxunooptp/image/upload/v1756093584/imagen_2025-08-25_004621649_gpiecd.png" width="250" alt="Screenshot 3"> </td> </tr> </table> </div>

📢 Now available in the Arduino IDE!

You can install AyresWiFiManager directly from the Arduino IDE Library Manager.
Just search for “AyresWiFiManager” and click “Install”.

AWM — Pro Wi‑Fi manager for ESP32/ESP8266 featuring a real captive portal (AP+DNS), modern UI served from LittleFS, secure credential storage, fallback policies, provisioning button, status LED, NTP, Internet reachability check, and configurable logging.

Project: https://github.com/AyresNet/AyresWiFiManager
License: MIT — (c) 2025 AyresNet

🇪🇸 ¿Español? Lee el README.es.md.

⭐ Why AyresWiFiManager?

Real captive portal: DNS catch‑all + OS connectivity routes (Android/iOS/Windows) to force open http://192.168.4.1.
Lightweight UI (no external deps) served from /data (LittleFS): search, rescan, signal bars, and an option to erase credentials from the portal.
Clear, cross‑platform API for ESP32/ESP8266 with explicit policies.
Smart fallbacks: NO_CREDENTIALS_ONLY (default), ON_FAIL, SMART_RETRIES, BUTTON_ONLY, NEVER.
Integrated Button & LED:
- Button (LOW): 2–5 s opens portal · ≥5 s erases JSON and restarts.
- LED: ON connected · BLINK_SLOW portal · BLINK_FAST scanning · OFF idle (+ double/triple patterns for feedback).
Safe JSON erase with whitelist, recursive on ESP32.
Professional logging (AWM_LOG* macros) with level set via build_flags.
Utilities: NTP (pool.ntp.org/time.nist.gov), hayInternet() (Google 204), RSSI, timestamp, auto‑reconnect.

🚀 Features

Credential storage at /wifi.json (LittleFS).
Portal routes
- GET / → index.html
- POST /save → stores {ssid,password} and restarts
- GET /scan or /scan.json → [{ssid,rssi,secure}]
- POST /erase → deletes .json (respects whitelist) and restarts
Example HTML/JS/CSS included: data/index.html, data/success.html, data/error.html
ESP32: esp_wifi_set_ps(WIFI_PS_NONE), LittleFS.begin(true) (auto‑format)
ESP8266: WiFi.setSleepMode(WIFI_NONE_SLEEP), non‑recursive LittleFS iteration

📦 Installation

PlatformIO (recommended)

Minimal platformio.ini:

[env:esp32dev]
platform = espressif32
board = esp32dev
framework = arduino
monitor_speed = 115200
board_build.filesystem = littlefs

; Optional: logging
build_flags =
  -D AWM_ENABLE_LOG=1     ; 0=off, 1=on
  -D AWM_LOG_LEVEL=3      ; 1=E, 2=W, 3=I, 4=D, 5=V

Place your portal files in data/ (e.g. index.html).
Upload FS: pio run -t uploadfs.
Flash the sketch and open the serial monitor.

Arduino IDE

Install the official ESP32/ESP8266 cores.
Install the appropriate LittleFS uploader (ESP32/ESP8266).
Upload the data/ folder to the FS with the “Data Upload” tool.
Build and upload the sketch.

✏️ Minimal usage

#include <AyresWiFiManager.h>

AyresWiFiManager wifi;

void setup() {
  Serial.begin(115200);

  wifi.setAPCredentials("ayreswifimanager","123456789");
  wifi.setPortalTimeout(300);   // 5 min of inactivity
  wifi.setAPClientCheck(true);  // don't close if clients connected
  wifi.setWebClientCheck(true); // each HTTP request resets the timer
  // wifi.setCaptivePortal(false); // disable redirections if you prefer

  wifi.begin();  // mounts FS, loads /wifi.json if present
  wifi.run();    // tries STA; if it fails applies the fallback policy
}

void loop() {
  wifi.update(); // serves HTTP/DNS and handles timeouts/LED
}

🪄 Recommended boot flow

The example examples/30sVentana/src/main.cpp does:

If credentials exist → opens portal with 30 s inactivity timeout; if unused, it closes and continues automatically.
If no credentials → opens a “normal” portal (e.g. 5 min inactivity timeout).
In both cases, while the portal is in use (AP clients or HTTP requests), it won’t close until usage stops.

🧩 API overview

// Portal / AP
void setHtmlPathPrefix(const String& prefix);  // e.g.: "/wifimanager"
void setHostname(const String& host);
void setAPCredentials(const String& ssid, const String& pass);
void setCaptivePortal(bool enabled);           // DNS + captive routes
void setPortalTimeout(uint32_t seconds);       // 0 = no timeout
void setAPClientCheck(bool enabled);           // keep open if clients connected
void setWebClientCheck(bool enabled);          // each request resets timer
void openPortal();
void closePortal();
bool isPortalActive() const;

// Fallback
enum class FallbackPolicy { ON_FAIL, NO_CREDENTIALS_ONLY, SMART_RETRIES, BUTTON_ONLY, NEVER };
void setFallbackPolicy(FallbackPolicy p);
void setSmartRetries(uint8_t maxRetries, uint32_t windowMs);
void enableButtonPortal(bool enable);
void setAutoReconnect(bool enabled);

// Status / utilities
bool tieneCredenciales() const;
bool connectToWiFi();
bool isConnected();
int  getSignalStrength();     // RSSI
uint64_t getTimestamp();      // ms (0 if no NTP)
bool hayInternet();           // generate_204
bool scanRedDetectada();
void forzarReconexion();

// LED
enum class LedPattern { OFF, ON, BLINK_SLOW, BLINK_FAST, BLINK_DOUBLE, BLINK_TRIPLE };
void setLedAuto(bool enable);
void setLedPatternManual(LedPattern p);

// FS safety (.json whitelist)
void setProtectedJsons(std::initializer_list<const char*> names); // e.g.: {"/wifi.json","license.json"}

🔘 Button & 💡 LED

Button (default pin 0, INPUT_PULLUP, active LOW):
- 2–5 s → open portal (if enableButtonPortal(true))
- ≥5 s → erase .json (respects setProtectedJsons) and restart
LED (default pin 2):
- ON connected to Wi‑Fi
- BLINK_SLOW portal active
- BLINK_FAST scanning
- BLINK_DOUBLE / TRIPLE feedback while holding the button
- OFF no link/portal

You can set the pattern manually (setLedPatternManual) or leave it automatic (setLedAuto(true)).

📋 Logging (optional, recommended)

Include include/AWM_Logging.h and use the macros:

AWM_LOGE("error: %d", code);   // Error
AWM_LOGW("warning...");
AWM_LOGI("info...");
AWM_LOGD("debug x=%d", x);
AWM_LOGV("verbose...");

Enable via compile flags (PlatformIO):

build_flags =
  -D AWM_ENABLE_LOG=1
  -D AWM_LOG_LEVEL=3    ; 1=ERROR, 2=WARN, 3=INFO, 4=DEBUG, 5=VERBOSE

Set AWM_ENABLE_LOG=0 to turn all logs off (no‑ops).
Raise/lower AWM_LOG_LEVEL to control verbosity.

🗂 Portal files (LittleFS)

data/index.html – scan, filter, SSID selection, save form, advanced options
data/success.html – saved confirmation (SVG with pulse; the device restarts)
data/error.html – save error (SVG with subtle shake + “Back” link)

Change the root with setHtmlPathPrefix("/wifimanager") if you prefer another folder.

Upload FS

PlatformIO: pio run -t uploadfs
Arduino IDE: “Data Upload” tool

🔁 Migrating from tzapu/WiFiManager

AyresWiFiManager aims to be simple and explicit:

No configuration auto‑magic: you decide when to open the portal and for how long.
A truly captive portal (DNS + routes), not just AP + webserver.
Modern UI without CDNs, tailored for low RAM/flash ESPs.
Safe erase of .json with whitelist and (on ESP32) recursive.
Logging with adjustable levels.

📚 Examples

examples/AWM_Minimal/AWM_Minimal.ino – min
