ECSPowerNetcode

The library is made on top of the Unity Netcode package and saves you some time on configuring it / provides tools for client-server communication.

Table of Contents

• Install
  • Dependencies
• Getting started
• • Starting a server and connecting to it locally
• • Connecting to a remote server
• • Accessing connection's entities
• • Handlers
• Groups
• Command builders
• Command handlers
• Synchronizing entities
• • Creating an entity on server side
• • Transferring the entity
• • Creating the entity on the client side
• • Synchronizing the entity
• • Destroying the entity
• • Accessing the entities
• • Customization
• Synchronizing components
• Managed RPC commands

Demo

I like to have this repo as a module without a unity project, so please go to another repo which I created just for a demo: ECSPowerNetcodeDemo.

Install

You can either just put the files into Assets/Plugins/ECSEntityBuilder or use it as a submodule:

git submodule add https://github.com/actionk/ECSPowerNetcode.git Assets/Plugins/ECSPowerNetcode

Important! After adding a plugin, please add the Network prefab into your scene from ECSPowerNetcode/Prefabs folder. This will enable networking.

Dependencies

The library depends on:

• UnityECSEntityBuilder
• Unity Netcode 0.3

These are required dependencies

Getting started

Starting a server and connecting to it locally

ServerManager.Instance.StartServer(7979);
ClientManager.Instance.ConnectToServer(7979);

After doing so, the library will automatically establish a connection and create command handlers for each connection in both client & server world.

Connecting to a remote server

ClientManager.Instance.ConnectToServer(7979, "remote ip address");

Accessing connection's entities

Each connection is described by these parameters:

public struct ConnectionDescription
{
    public int networkId; // unique network id value for client-server connection
    public Entity connectionEntity;
    public Entity commandHandlerEntity;
}

Client side

ClientManager.Instance.IsConnected

ClientManager.Instance.ConnectionToServer -> ConnectionDescription struct

Server side

ServerManager.Instance.AllConnections - getting list of all connected clients of ConnectionDescription struct

ServerManager.Instance.GetClientConnectionByNetworkId

Handlers

Client

You can set your handlers for OnConnected & OnDisconnected events:

ClientManager.Instance.OnConnectedHandler += MyHandler;
ClientManager.Instance.OnDisconnectedHandler += MyHandler;

Server

You can set your handlers for OnConnected & OnDisconnected events for each player:

public delegate void OnPlayerDisconnected(int networkConnectionId);

ServerManager.Instance.OnPlayerConnectedHandler += MyHandler;
ServerManager.Instance.OnPlayerDisconnectedHandler += MyHandler;

Groups

Client

ClientConnectionSystemGroup
ClientRequestProcessingSystemGroup
ClientNetworkEntitySystemGroup
ClientGameSimulationSystemGroup

| Group | Description | | --- | --- | | ClientConnectionSystemGroup | Connection/Disconnection from server | | ClientRequestProcessingSystemGroup | Processing requests from server | | ClientNetworkEntitySystemGroup | Processing network entities | | ClientGameSimulationSystemGroup | All your game simulations on client side |

Server

ServerConnectionSystemGroup
ServerRequestProcessingSystemGroup
ServerNetworkEntitySystemGroup
ServerGameSimulationSystemGroup

| Group | Description | | --- | --- | | ServerConnectionSystemGroup | Connection/Disconnection from clients | | ServerRequestProcessingSystemGroup | Processing requests from clients | | ServerNetworkEntitySystemGroup | Processing network entities | | ServerGameSimulationSystemGroup | All your game simulations on server side |

Command builders

For making your life easier, there are command builders for both client & server commands. First of all, you have to create an IRpcCommand yourself.

Client

ClientToServerRpcCommandBuilder
    .Send(new ClientPlayerLoginCommand {localPlayerSide = PlayerManager.LocalPlayerSide.LEFT})
    .Build(PostUpdateCommands);

Where ClientPlayerLoginCommand implements IRpcCommand

Server

You can specify which client to send the command to:

ServerToClientRpcCommandBuilder
    .SendTo(clientConnectionEntity, command)
    .Build(PostUpdateCommands);

ServerToClientRpcCommandBuilder
    .SendTo(networkConnectionId, command)
    .Build(PostUpdateCommands);

Or you can simply broadcast:

ServerToClientRpcCommandBuilder
    .Broadcast(command)
    .Build(PostUpdateCommands);

Command handlers

Client

Simply inherit from AClientReceiveRpcCommandSystem to implement a client command handler for RPC command of type ServerPlayerLoginResponseCommand (for example):

public class ClientPlayerLoginResponseSystem : AClientReceiveRpcCommandSystem<ServerPlayerLoginResponseCommand>
{
    protected override void OnCommand(ref ServerPlayerLoginResponseCommand command, ConnectionDescription clientConnection)
    {
        // process your command
    }
}

Server

Simply inherit from AServerReceiveRpcCommandSystem to implement a server command handler for RPC command of type ClientDropItemCommand (for example):

public class ServerDropItemSystem : AServerReceiveRpcCommandSystem<ClientDropItemCommand>
{
    protected override void OnCommand(ref ClientDropItemCommand command, ConnectionDescription clientConnection)
    {
        // process your command
    }
}

Synchronizing entities

Usually your way of organizing entities in client-server architecture with ECS would look like that:

That's for, the library provides you with a way of synchronizing entities without using ghost components:

Creating an entity on server side

You start with creating an entity builder by inheriting your builder from ServerNetworkEntityBuilder:

public class ServerPlayerBuilder : ServerNetworkEntityBuilder<ServerPlayerBuilder>
{
    protected override ServerPlayerBuilder Self => this;

    public static ServerPlayerBuilder Create(int networkId, Entity connection, uint playerId, PlayerManager.LocalPlayerSide localPlayerSide)
    {
        return new ServerPlayerBuilder(networkId, connection, playerId, localPlayerSide);
    }

    private ServerPlayerBuilder(int networkId, Entity connection, uint playerId, PlayerManager.LocalPlayerSide localPlayerSide) : base()
    {
        CreateFromArchetype<PlayerArchetype>(WorldType.SERVER);
        SetComponentData(new Scale {Value = 1});
        AddComponentData(new ServerPlayer
        {
            networkId = networkId,
            connection = connection,
            playerId = playerId,
            localPlayerSide = localPlayerSide
        });
    }
}

Transferring the entity

Then, you create an RPC command to send the entity to the clients:

[BurstCompile]
public struct PlayerTransferCommand : INetworkEntityCopyRpcCommand, IRpcCommand
{
    public ulong NetworkEntityId => networkEntityId;

    public int networkId;
    public ulong networkEntityId;
    public uint playerId;
    public PlayerManager.LocalPlayerSide localPlayerSide;
    public float3 position;
}

Then, for creating the command, you create a system inherited from AServerNetworkEntityTransferSystem:

[UpdateInGroup(typeof(ServerNetworkEntitySystemGroup))]
public class ServerPlayerTransferSystem : AServerNetworkEntityTransferSystem<ServerPlayer, PlayerTransferCommand>
{
    protected override PlayerTransferCommand CreateTransferCommandForEntity(Entity entity, NetworkEntity networkEntity, ServerPlayer selectorComponent)
    {
        return new PlayerTransferCommand
        {
            networkId = selectorComponent.networkId,
            networkEntityId = networkEntity.networkEntityId,
            playerId = selectorComponent.playerId,
            localPlayerSide = selectorComponent.localPlayerSide,
            position = EntityManager.GetComponentData<Translation>(entity).Value
        };
    }
}

There are also options for selection more components (2 and 3), such as AServerNetworkEntityTransferSystemT2 and AServerNetworkEntityTransferSystemT3.

Creating the entity on the client side

And the system for consuming this command on the client side:

[UpdateInGroup(typeof(ClientEarlyUpdateSystemGroup))]
public class ClientPlayerTransferSystem : AClientNetworkEntityTransferSystem<PlayerTransferCommand>
{
    protected override void CreateNetworkEntity(ulong networkEntityId, PlayerTransferCommand command)
    {
        ClientPlayerBuilder
            .Create(command)
            .Build(EntityManager);
    }

    protected override void SynchronizeNetworkEntity(Entity entity, PlayerTransferCommand command)
    {
        EntityWrapper.Wrap(entity, PostUpdateCommands)
