CUDASW++4.0: Ultra-fast GPU-based Smith-Waterman Protein Sequence Database Search

Software requirements

• Linux operating system with compatible CUDA Toolkit 12.2 or newer
• C++17 compiler
• zlib
• make

Hardware requirements

• A modern CUDA-capable GPU of generation Ampère or newer. We have tested CUDASW4 on Ampère (sm_80), Ada Lovelace (sm_89), and Hopper (sm_90). Older generations lack hardware-support for specific instructions and may run at reduced speeds or may not run at all.

Download

git clone https://github.com/asbschmidt/CUDASW4.git

Build

Our software has two components, makedb and align . makedb is used to construct a database which can be queried by align.

The build step compiles the GPU code for all GPU archictectures of GPUs detected in the system. The CUDA environment variable CUDA_VISIBLE_DEVICES can be used to control the detected GPUs. If CUDA_VISIBLE_DEVICES is not set, it will default to all GPUs in the system.

• Build makedb: make makedb

• Build align: make align

• Build align for the GPU architecture of GPUs 0 and 1: CUDA_VISIBLE_DEVICES=0,1 make align

Database construction

Use makedb to create a database from a fasta file. The file can be gzip'ed. We support fasta files with up to 2 billion sequences.

mkdir -p dbfolder
./makedb input.fa(.gz) dbfolder/dbname [options]

Options:

• --mem val : Memory limit. Can use suffix K,M,G. If makedb requires more memory, temp files in temp directory will be used. Default all available memory.
• --tempdir val : Temp directory for temporary files. Must exist. Default is db output directory.

Querying the database

Use align to query the database. align has two mandatory arguments.

1. --query The query file which contains all queries
2. --db The path to the reference database constructed with makedb.

Run ./align --help to get a complete list of options.

By default, the results will be output to stdout in plain text. Results can be output to file instead (--of filename), and can be output as tab-separated values (--tsv). Example tsv output is given below.

| Query number | Query length | Query header | Result number | Result score | Reference length | Reference header | Reference ID in DB | |------------|------------|------------|------------|------------|------------| ------------|------------| | 0 | 144 | gi|122087146 | 0 | 541 | 148 | UniRef50_P02233 | 23128215 | | 0 | 144 | gi|122087146 | 1 | 444 | 144 | UniRef50_P02238 | 22381647 |

Selecting GPUs

Similar to the build process, align will use all GPUs that are set with CUDA_VISIBLE_DEVICES, or all GPUs if CUDA_VISIBLE_DEVICES is not set.

# use the gpus that are currently set in CUDA_VISIBLE_DEVICES
./align --query queries.fa(.gz) --db dbfolder/dbname

# use gpus 0 and 1 for only this command
CUDA_VISIBLE_DEVICES=0,1 ./align --query queries.fa(.gz) --db dbfolder/dbname

Scoring options

    --top val : Output the val best scores. Default val = 10.
    --mat val : Set substitution matrix. Supported values: blosum45, blosum50, blosum62, blosum80. Default val = blosum62.
    --gop val : Gap open score. Overwrites blosum-dependent default score.
    --gex val : Gap extend score. Overwrites blosum-dependent default score.

The default gap scores are listed in the following table.

| | blosum45 | blosum50 | blosum62 | blosum80 | |------------|----------|----------|----------|----------| | gap_open | -13 | -13 | -11 | -10 | | gap_extend | -2 | -2 | -1 | -1 |

Memory options

    --maxGpuMem val : Try not to use more than val bytes of gpu memory per gpu. This is not a hard limit. Can use suffix K,M,G. All available gpu memory by default.
    --maxTempBytes val : Size of temp storage in GPU memory. Can use suffix K,M,G. Default val = 4G
    --maxBatchBytes val : Process DB in batches of at most val bytes. Can use suffix K,M,G. Default val = 128M
    --maxBatchSequences val : Process DB in batches of at most val sequences. Default val = 10000000

Depending on the database size and available total GPU memory, the database is transferred to the GPU once for all queries, or it is processed in batches which requires a transfer for each query. Above options give some control over memory usage. For best performance, the complete database must fit into maxGpuMem times the number of used GPUs.

Other options

    --dpx : Use DPX instructions. Hardware support requires Hopper (sm_90) or newer. Older GPUs fall back to software emulation.
    --verbose : More console output. Shows timings.
    --printLengthPartitions : Print number of sequences per length partition in db.
    --interactive : Loads DB, then waits for sequence input by user
    --help : Print all options

Benchmark scripts

This repository includes some of our benchmark scripts. Benchmark results are written to files. Benchmark scripts use the file allqueries.fasta . Reference sequences will be downloaded.

Peak performance benchmark

Aligns file allqueries.fasta to a simulated database with equal sequences.

./runpeakbenchmark.sh kerneltype

kerneltype 0: half2, kerneltype 1: dpx_s16, kerneltype 2: dpx_s32, kerneltype 3: float

uniprot sprot benchmark

Downloads https://ftp.expasy.org/databases/uniprot/current_release/knowledgebase/complete/uniprot_sprot.fasta.gz (88 megabyte) to folder benchmarkdbs, then constructs the corresponding DB and queries file allqueries.fasta

./runsprotbenchmark.sh kerneltype

kerneltype 0: half2, kerneltype 1: dpx

uniref50 benchmark

Downloads https://ftp.expasy.org/databases/uniprot/current_release/uniref/uniref50/uniref50.fasta.gz (12 gigabyte) to folder benchmarkdbs, then constructs the corresponding DB and queries file allqueries.fasta

./rununiref50benchmark.sh kerneltype

kerneltype 0: half2, kerneltype 1: dpx

uniprot trembl benchmark

Downloads https://ftp.expasy.org/databases/uniprot/current_release/knowledgebase/complete/uniprot_trembl.fasta.gz (57 gigabyte) to folder benchmarkdbs, then constructs the corresponding DB and queries file allqueries.fasta

./runtremblbenchmark.sh kerneltype

kerneltype 0: half2, kerneltype 1: dpx

Publication

This work is presented in the following paper.

Schmidt, B., Kallenborn, F., Chacon, A. et al. CUDASW++4.0: ultra-fast GPU-based Smith–Waterman protein sequence database search. BMC Bioinformatics 25, 342 (2024). https://doi.org/10.1186/s12859-024-05965-6
