MQSpaceData v5.5.4

MQDataScience What can be create?

"The first and only Arduino library where MQ Sensors combine with Data Science"

1) Advanced Data Science System for Regression Calculations

2) Ppm Analysis of Different Model Gases

3) Formulated Correction Coefficients depending on Temperature and Humidity

4) 3D Surface Diagram for MQ-135 Gases

5) Slope Estimation in Time-Dependent 4D Space

4D Axis Features:

<img width="750" alt="4dformullas" src="https://github.com/user-attachments/assets/7c5a1464-fcb9-4a8f-9693-c2c473f1ec1a" />

Ppm Formullas

<img width="360" alt="log" src="https://github.com/user-attachments/assets/c0d1db76-0c69-4725-80fc-aed740fcbac8" />

<img width="1264" alt="image1" src="https://github.com/user-attachments/assets/63fcad55-8c34-4520-a2b6-af4c509d6888" /> <img width="1264" alt="image2" src="https://github.com/user-attachments/assets/2aeeeef4-0d06-45f1-9f49-b4e513cc5dea" />

    if r_squared >= 0.9995:
        print("R-squared value for {gas name} is above 0.9995, plotting against first and last values.")

        x0, y0 = x[0], y[0]
        xn, yn = x[-1], y[-1]
        b = np.log10(yn/y0) / np.log10(xn/x0)
        a = 10**(np.log10(yn) - b * np.log10(xn))
        b2 = np.log10(yn) - b * np.log10(xn)
        b2_rounded = round(b2, 4)
        a_rounded = round(a, 4)
        b_rounded = round(b, 4)

The first formula is determined according to all points (Curves.py, OldCurve), while the second formula is determined according to the first and last point. Therefore, in order to collect them all in the same formula and to increase the accuracy rate, we used the method in the second formula and took the logarithm (if R^2 = 1 (%100) always: logm = valueb, logb = log10(valuea)) for curves greater than 99.95% and collected them all in the first formula, thus we increased the accuracy rate without having to use 2 different formulas (Curves.py, NewCurve).

y = ax^b --> ppm = a×ratio^b

<b> Therefore, we need to make a transition according to the formula:

<img width="400" alt="image3" src="https://github.com/user-attachments/assets/9706b917-7ce9-4bc9-a3bb-171a11e46052" />

<b> In data graphs, the x-axis is given as ppm and the y-axis is given as ratio.

V = I × R

<img width="1264" alt="image4" src="https://github.com/user-attachments/assets/cdcdc664-251c-4d1f-a79b-8481ded8a043" />

---

<img width="685" height="70" alt="image5" src="https://github.com/user-attachments/assets/36fedfeb-24dc-4a71-801d-1188c149e6bd" />

Calculate Ratio

<img width="698" height="332" alt="image6" src="https://github.com/user-attachments/assets/13d05db9-011d-4844-bf97-16c3baca77b6" />

Ratio for Sensors

STATUS 1: MQ-2, MQ-3, MQ-4, MQ-5, MQ-6, MQ-7, MQ-8, MQ-9, MQ-135, MQ-136, MQ-137 [Almost All & Standart]

STATUS 2: MQ303A, MQ303B, MQ307A, MQ309A [A Models & B Models]

STATUS 3: MQ-131_LOW, MQ131 [MQ131 Models]

Inclusion of Correction Coefficient

<img width="1264" alt="ppmlast" src="https://github.com/user-attachments/assets/d597f6f1-44b3-4ea8-ae55-20d8d35e7c47" />

STEL Limits For Gases

Required Preheating Times For MQ Sensors

Required Circuit Diagrams For MQ sensors

Required Voltage Ranges For MQ Sensors

Required RL Values (Load Resistors) For MQ Sensors

Check out all our DataScience libraries under the SpaceData series!

"The first and only Arduino library series where Gas Sensors and Geiger Counter combine with Data Science"

| Library | Scope | |---------|---------| | <a href="https://github.com/abcdaaaaaaaaa/MQDataScience">MQDataScience | MQ2, MQ3, MQ4, MQ5, MQ6, MQ7, MQ8, MQ9, MQ131_LOW, MQ131_HIGH, MQ135, MQ136, MQ137, MQ138, MQ214, MQ216, MQ303A, MQ303B, MQ306A, MQ307A, MQ309A Gas Sensors | | <a href="https://github.com/abcdaaaaaaaaa/TGSDataScience">TGSDataScience | TGS813, TGS822, TGS826, TGS2201, TGS2442, TGS2600, TGS2602, TGS2610, TGS2611, TGS2612, TGS2620, TGS6812, TGS8100 Gas Sensors | | <a href="https://github.com/abcdaaaaaaaaa/MG811DataScience">MG811DataScience | MG811 Gas Sensor | | <a href="https://github.com/abcdaaaaaaaaa/SP3S-AQ2DataScience">SP3S-AQ2DataScience | SP3S-AQ2-01 Gas Sensor | | <a href="https://github.com/abcdaaaaaaaaa/RadioactiveDataScience">RadioactiveDataScience | Geiger Counter |

For detailed explanation, You can also check out the github <a href="https://github.com/abcdaaaaaaaaa/MQDataScience/wiki">Wiki Page!

You can access the library's article <a href="https://www.spacepedia.info/MQDataScience">Here!
