openLIS

A Python package that implements a Recursive-Model Index (RMI) and provides a high-level database-like interface.

Description

This package implements the Recursive-Model Index described in the paper "The Case for Learned Index Structures," Kraska et al., 2017 (pdf).

In addition to implementing the Recursive-Model Index, openLIS provides a high-level database-like interface with Select, Insert, and Delete functionality.

The Recursive-Model Index

An example of a standard index structure is a BTree, which keeps keys sorted within a tree structure and allows fast lookup of the keys. BTrees and their variants are often used by modern databases to perform fast search and are particularly efficient when searching for a range of keys.

The basic idea of the Learned Index Structures paper is to replace standard index structures (such as BTrees) with statistical learning methods (such as neural networks). Both take a key as input and output the position of the key in the data set.

The paper proposes using a Recursive-Model Index (RMI) as the statistical learning method. A general RMI would consist of several stages. We only implement two stages, as was done in the paper.

In Stage 1 a neural network is used to predict the position of the key. The predicted position is then used to choose which linear regression model to use in Stage 2. Each linear regression model in Stage 2 is called an "expert." Each expert handles only a small subset of the outputs of Stage 1. For more detail see the paper referenced above.

The output of Stage 2 is a (hopefully) improved prediction of the position of the key. Because the predicted position is typically slightly off, a binary search over nearby locations is used to find the key. The range of the binary search is determined by the known maximum error of each linear regression model.

Getting Started

You can install this package using pip:

pip install openlis

Example usage

For a basic example, see the Jupyter notebook:

openlis_example.ipynb

The notebook demonstrates generating a random data set, training the Recursive-Model Index on that data set, and using the three database functions: Select, Insert and Delete.

Usage details

Generating and loading data

The module defines a class DataSet. You can obtain a DataSet object in four ways:

1. You can generate a random dataset using

data_set = openlis.data.generate_uniform_floats(num_keys,
                                          key_range,
                                     iseed=17)

or

openlis.data.generate_normal_floats(num_keys,
                                    mean=0.0,
                                    std=1.0,
                                    iseed=17)

The former uses a uniform distribution, whereas the latter uses a normal distribution.

2. Or, first create a Numpy array of keys. Save those keys using numpy.save(). Then create a DataSet object using

data_set = openlis.data.load_keys_numpy(dir,fname)

3. Create your own DataSet from a list of keys using

data_set = DataSet(keys)

4. Finally, you may create your own DataSet from a list of keys and a list of labels using

data_set = DataSet(keys, labels)

This final method should be used with caution, because you are required to ensure that labels are the sorted positions of the keys. It is better to use option 3 above, which automatically generates the labels for you.

Notes:

• The keys are assumed to be floating point values. If you use something else (like integers), some functions might not work. A future implementation should be able to handle different data types.
• Also, a real data set would have keys paired with actual data (or pointers to the data). Here we just deal with keys, keeping in mind that we could later implement a data array in parallel with keys.

Creating the training DataSet

From the data_set created above, we must split the data into training and validation. For our problem, because we are not particularly concerned with overfitting, it typically makes sense to use 100% of the data for training, so we set validation_size=0 (the Default value).

Use the following function to create the training and validation data sets:

data_sets = li.data.create_train_validate_data_sets(data_set,
                                        validation_size=0)

The training DataSet will be stored in

data_sets.train

and the validation DataSet will be stored in

data_sets.valid

Create a Recursive-Index-Model

Once we have the training data set, we can create the Recursive-Index-Model based on the training data:

rmi = openlis.model.RMI_simple(data_sets.train,
                               hidden_layer_widths=[8,8],
                               num_experts=100)

In the above example, the Stage 1 neural network will have two hidden layers each with width=8, and Stage 2 will have 100 experts.

The number and widths of the hidden layers are set by the input parameter hidden_layer_widths. For example, to create three layers with widths 100, 50, and 10, set

hidden_layer_widths = [100,50,10]

If you want zero hidden layers (i.e. just do a linear regression with no activation), set

hidden_layer_widths = []

The number of linear regression models used in Stage 2 is set by the input parameter num_experts. For example, if you want 100 experts, set

num_experts = 100

Notes:

• The number of experts in Stage 2 must be at least 1.
• Currently not implemented is the possibility of having no Stage 2.

Create the database-like interface

Once a model is defined, we can create a database-like interface to that model using either

rmi_db = openlis.database.IndexStructurePacked(model=rmi)

or

rmi_db = openlis.database.IndexStructureGapped(model=rmi, scale=2)

The former creates an object of type IndexStructurePacked while the latter creates an object of type IndexStructureGapped.

The word "Packed" in IndexStructurePacked refers to how the keys are stored: the keys are simply stored contiguously in a Numpy array. This means that insertions and deletions will be quite slow, because the array must be resized.

The word "Gapped" in IndexStructureGapped also refers to how the keys are stored: gaps are left between keys in the Numpy array. The gaps leave room for fast key insertions and require no additional work for key deletions. The parameter scale sets the size of the "gapped" array relative to a packed array. For example, setting scale = 3 would create two gaps for every key, evenly distributed between the keys.

If using IndexStructureGapped, the fuction

rmi_db.rescale(scale=3)

can be used at any time to rescale the array.

Train the model

Training the model (to predict the positions of the keys) can be accomplished via the database interface:

rmi_db.train(batch_sizes=[10000,1000],
             max_steps=[500,500],
             learning_rates=[0.001,1000],
             model_save_dir='tf_checkpoints_example')

batch_sizes are the batch sizes for the two stages.
max_steps are the maximum number of batches for each stage.
learning_rates are the learning rates for the two stages.
model_save_dir is where to save the trained model.

Currently, the user must choose the above hyperparameters manually.

Training proceeds as follows:

• The Stage 1 model is trained with Adam optimization, using Mean Squared Error (MSE) as Loss.
• The Stage 2 model is trained with Stage 1 variables held fixed. Stage 2 also uses MSE and an Adam optimizer.

Then rmi_db.train(...) also performs the following steps:

• The maximum errors for each linear regression are calculated and stored.
• The trained variables are retrieved from the TensorFlow model and stored as Numpy arrays (for use in faster inference calculations).

If you prefer not to use the database interface, you can train the model directly with

rmi.run_training(batch_sizes=[10000,1000],
                 max_steps=[500,500],
                 learning_rates=[0.001,1000],
                 model_save_dir='tf_checkpoints_example')

Then you can calculate the linear regression errors with

rmi.calc_min_max_errors(batch_size=10000)

And then you may retrieve the trained variables from the TensorFlow model:

rmi.get_weights_from_trained_model()

Basically, rmi_db.train(...) wraps the above three functions into a single convenient function call.

Use the Database

Once we have a fully trained model with saved errors and saved weights -- for example, after we have run rmi_db.train(...) -- we are ready to use the database functionality!

Given a list or Numpy array keys, you may

• Select the keys:

  pos = rmi_db.select(keys)


  The output, pos, is a Numpy array containing the positions of the keys. By convention, pos[i] = -1 if keys[i] is not in the data set.

• Insert the keys:

  success = rmi_db.insert(keys)


  The output, success, is a boolean array that indicates whether each key insertion was a success. Insertion fails if the key is already in the data set (i.e. uniqueness of keys is enforced).

• Delete the keys:

  success = rmi_db.delete(keys)


  The output, success, is a boolean array that indicates whether each key deletion was a success. Deletion fails if the key was not in the data set.

Notes:

• Instead of a list or Numpy array of keys, you may input a single key to any of the above functions.
• When using IndexStructurePacked, submitting multiple keys at a time is significantly faster than submitting single keys repeatedly.
  • Select, Insert and Delete all run inference on all of the input keys as a single batch, which can be faster
