Information

The official source code for NuevoMatch as described in "A Computational Approach to Packet Classification" [1]. This library contains the source-code for training and running RQ-RMI models (in a stand-alone fashion), the algorithm for generating iSets from ClassBench [2] files, NuevoMatch classifier, and other several tools and benchmarks.

Prerequisites

General prerequisites:

• A Linux operating system / WSL for Windows operating system
• Intel CPU that supports AVX2 and FMA extensions (the configuration script will check that for you)
• g++ compiler that supports C++14
• GNU Make
• Python 3.5+
• Python3-dev package (must be compatible with Python 3.5+)
• Make sure both hyperthreading and frequency scaling are disabled for maximum performance.

Python prerequisites:

• Tensorflow (tested with version 1.13.1)
• Numpy (tested with version 1.16.2)
• Distutils (tested with version 3.6.7)
• Matplotlib (tested with version 3.0.3)

Installation

• Run the configuration script. It checks that all prerequisites are met, and generates a Makefile.

./configure

• Run GNU make (-f option recommended)

make -f

A directory named "bin" will be created with executable and scripts.

Simple Python Examples

The "examples" directory contains three simple Python examples.

• simple_rmi.py: (1) generates a key-value database according to Zipf law (2) trains a limited RMI [3] model (3) saves the model to a file and exports a chart with some information.
• simple_rqrmi.py: Does the same as simple_rmi.py but with RQRMI training & theory (responsibilities, dataset sampling, etc.). The saved model can be loaded using bench_rqrmi.exe tool for performance measurements.
• simple_lookup.py: Perform a full key-value lookup using RQRMI and secondary search in Python. Exports the data-structure to a file. The saved data-structure can be loaded using bench_lookup.exe tool for performance measurements.

Tools and Microbenchmarks

All tools and microbenchmarks are available under the "bin" directory. Use "--help" for usage instructions.

Tools:

• tool_classifier.exe: Use this tool to evaluate NuevoMatch against CutSplit [5], NeuroCuts [4], and TupleMerge [6].
• tool_trace_generator.exe: Generates accurate packet traces (5-tuple + matched priority) from ClassBench files with uniform rule distribution.
• tool_locality.exe: Locality tool for generating skewed traces. Can be used to extract temporal locality from PCAP files (together with tcpdump), or to generate Zipf distribution with various parameters.
• nuevomatch.py: Generates NuevoMatch classifiers from ClassBench files.
• ruleset_analysis.py: Analyze ClassBench rulesets. Mainly used for debugging iSets.
• pack_neurocuts.py: Converts NeuroCuts [4] classifiers to binary files that can be read using our native implementation of NeuroCuts.
• classifier_analysis.py: Extracts RQRMI models from NuevoMatch classifier files.

Microbenchmarks:

• bench_rqrmi.exe: Tests the performance of an RQRMI model using both serial code and AVX acceleration. The model is loaded from a file (use simple_rqrmi.py for generating such files).
• bench_lookup.exe: Tests both the performance and the correctness of RQRMI using a secondary search. The data-structure is loaded from a file (use simple_lookup.py for generating such files).
• bench_echo.exe: Tests the communication performance between two threads.
• bench_reducer.exe: Tests the communication performance between several threads.

A Full Example

You can use the tools to run NuevoMatch as follows:

1. Get a ClassBench ruleset. You can generate one using the original tool.
2. Train a model using ./bin/nuevomatch.py (takes about 40 minutes):

./bin/nuevomatch.py -f my_ruleset.txt -o my_model.data --min-size 64 --max-error 64

3. Use ./bin/tool_trace_generator.exe to generate a trace from a ClassBench ruleset:

./bin/tool_trace_generator.exe -f my_ruleset.txt -n 10000000 -o my_trace.txt

4. You can shuffle the trace according to Zipf temporal locality:

./bin/tool_locality.exe --trace-file my_trace.txt --output-trace my_trace_modified.txt --zipf --alpha 0.99

5. Use ./bin/tool_classifier.exe to test NuevoMatch:

./bin/tool_classifier.exe -m nuevomatch -l -in my_model.data --trace my_trace_modified.txt --parallel 1 --trace-silent --max-subsets 1 --remainder-type tuplemerge --force-remainder-build -v 3

License and Credits

MIT license. See LICENSE.md for more details.

---

[1] A computational approach to packet classification (ACM SIGCOMM, 2020)

[2] Classbench: A packet classification benchmark (ACM TON, 2007)

[3] The case for learned index structures (ACM SIGMOD, 2018)

[4] Neural packet classification (ACM SIGCOMM, 2019)

[5] Cutsplit: A decision-tree combining cutting and splitting for scalable packet classification (IEEE INFOCOM, 2018)

[6] TupleMerge: Fast software packet processing for online packet classification (ACM TON, 2019)
