GPUtil

GPUtil is a Python module for getting the GPU status from NVIDA GPUs using nvidia-smi. GPUtil locates all GPUs on the computer, determines their availablity and returns a ordered list of available GPUs. Availablity is based upon the current memory consumption and load of each GPU. The module is written with GPU selection for Deep Learning in mind, but it is not task/library specific and it can be applied to any task, where it may be useful to identify available GPUs.

Table of Contents

Requirements
Installation
Usage
1. Main functions
2. Helper functions
Examples
License

Requirements

NVIDIA GPU with latest NVIDIA driver installed. GPUtil uses the program nvidia-smi to get the GPU status of all available NVIDIA GPUs. nvidia-smi should be installed automatically, when you install your NVIDIA driver.

Supports both Python 2.X and 3.X.

Python libraries:

subprocess (The Python Standard Library)
distutils (The Python Standard Library)
math (The Python Standard Library)
random (The Python Standard Library)
time (The Python Standard Library)
os (The Python Standard Library)
sys (The Python Standard Library)
platform (The Python Standard Library)

Tested on CUDA driver version 390.77 Python 2.7 and 3.5.

Installation

Open a terminal (Ctrl+Shift+T)
Type pip install gputil
Test the installation
1. Open a terminal in a folder other than the GPUtil folder
2. Start a python console by typing python in the terminal
3. In the newly opened python console, type:
```
import GPUtil
GPUtil.showUtilization()
```
4. Your output should look something like following, depending on your number of GPUs and their current usage:
```
 ID  GPU  MEM
--------------
  0    0%   0%
```

Old way of installation

Download or clone repository to your computer
Add GPUtil folder to ~/.bashrc
1. Open a new terminal (Press Ctrl+Alt+T)
2. Open bashrc:
```
gedit ~/.bashrc
```
3. Added your GPUtil folder to the environment variable PYTHONPATH (replace <path_to_gputil> with your folder path):
```
export PYTHONPATH="$PYTHONPATH:<path_to_gputil>"

Example:
export PYTHONPATH="$PYTHONPATH:/home/anderskm/github/gputil"
```
4. Save ~/.bashrc and close gedit
5. Restart your terminal
Test the installation
1. Open a terminal in a folder other than the GPUtil folder
2. Start a python console by typing python in the terminal
3. In the newly opened python console, type:
```
import GPUtil
GPUtil.showUtilization()
```
4. Your output should look something like following, depending on your number of GPUs and their current usage:
```
 ID  GPU  MEM
--------------
  0    0%   0%
```

Usage

To include GPUtil in your Python code, all you hve to do is included it at the beginning of your script:

import GPUtil

Once included all functions are available. The functions along with a short description of inputs, outputs and their functionality can be found in the following two sections.

Main functions

deviceIDs = GPUtil.getAvailable(order = 'first', limit = 1, maxLoad = 0.5, maxMemory = 0.5, includeNan=False, excludeID=[], excludeUUID=[])

Returns a list ids of available GPUs. Availablity is determined based on current memory usage and load. The order, maximum number of devices, their maximum load and maximum memory consumption are determined by the input arguments.

Inputs
- order - Deterimines the order in which the available GPU device ids are returned. order should be specified as one of the following strings:
  - 'first' - orders available GPU device ids by ascending id (defaut)
  - 'last' - orders available GPU device ids by descending id
  - 'random' - orders the available GPU device ids randomly
  - 'load'- orders the available GPU device ids by ascending load
  - 'memory' - orders the available GPU device ids by ascending memory usage
- limit - limits the number of GPU device ids returned to the specified number. Must be positive integer. (default = 1)
- maxLoad - Maximum current relative load for a GPU to be considered available. GPUs with a load larger than maxLoad is not returned. (default = 0.5)
- maxMemory - Maximum current relative memory usage for a GPU to be considered available. GPUs with a current memory usage larger than maxMemory is not returned. (default = 0.5)
- includeNan - True/false flag indicating whether to include GPUs where either load or memory usage is NaN (indicating usage could not be retrieved). (default = False)
- excludeID - List of IDs, which should be excluded from the list of available GPUs. See GPU class description. (default = [])
- excludeUUID - Same as excludeID except it uses the UUID. (default = [])
Outputs
- deviceIDs - list of all available GPU device ids. A GPU is considered available, if the current load and memory usage is less than maxLoad and maxMemory, respectively. The list is ordered according to order. The maximum number of returned device ids is limited by limit.

deviceID = GPUtil.getFirstAvailable(order = 'first', maxLoad=0.5, maxMemory=0.5, attempts=1, interval=900, verbose=False)

Returns the first avaiable GPU. Availablity is determined based on current memory usage and load, and the ordering is determined by the specified order. If no available GPU is found, an error is thrown. When using the default values, it is the same as getAvailable(order = 'first', limit = 1, maxLoad = 0.5, maxMemory = 0.5)

Inputs
- order - See the description for GPUtil.getAvailable(...)
- maxLoad - Maximum current relative load for a GPU to be considered available. GPUs with a load larger than maxLoad is not returned. (default = 0.5)
- maxMemory - Maximum current relative memory usage for a GPU to be considered available. GPUs with a current memory usage larger than maxMemory is not returned. (default = 0.5)
- attempts - Number of attempts the function should make before giving up finding an available GPU. (default = 1)
- interval - Interval in seconds between each attempt to find an available GPU. (default = 900 --> 15 mins)
- verbose - If True, prints the attempt number before each attempt and the GPU id if an available is found.
- includeNan - See the description for GPUtil.getAvailable(...). (default = False)
- excludeID - See the description for GPUtil.getAvailable(...). (default = [])
- excludeUUID - See the description for GPUtil.getAvailable(...). (default = [])
Outputs
- deviceID - list with 1 element containing the first available GPU device ids. A GPU is considered available, if the current load and memory usage is less than maxLoad and maxMemory, respectively. The order and limit are fixed to 'first' and 1, respectively.

GPUtil.showUtilization(all=False, attrList=None, useOldCode=False)

Prints the current status (id, memory usage, uuid load) of all GPUs

Inputs
- all - True/false flag indicating if all info on the GPUs should be shown. Overwrites attrList.
- attrList - List of lists of GPU attributes to display. See code for more information/example.
- useOldCode - True/false flag indicating if the old code to display GPU utilization should be used.
Outputs
- None

Helper functions

 class GPU

Helper class handle the attributes of each GPU. Quoted descriptions are copied from corresponding descriptions by nvidia-smi.

Attributes for each GPU
- id - "Zero based index of the GPU. Can change at each boot."
- uuid - "This value is the globally unique immutable alphanumeric identifier of the GPU. It does not correspond to any physical label on the board. Does not change across reboots."
- load - Relative GPU load. 0 to 1 (100%, full load). "Percent of time over the past sample period during which one or more kernels was executing on the GPU. The sample period may be between 1 second and 1/6 second depending on the product."
- memoryUtil - Relative memory usage from 0 to 1 (100%, full usage). "Percent of time over the past sample period during which global (device) memory was being read or written. The sample period may be between 1 second and 1/6 second depending on the product."
- memoryTotal - "Total installed GPU memory."
- memoryUsed - "Total GPU memory allocated by active contexts."
- memoryFree - "Total free GPU memory."
- driver - "The version of the installed NVIDIA display driver."
- name - "The official product name of the GPU."
- serial - This number matches the serial number physically printed on each board. It is a globally unique immutable alphanumeric value.
- display_mode - "A flag that indicates whether a physical display (e.g. monitor) is currently connected to any of the GPU's connectors. "Enabled" indicates an attached display. "Disabled" indicates otherwise."
- display_active - "A flag that indicates whether a display is initialized on the GPU's
