<!-- # Arnika - Quantum secure VPN ![Arnika](img/ARNIKA-logo_128_2x.png) --> <div align="center"> <img src="img/ARNIKA_banner.png"> <h1> Arnika - Quantum secure VPN</h1> </div>

Arnika is a compact, lightweight external extension for Wireguard VPN, engineered to incorporate symmetric keys as Pre-Shared Keys (PSK) into Wireguard. This integration ensures the establishment of a quantum-secure VPN (safeguarding against compromise of session keys).

It gathers a 256-bit symmetric encryption key from a Key Management System (KMS) within a Quantum Key Distribution (QKD) infrastructure, shares the associated key ID with an Arnika peer, and configures an additional Pre-Shared Key (PSK) for Wireguard using the obtained key material.

Arnika offers an additional security layer for cryptography enthusiasts. It can integrate Post-Quantum Cryptography (PQC) by leveraging a PQC key provided by a system like Rosenpass. This key is then used to create an even stronger Preshared Key (PSK) for WireGuard. This PSK benefits from both PQC and QKD, offering enhanced protection against potential security threats.

Arnika integrates with WireGuard to establish quantum-resistant VPN connections, adding a significant layer of security to your communication

Arnika has been developed in scope of EU EUROQCI / QCI-CAT research program for the Use-Case HSM BACKUP USING QKD - https://qci-cat.at/hsm-backup-using-qkd

Quantum secure VPN

Arnika Encapsulation Pipe, Figure 1 <br/>Figure 1

Arnika Wireguard PSK, Figure 2 <br/>Figure 2

Wireguard + Rosenpass + Arnika

SAE (Secure Application Entity) = Wireguard + Rosenpass + Arnika

QKD and PQC to achieve quantum resistance

The approach of combining symmetric keys from Quantum Key Distribution (QKD) and/or Post-Quantum Cryptography (PQC) with WireGuard as preshared key (PSK) has been used to enhance the security to achieve a post-quantum secure VPN.

QKD | PQC key handling

The setup supports 3 operational modes, A, B, and C

  • (A) ... QKD mode
  • (B) ... PQC mode
  • (C) ... QKD+PQC hyprid mode

Regardless of the selected mode, WireGuard always receives a single 256bit (32byte) key as PSK which is used for WireGuard internal MixKeyAndHash() using HKDF.

Figure 3 shows the key path of 2 interconnected sites for the hyprid mode (C) (QKD+PQC). In this scenario, the KEY-CONTROL function serves as a control entity, responsible for obtaining a key and transferring it to the encryption function (WireGuard).

QKD | PQC functions post-quantum secure VPN, Figure 3 <br/>Figure 3

The QKD key is obtained via ETSI014 from the QKDs embedded KMS and the PQC key is obtained via API or pointer/filedescriptor from a source such as Rosenpass or an alternative/already existing PQC function/implementation.

Subsequently, the KEY-CONTROL function uses the QKD key and PQC key by using a HKDF HMAC Key Derivation Function with SHA3-256 as the hash function, to derive a single key from the two input keys (QKD, PQC). The specific derivation function, whether HKDF or an alternative, is a topic open for discussion among cryptographic experts.

Advantages

QKD/PQC operation on Layer 3 offers several notable advantages:

  • Very low keyrate -> 1key per 120seconds (Rekey-After-Time, Rekey-After-Messages)
  • PQC/QKD keys can be injected as preshared key at runtime by design
  • no change in existing WireGuard setups
  • L3 based VPN can go over any existing, affortable, foreign infrastructure over the internet
  • Rosenpass (PQC) already implemented in netbird commercial VPN service Netbird that supports mesh functionality
  • unaffected by patent "Method of integrating QKD with IPSec" (US7602919B2,CN101142779A,...)

Requirements

The Secure Application Entity consists of following components running on a secure and hardened linux system:

  • WireGuard
  • Arnika
  • Rosenpass (optional)

WireGuard

WireGuard must be installed/setup separately before Arnika can be used. For further installation instructions, refer to the WireGuard homepage.

Rosenpass

Rosenpass is optional, Arnika can run without Rosenpass / PQC, then it will run in QKD mode only. For further installation instructions, refer to the Rosenpass homepage.

golang version

Version >1.22 => golang-1.22

Limitations

[!IMPORTANT] ARNIKA is intended to supply a PSK exclusively to a local WireGuard instance.

As a result, WireGuard and ARNIKA are required to operate on the same host and kernel instance.

A race condition may occur if ARNIKA is started in development environments on the same host at exactly the same time. This is intentional and a consequence of the simple yet robust state mechanism. This will be changed in an upcoming major release and it has no impact on production and can be avoided by starting both with a random delay and using the recommended interval values.

Install golang

Ubuntu 22.04.x

apt install golang-1.22
export PATH=/usr/lib/go-1.22/bin/:$PATH

$ go version
go version go1.22.2 linux/amd64

[!CAUTION] The default golang version shipped with Ubuntu 22.04 is outdated and does not meet the requirements. Install and use golang-1.22 instead.

$ apt install golang-go
$ go version
go version go1.18.1 linux/amd64
$ make build
/home/arnika/arnika/go.mod:3: invalid go version '1.22.1': > must match format 1.23

Build binaries from source

[!NOTE] Arnika and kms (mock) can be downloaded as a compiled binary from the release page and run without the need for golang.

Following steps are required to build the binaries from source.

The binaries can be copied to the target system (matching architecture) or directory and executed. No further dependencies are required, all necessary libraries are statically linked, and the binaries are self-contained.

The configuration for Arnika is done via environment variables.

compile Arnika

git clone git@github.com:arnika-project/arnika.git
cd arnika
go mod tidy
make build

nean@qcicat01:~/arnika$ make build
Building arnika
CGO_ENABLED=0 go build -trimpath -ldflags "-w -s -extldflags=-Wl,-Bsymbolic -X 'main.Version=v0.2.0-14-gd429061' -X 'main.APPName=arnika'" -o build/arnika .
go: downloading golang.org/x/crypto v0.8.0
go: downloading golang.zx2c4.com/wireguard/wgctrl v0.0.0-20230429144221-925a1e7659e6
go: downloading golang.zx2c4.com/wireguard v0.0.0-20230325221338-052af4a8072b
go: downloading github.com/mdlayher/genetlink v1.3.2
go: downloading github.com/mdlayher/netlink v1.7.2
go: downloading golang.org/x/sys v0.7.0
go: downloading golang.org/x/net v0.9.0
go: downloading github.com/josharian/native v1.1.0
go: downloading github.com/mdlayher/socket v0.4.1
go: downloading golang.org/x/sync v0.1.0

The result is a single binary arnika located in the new created subdirecory build (build/arnika).

./build/arnika
=== Arnika Configuration ===
Arnika Mode:              AtLeastQkdRequired
Arnika Interval:          10s
Arnika ID:                9999
Arnika Listen Address:    127.0.0.1:9999
Arnika Peer Address:      127.0.0.1:9998
KMS URL:                  http://localhost:8080/api/v1/keys/CONSA
KMS HTTP Timeout:         10s
KMS Backoff Max Retries:  5
KMS Backoff Base Delay:   100ms
KMS Retry Interval:       5s
Client Certificate:       (not configured)
Private Key:              (not configured)
CA Certificate:           (not configured)
PQC key provider:        DISABLED
WireGuard Interface:      qcicat0
WireGuard Peer PublicKey: ****************=
============================
2026/01/22 18:04:40.628630 [INFO] MASTER[9999] [REQ] request QKD key from http://localhost:8080/api/v1/keys/CONSA
2026/01/22 18:04:40.629081 [INFO] ARNIKA[9999] TCP server started on 127.0.0.1:9999
2026/01/22 18:04:40.635236 [INFO] MASTER[9999] [SND] send key_id ffffffff-fe92-4fdc-bef3-c0cdc73ff774 to 127.0.0.1:9998
2026/01/22 18:04:40.636669 [INFO] MASTER[9999] [OK] PSK configured on WireGuard interface: qcicat0 for peer: ****************=
2026/01/22 18:04:43.399193 [INFO] BACKUP[9999] [RCV] received key_id ffffffff-bcec-4858-838e-623c79eabf61 from 127.0.0.1:58905
2026/01/22 18:04:43.399195 [INFO] BACKUP[9999] [REQ] request QKD key for key_id ffffffff-bcec-4858-838e-623c79eabf61 from http://localhost:8080/api/v1/keys/CONSA
2026/01/22 18:04:43.399760 [INFO] BACKUP[9999] [OK] PSK configured on WireGuard interface: qcicat0 for peer: ****************=
2026/01/22 18:04:55.399323 [INFO] BACKUP[9999] [RCV] received key_id ffffffff-8a32-4540-9b78-7d4e1afebb5f from 127.0.0.1:58927

compile QKD KMS simulator

git clone git@github.com:arnika-project/arnika.git
cd arnika/tools
go mod tidy
go build -o kms

The result is a single binary kms located in the new created subdirecory tools (tools/kms). If build without -o was used, it is recommended to rename it eg. to kms (mv tools/tools tools/kms).

[!Note] kms aka mock is designed to test Arnika, it is NOT a full featured ETSI014 Simulator.

pseudo values are used, if adoption is required please consider change the source code:

  • listening port is 8080
  • http only
  • CONSA and CONSB as SAE
  • key and key_ID
  • key size=256
  • key number=1

Start Dev Environment

Start QKD KMS Simulator

To start the simulator using Go:

go run tools/mock.go

Or, if you have already compiled the binary:

tools/kms

The QKD KMS simulator is now accessible at http://127.0.0.1:8080.

Start Arnika #1

http_proxy=http://127.0.0.1:8080 \
no_proxy=127.0.0.1 \
LISTE
