AFLNet: A Greybox Fuzzer for Network Protocols

AFLNet is a greybox fuzzer for protocol implementations. Unlike existing protocol fuzzers, it takes a mutational approach and uses state-feedback, in addition to code-coverage feedback, to guide the fuzzing process. AFLNet is seeded with a corpus of recorded message exchanges between the server and an actual client. No protocol specification or message grammars are required. It acts as a client and replays variations of the original sequence of messages sent to the server and retains those variations that were effective at increasing the coverage of the code or state space. To identify the server states that are exercised by a message sequence, AFLNet uses the server’s response codes. From this feedback, AFLNet identifies progressive regions in the state space, and systematically steers towards such regions.

Licences

AFLNet is licensed under Apache License, Version 2.0.

AFLNet is an extension of American Fuzzy Lop written and maintained by Michał Zalewski <lcamtuf@google.com>. For details on American Fuzzy Lop, we refer to README-AFL.md.

AFL: Copyright 2013, 2014, 2015, 2016 Google Inc. All rights reserved. Released under terms and conditions of Apache License, Version 2.0.

Citing AFLNet

AFLNet has been accepted for publication as a Testing Tool paper at the IEEE International Conference on Software Testing, Verification and Validation (ICST) 2020.

@inproceedings{AFLNet,
author={Van{-}Thuan Pham and Marcel B{\"o}hme and Abhik Roychoudhury},
title={AFLNet: A Greybox Fuzzer for Network Protocols},
booktitle={Proceedings of the 13rd IEEE International Conference on Software Testing, Verification and Validation : Testing Tools Track},
year={2020},}

Installation (Tested on Ubuntu 18.04 & 16.04 64-bit)

Prerequisites

# Install clang (as required by AFL/AFLNet to enable llvm_mode)
sudo apt-get install clang
# Install graphviz development
sudo apt-get install graphviz-dev libcap-dev

AFLNet

Download AFLNet and compile it. We have tested AFLNet on Ubuntu 18.04 and Ubuntu 16.04 64-bit and it would also work on all environments that support the vanilla AFL and graphviz.

# First, clone this AFLNet repository to a folder named aflnet
git clone <links to the repository> aflnet
# Then move to the source code folder
cd aflnet
make clean all
cd llvm_mode
# The following make command may not work if llvm-config cannot be found
# To fix this issue, just set the LLVM_CONFIG env. variable to the specific llvm-config version on your machine
# On Ubuntu 18.04, it could be llvm-config-6.0 if you have installed clang using apt-get
make
# Move to AFLNet's parent folder
cd ../..
export AFLNET=$(pwd)/aflnet
export WORKDIR=$(pwd)

Setup PATH environment variables

export PATH=$PATH:$AFLNET
export AFL_PATH=$AFLNET

Usage

AFLNet adds the following options to AFL. Run afl-fuzz --help to see all options. Please also see the FAQs section for common questions about these AFLNet's options.

-N netinfo: server information (e.g., tcp://127.0.0.1/8554)
-P protocol: application protocol to be tested (e.g., RTSP, FTP, DTLS12, DNS, DICOM, SMTP, SSH, TLS, DAAP-HTTP, SIP)
-D usec: (optional) waiting time (in microseconds) for the server to complete its initialization
-e netnsname: (optional) network namespace name to run the server in
-K : (optional) send SIGTERM signal to gracefully terminate the server after consuming all request messages
-E : (optional) enable state aware mode
-R : (optional) enable region-level mutation operators
-F : (optional) enable false negative reduction mode
-c script : (optional) name or full path to a script for server cleanup
-q algo: (optional) state selection algorithm (e.g., 1. RANDOM_SELECTION, 2. ROUND_ROBIN, 3. FAVOR)
-s algo: (optional) seed selection algorithm (e.g., 1. RANDOM_SELECTION, 2. ROUND_ROBIN, 3. FAVOR)

Example command:

afl-fuzz -d -i in -o out -N <server info> -x <dictionary file> -P <protocol> -D 10000 -q 3 -s 3 -E -K -R <executable binary and its arguments (e.g., port number)>

Tutorial - Fuzzing Live555 media streaming server

Live555 Streaming Media is a C++ library for multimedia streaming. The library supports open protocols such as RTP/RTCP and RTSP for streaming. It is used internally by widely-used media players such as VLC and MPlayer and some security cameras & network video recorders (e.g., DLink D-View Cameras, Senstar Symphony, WISENET Video Recorder). In this example, we show how AFLNet can be used to fuzz Live555 and discover bugs in its RTSP server reference implementation (testOnDemandRTSPServer). Similar steps would be followed to fuzz servers implementing other protocols (e.g., FTP, SMTP, SSH).

If you want to run some experiments quickly, please take a look at ProFuzzBench. ProFuzzBench includes a suite of representative open-source network servers for popular protocols (e.g., TLS, SSH, SMTP, FTP, SIP), and tools to automate experimentation.

Step-0. Server and client compilation & setup

The newest source code of Live555 can be downloaded as a tarball at Live555 public page. There is also a mirror of the library on GitHub. In this example, we choose to fuzz an old version of Live555 which was commited to the repository on August 28th, 2018. While fuzzing this specific version of Live555, AFLNet exposed four vulnerabilites in Live555, two of which were zero-day. To compile and setup Live555, please use the following commands.

cd $WORKDIR
# Clone live555 repository
git clone https://github.com/rgaufman/live555.git
# Move to the folder
cd live555
# Checkout the buggy version of Live555
git checkout ceeb4f4
# Apply a patch. See the detailed explanation for the patch below
patch -p1 < $AFLNET/tutorials/live555/ceeb4f4.patch
# Generate Makefile
./genMakefiles linux
# Compile the source
make clean all

As you can see from the commands, we apply a patch to make the server effectively fuzzable. In addition to the changes for generating a Makefile which uses afl-clang-fast++ to do the coverage feedback-enabled instrumentation, we make a small change to disable random session ID generation in Live555. In the unmodified version of Live555, it generates a session ID for each connection and the session ID should be included in subsequent requests sent from the connected client. Otherwise, the requests are quickly rejected by the server and this leads to undeterministic paths while fuzzing. Specifically, the same message sequence could exercise different server paths because the session ID is changing. We handle this specific issue by modifing Live555 in such a way that it always generates the same session ID.

Once Live555 source code has been successfully compiled, we should see the server under test (testOnDemandRTSPServer) and the sample RTSP client (testRTSPClient) placed inside the testProgs folder. We can test the server by running the following commands.

# Move to the folder keeping the RTSP server and client
cd $WORKDIR/live555/testProgs
# Copy sample media source files to the server folder
cp $AFLNET/tutorials/live555/sample_media_sources/*.* ./
# Run the RTSP server on port 8554
./testOnDemandRTSPServer 8554
# Run the sample client on another screen/terminal
./testRTSPClient rtsp://127.0.0.1:8554/wavAudioTest

We should see the outputs from the sample client showing that it successfully connects to the server, sends requests and receives responses including streaming data from the server.

Step-1. Prepare message sequences as seed inputs

AFLNet takes message sequences as seed inputs so we first capture some sample usage scenarios between the sample client (testRTSPClient) and the server under test (SUT). The following steps show how we prepare a seed input for AFLNet based on a usage scenario in which the server streams an audio file in WAV format to the client upon requests. The same steps can be followed to prepare other seed inputs for other media source files (e.g., WebM, MP3).

We first start the server under test

cd $WORKDIR/live555/testProgs
./testOnDemandRTSPServer 8554

After that, we ask tcpdump data-network packet analyzer to capture all traffics through the port opened by the server, which is 8554 in this case. Note that you may need to change the network interface that works for your setup using the -i option.

sudo tcpdump -w rtsp.pcap -i lo port 8554

Once both the server and tcpdump have been started, we run the sample client

cd $WORKDIR/live555/testProgs
./testRTSPClient rtsp://127.0.0.1:8554/wavAudioTest

When the client completes its execution, we stop tcpdump. All the requests and responses in the communication between the client and the server should be stored in the specified rtsp.pcap file. Now we use Wireshark network analyzer to extract only the requests and use the request sequence as a seed input for AFLNet. Please install Wireshark if you haven't done so.

We first open the PCAP fi
