ZS-GX1 Hacks

Record of attempted hacks on the ZS-GX1 IP Camera

Confirmed working on the following camera models

ZS-GX1
Snowman SRC-001
GUUDGO GD-SC01
GUUDGO GD-SC03
GUUDGO GD-SC11
Digoo DG-W01F
YSA CIPC-GC13H
KERUI CIPC-GC15HE (read-only version)

Disclaimer - I'm not a programmer, just a hobbyist that likes poking around with things like this. You use the software here at your own risk. If your camera isn't listed as supported you may break your camera. You may even break your camera if it is listed due to a variety of firmware versions available.

A few people have asked if they can donate something, you probably have much better things to spend your money on, but if you insist you can on PayPal

I will look to put any donations towards getting some other cheap IP Cameras to hack and explore - suggestions welcome!

This is a cheap Pan Tilt IP Camera (supposedly 1080p) that for a time was available on Gearbest for around £12. I bought 2 in an attempt to hack them as the reason they are so cheap is due to them being locked to paid cloud services.

SOC - GOKE - GK7102

Sensor - SC2135 - supposedly capable of 1080p 30fps

Instructions

There's a few different varieties of firmware across various brands of cameras which means it is impossible to know which version of the hack is the best for your camera. Older firmware are more hackable because the root filesystem is mounted read/write, new firmwares need the hack applying differently because the root filesystem is mounted read-only but the /home directory is writeable.

For example
Version 3.1.1.0908 is read-write and can use zsgx1hacks-v0.4.zip
Version 3.2.8.0121 is read-only and can only use readonlyhack-v0.1.zip
If in doubt use the read-only hack as that is more likely to work across more cameras.

How to check version

If you have already configured the camera with the cloud app there should be some info within the app showing firmware version.
Using an onvif tool/app like Onvifer (Android) should give firmware version.
You should also be able to find the firmware version by logging in via telnet and excuting the command
ls /tmp | grep -F 3. or ls /tmp | head -1

Steps

Create network connection
- WiFi - setup camera via app
- Ethernet - plug in to network (doesn't need app setup)
Download hack for your camera

Older firmware - read/write

Download zip file - zsgx1hacks-v0.4.zip
Extract the contents of the zip file to a vfat/fat32 formatted microSD card
Change options in config.txt
- Option for persistent hack without SD card
  - Default - run off SD Card
  - If in doubt, run it off the SD Card
- Option to restore original state of camera without hack
- Option to silence the voices
  - This may be causing issues on some cameras so use at your own risk

Newer firmware - read-only

Download zip file - readonlyhack-v0.1.zip
Extract the contents of the zip file to a vfat/fat32 formatted microSD card

All

Insert microSD card into camera and boot
Result should be
- No communication to cloud services
- RTSP/onvif server on the IP address of the camera
- SSH server
  - R/W version - user/pass root/cxlinux
  - R-O version - user root no password
- Telnet server - user/pass root/cxlinux
- Updated busybox
- Annoying whining noise reduced (RW version only currently)
- WebUI accessible - http://IPAddress:8080/cgi-bin/webui
- FTP Server pointing to the root file system - no username or password

Achieved so far

debug_cmd.sh on an SD card enables commands to be run
Change root password to enable telnet login
Telnet/root password found cxlinux (thanks 1sttommy2guns)
Upgrade busybox
Add dropbear SSH server
RTSP server accessible - rtsp://IPADDRESS/
- user/pass admin/admin
- user/pass on a non-setup camera is sometimes admin with no password
- Different camera models may have different RTSP credentials eg dg20160404 or 12345
Block cloud services via hosts file
Some GPIO functions found (IR LEDs and IR Cut)
WebUI - http://IPAddress:8080/cgi-bin/webui
PTZ control via command line or WebUI
FTP server - no username or password
WiFi Connection without inital setup with app in cls.conf

ToDo

Figure out GPIO control for Light sensor
Change bitrate of RTSP stream
Get rid of p2pcam and use an alternative RTSP server

2019-22-05 - Update 18 (susw12)

Adds the ability to have camera connect to WiFi without needing to setup the camera using the app/software.

2018-08-05 - Update 17 (ant-thomas)

Read-only hack created to enable cameras with a newer firmware to have extra features and turn off cloud connections.
SSH server has no password. It wasn't working with a password so I enabled no password logins. Hopefully be able to get that fixed.

2018-03-30 - Update 16 (ant-thomas)

Updated sdcard zip - zsgx1hacks-v0.4.zip
config.txt file to change some options
Option for persistent or SD card install - default is SD card
Option to remove hack and restore camera to before hack

2018-03-24 - Update 15 (ant-thomas)

Updated sdcard zip - zsgx1hacks-v0.3.zip
Hack no longer requires micro SD card to be present. Once installed the micro SD card can be removed.
- If anyone wants a version that doesn't make any permanent changes to the camera let me know.
Very simple WebUI created - to be improved - using busybox httpd.
WebUI has PTZ controls - massive thanks to phaeilo.
New VOICE.tgz file with empty audio files to silence the voices on boot.
FTP Server added.

2018-03-16 - Update 14 (phaeilo)

Documented PTZ driver interface
Added additional pictures of hardware
Requesting excessively long URLs on port 80 will cause p2pcam to segfault...

2018-02-13 - Update 13 (ant-thomas)

RTSP streams with sound rtsp://ipaddress/0/av0
av0 - high res stream with sound
av1 - low res stream with sound

2017-12-03 - Update 12 (ant-thomas)

Script updates time
Removed password update sections - use cxlinux as password
Updated hosts file with more addresses to block

2017-11-26 - Update 11 (ant-thomas)

Telnet/root password found by 1sttommy2guns - cxlinux

2017-11-17 - Update 10 (ant-thomas)

Pan/Tilt works via onvif - tested on TinyCam Free on Android. Hopefully this can be exploited otherwise using a webUI or other means if it sticks to the onvif api.

2017-11-17 - Update 9

./goke_p2pcam_param --wifissid=mywifiap --wifipass=8chrpass

Also see the other options for goke_p2pcam_param by executing the following command: goke_p2pcam_param -h
goke_volume allows you to make the camera much quieter.

./goke_volume -s 0

2017-11-04 - Update 8

Observations compared to the Xiaofang camera
- Image quality is generally better than the Xiaofang camera, much sharper at distance
- FOV is not as wide as the Xiaofang camera
- An increase in bitrate would produce a decent quality stream

2017-10-22 - Update 7 - (DJWillis)

I am not saying the closed source p2pcam blob looks dodgy or anything but this did make me smile (from /home/factory_tool.sh)

   #avoid p2pcam auto format tf card!!!
   rm -f /bin/mkdosfs
   rm -f /sbin/mkdosfs

That feels like the right way to work around some awesome design considerations :).

2017-10-22 - Update 6 - (DJWillis)

Firmware can be updated from a firmware.bin file on the root of the SD card (formatted vfat). This is a JFFS2 image structured much like other generic cameras based on the GOKE SoC's and a good few better know brands.
- Suspect this will be distrbuted as one section per partition. With the kernel and uboot not normally being flashed.
- The tool used to flash the images is sdc_tool.
- https://github.com/zzerrg/gmfwtools should be usable with the right key and board ident (1003) to unpack and repack the userspace firmware into something we can flash. It may also make cross flashing userspaces possible. Right now however you may well end up with a bricked camera or at least needing serial so try at your own risk.

2017-10-22 - Update 5

IR Cut and IR LED GPIOs found and controllable
- gio -s 40 1 IR Cut - night
- gio -s 40 0 IR Cut - day
- gio -s 46 1 IR LEDs - on
- gio -s 46 0 IR LEDs - off

2017-10-22 - Update 4

SD card contents moved to SD card folder
Updated hosts file included which looks like it prevents the camera from contacting the cloud services. The app shows the camera as disconnected and I'm seeing no activity on my router. RTSP server remains active.

2017-10-22 - Update 3

RTSP server user/pass - admin/admin - Presents a 1920x1080 12fps stream on rtsp://IPADDRESS/ (no audio)
Attempted to not run p2pcam by editing out specific parts of start.sh, this resulting in the WiFi connection
