Elvato

Architecture Overview

Elvato is a headless commerce system built on Medusa.js with a Next.js storefront, designed as a decoupled service mesh where commerce logic, web delivery, media distribution, and payments are isolated and independently scalable.

Platform Composition

• Commerce framework: Medusa.js provides catalog, cart, checkout, order, and admin domain logic.
• Storefront runtime: Next.js application deployed on Vercel.
• Search engine: MeiliSearch provides full-text product search, category filtering, and price sorting.
• Payment provider: Stripe handles payment authorization, capture, and webhook-driven reconciliation.

Production Topology

• Storefront edge endpoint: Vercel hosts the production storefront at https://elvato.shop.
• Core commerce origin: Railway hosts the Medusa backend, including Store API and Admin API surfaces.
• Admin access path: https://admin.elvato.shop is served via a Vercel front-door and routed to the Railway admin origin at /app.
• Search index: Railway hosts a self-hosted MeiliSearch v1.12.8 instance at https://meilisearch-production-3595.up.railway.app. The Medusa backend indexes products via Railway private networking; the storefront queries via the public endpoint.
• Persistence layer: Neon hosts PostgreSQL as the primary transactional datastore for the Medusa backend.
• Cache and event infrastructure: Upstash Redis (via Vercel integration) supports caching and event-driven backend workloads.
• Image pipeline: Convex manages image metadata and file workflows, with Bunny.net CDN serving optimized storefront media at edge.

Operational Value

• Separation of concerns: Web delivery (Vercel), commerce runtime (Railway), search (MeiliSearch), and data services (Neon/Upstash/Convex) can be scaled and operated independently.
• Performance profile: Edge-rendered storefront delivery, sub-100ms typo-tolerant search, and CDN-backed media distribution reduces latency and origin load.
• Reliability posture: Managed platforms (Vercel, Railway, Neon, Upstash, Stripe) reduce operational overhead while preserving production-grade observability and elasticity.

Service Documentation

Detailed documentation for each service is maintained in .docs/:

| Service | Documentation | |---------|---------------| | Railway Admin Backend | .docs/railway-admin-backend.md | | Docker Container (Railway) | .docs/docker-container.md | | MeiliSearch Product Search | .docs/product-index/meilisearch-integration.md | | Vercel Storefront Deployment | .docs/vercel-storefront-deployment.md | | Neon PostgreSQL Database | .docs/neon-postgresql-database.md | | Stripe Payment Processing | .docs/stripe-payment-processing.md | | Convex CDN Image Layer | .docs/convex-cdn-image-layer.md |

Docker Container (Railway)

The Medusa admin backend runs as a Docker container on Railway, built from admin/Dockerfile and configured via railway.json.

Build pipeline:

1. Railway detects a push to the linked branch
2. Builds a Docker image using admin/Dockerfile (Node 20, production dependencies only)
3. Deploys the image as a container on Railway infrastructure

Startup sequence (CMD):

npx medusa db:migrate
npx medusa exec ./src/scripts/bootstrap-meilisearch.ts
npm run start

| Step | Purpose | |------|---------| | db:migrate | Applies any pending database migrations to Neon PostgreSQL | | bootstrap-meilisearch | Configures index settings (searchable/filterable fields, stop words, synonyms) and syncs all products into MeiliSearch. Required because MeiliSearch uses ephemeral storage — data is wiped on each Railway restart. | | start | Starts the Medusa server on port 9000 |

Key details:

• The container is not visible in Docker Desktop — Railway builds and runs it remotely
• Service status is monitored via the Railway dashboard (deploy logs, runtime logs, metrics)
• MeiliSearch is a separate Railway service with ephemeral storage; the bootstrap step repopulates it on every deploy
• The storefront falls back to the Medusa Store API if MeiliSearch is temporarily unavailable during startup
