Monocle is tooling backed by a large language model for performing natural language searches against compiled target binaries. Monocle can be provided with a binary and a search criteria (e.g., authentication code, vulnerable code, password strings, and more), and it will decompile the binary and use its in-built LLM to identify and score areas of the code that meet the criteria.

• 🔬 Binary Search: Without any prior knowledge, Monocle will support in answering binary analysis questions related to the target.
• 🤖 Natural Language and Open-Ended Questions: As Monocle is backed by an LLM queries passed to it are written in plain text.
• 🛠️ Ghidra Enabled: Monocle uses Ghidra headless to enable decompilation of compiled binaries!

⚙️ Setup

System Requirements

Monocle uses the Mistral-7B-Instruct-v0.2 model, and where possible offloads processing to your system's GPU. It is recommended to run Monocle on a machine with a minimum of 16GB of RAM and a dedicated Nvidia GPU with at least 4GB of memory. However, it can run on lower spec machines, but will be significantly slower.

Monocle has been tested on Windows 11; however, it should be compatible with Unix and other systems.

Dependencies

Monocle requires Nvidia CUDA which allows for greatly increased performance of the LLM. For this follow the below steps:

• Ensure your Nvidia drivers are up to date: https://www.nvidia.com/en-us/geforce/drivers/
• Install the appropriate dependancies from here: https://pytorch.org/get-started/locally/
• Validate CUDA is installed correctly by running the following and being returned a prompt python -c "import torch; print(torch.rand(2,3).cuda())"

Monocle requires Ghidra to be installed and accessible. Additionally, ensure that analyzeHeadless is available in your environment.

Python dependencies can be found in the requirements.txt file:

pip install -r requirements.txt

Monocle can then be installed using the ./setup.py script as below:

python -m pip insatll .

Running

To utilize Monocle, follow the instructions below:

Natural Language Search

Execute Monocle with the appropriate parameters to conduct binary search tasks.

Windows

monocle.exe --binary <path-to-binary> --find <component-to-find>

Unix

monocle --binary <path-to-binary> --find <component-to-find>

Output

As Monocle processes the functions present in the provided binary, it keeps a live tracker, sorted by the highest score, of all analyzed functions, their score between 0 and 10 (where 0 means the function does not meet the search criteria and 10 means it does), alongside an explanation of why the score was awarded. Scores of 0 do not have their explanation provided.

The format of this live display can be seen below:

                                             Authentication Code
┏━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━┳━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┓
┃ BINARY NAME ┃ FUNCTION NAME ┃ SCORE ┃ EXPLANATION                                                          ┃
┡━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━╇━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┩
│ pure-authd  │ FUN_080480c5  │ 1     │ The code contains a message asking to compile the server with a      │
│             │               │       │ specific flag to use a feature, which could be related to            │
│             │               │       │ authentication. However, there is no actual authentication code      │
│             │               │       │ visible in the provided function.                                    │
│ pure-authd  │ FUN_080480b4  │ 0     │                                                                      │
└─────────────┴───────────────┴───────┴──────────────────────────────────────────────────────────────────────┘
                                                   Monocle

Examples

Below is an example of using Monocle on the pure-authd x86 binary found here to search for authentication code.

python.exe /Monocle/monocle.py --binary "..\linux-static-binaries-master\linux-static-binaries-master\x86-i686\pure-authd" --find "authentication code"

<p align="center"> <img width=100% src="example.gif"> </a> </p>

🤖 Mistral-7B-Instruct-v0.2

Behind the scenes Monocle uses the Mistral-7B-Instruct-v0.2 model from The Mistral AI Team - see here. The Mistral-7B-Instruct-v0.2 Large Language Model (LLM) is an instruct fine-tuned version of the Mistral-7B-v0.2. More can be found on the model here!.

• 7.24B params
• Tensor type: BF16
• 32k context window (vs 8k context in v0.1)
• Rope-theta = 1e6
• No Sliding-Window Attention

🙏 Contributions

Monocle is an open-source project and welcomes contributions from the community. If you would like to contribute to Monocle, please follow these guidelines:

• Fork the repository to your own GitHub account.
• Create a new branch with a descriptive name for your contribution.
• Make your changes and test them thoroughly.
• Submit a pull request to the main repository, including a detailed description of your changes and any relevant documentation.
• Wait for feedback from the maintainers and address any comments or suggestions (if any).
• Once your changes have been reviewed and approved, they will be merged into the main repository.

⚖️ Code of Conduct

Monocle follows the Contributor Covenant Code of Conduct. Please make sure to review and adhere to this code of conduct when contributing to Monocle.

🐛 Bug Reports and Feature Requests

If you encounter a bug or have a suggestion for a new feature, please open an issue in the GitHub repository. Please provide as much detail as possible, including steps to reproduce the issue or a clear description of the proposed feature. Your feedback is valuable and will help improve Monocle for everyone.

📜 License

GNU General Public License v3.0
