Pyseistr
Description
Pyseistr is a python package for structural denoising and interpolation of multi-channel seismic data. The latest version has incorporated both Python and C (hundreds of times faster) implementations of the embedded functions. We keep both implementations for both educational and production purposes. This package has a variety of applications in both exploration and earthquake seismology.
Reference
Chen et al., 2023, Pyseistr: a python package for structural denoising and interpolation of multi-channel seismic data, Seismological Research Letters, 94(3), 1703-1714.
BibTeX:
@article{pyseistr,
title={Pyseistr: a python package for structural denoising and interpolation of multi-channel seismic data},
author={Yangkang Chen and Alexandros Savvaidis and Sergey Fomel and Yunfeng Chen and Omar M. Saad and Yapo Abol{\'e} Serge Innocent Obou{\'e} and Quan Zhang and Wei Chen},
journal={Seismological Research Letters},
volume={94},
number={3},
pages={1703–1714},
year={2023}
}
Copyright
The pyseistr developing team, 2021-present
License
MIT License
Install
Using the latest version
git clone https://github.com/aaspip/pyseistr
cd pyseistr
pip install -v -e .
or using Pypi
pip install pyseistr
or using pip directly from github (Preferable because Pyseistr is updated very frequently)
pip install git+https://github.com/aaspip/pyseistr
If you encounter a problem on certain machines or Google Colab, try the following:
pip install --no-build-isolation git+https://github.com/aaspip/pyseistr
Verified runnable OS
Mac OS, Linux, Windows (need Microsoft C++ Build Tools)
DEMO scripts
The "demo" directory contains all runable scripts to demonstrate different applications of pyseistr.
Gallery
The gallery figures of the pyseistr package can be found at https://github.com/aaspip/gallery/tree/main/pyseistr Each figure in the gallery directory corresponds to a DEMO script in the "demo" directory with the exactly the same file name.
Dependence Packages
- scipy
- numpy
- matplotlib
Modules
dip2d.py -> 2D local slope estimation (including both python and C implementations)
dip3d.py -> 3D local slope estimation (including both python and C implementations)
divne.py -> element-wise division constrained by shaping regularization (python implementation)
somean2d.py -> 2D structure-oriented mean filter (including both python and C implementations)
somean3d.py -> 3D structure-oriented mean filter (including both python and C implementations)
somf2d.py -> 2D structure-oriented median filter (including both python and C implementations)
somf3d.py -> 3D structure-oriented median filter (including both python and C implementations)
soint2d.py -> 2D structural interpolation (including both python and C implementations)
soint3d.py -> 3D structural interpolation (including both python and C implementations)
ricker.py -> Ricker wavelet
bp.py -> Butterworth bandpass filter (including both python and C implementations)
fk.py -> FK dip filter
plot.py -> seismic plotting functions
Development
The development team welcomes voluntary contributions from any open-source enthusiast.
If you want to make contribution to this project, feel free to contact the development team.
Contact
Regarding any questions, bugs, developments, collaborations, please contact
Yangkang Chen
chenyk2016@gmail.com
Examples
Example 1 (2D structure-oriented mean/smoothing filter)
Generated by demos/test_pyseistr_somean2d.py
<img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_somean2d.png' alt='Slicing' width=960/>Example 2 (3D structure-oriented mean/smoothing filter)
Generated by demos/test_pyseistr_somean3d.py
<img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_somean3d.png' alt='Slicing' width=960/>Example 3 (2D structure-oriented median filter)
Generated by demos/test_pyseistr_somf2d.py
<img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_somf2d.png' alt='Slicing' width=960/>Example 4 (3D structure-oriented median filter)
Generated by demos/test_pyseistr_somf3d.py
<img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_somf3d.png' alt='Slicing' width=960/>Example 5 (3D structure-oriented interpolation)
Generated by demos/test_pyseistr_passive_recon3d.py
<img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_passive_recon3d.png' alt='Slicing' width=960/>Example 6 (SS precursor data enhancement)
Generated by demos/test_pyseistr_ssprecursor.py
<img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_ssprecursor.png' alt='Slicing' width=960/>Example 7 (receiver function data enhancement)
Generated by demos/test_pyseistr_rf.py
<img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_rf.png' alt='Slicing' width=960/>Example 8 (structure-oriented distributed acoustic sensing (DAS) data processing)
Generated by demos/test_pyseistr_das.py
<img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_das.png' alt='Slicing' width=960/>For a spectra comparison, please see the figure below. Generated by the same script demos/test_pyseistr_das.py
<img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_das_fx.png' alt='Slicing' width=960/>Below are new examples in addition to the results in the original paper
Below is an example for 2D structure-oriented interpolation of a multi-channel synthetic seismic data
Generated by demos/test_pyseistr_soint2d.py <img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_soint2d.png' alt='comp' width=960/>
Below is an example for 2D structure-oriented interpolation of a seafloor dataset
Generated by demos/test_pyseistr_soint2d_seafloor.py <img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_soint2d_seafloor.png' alt='comp' width=960/>
Below is another example for 2D structure-oriented interpolation of sparse seismic data
Generated by demos/test_pyseistr_soint2d2.py <img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_soint2dnew.png' alt='comp' width=960/>
Below is an example for calculating relative geological time (RGT) from 2D seismic data
Generated by demos/test_pyseistr_rgt2d.py <img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_rgt2d.png' alt='comp' width=960/>
Below is an example for 2D interpolation of sparse seismic data
Generated by demos/test_pyseistr_sint2d.py <img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_sint2d.png' alt='comp' width=960/>
Below is an example for plotting fancy 3D figures using pyseistr
Generated by demos/test_first
<p align="center"> <img src='https://github.com/chenyk1990/gallery/blob/main/pywave/vel3d.png' alt='comp' width=960/> <img src='https://github.com/chenyk1990/gallery/blob/main/pywave/data3d.png' alt='comp' width=640/> </p>Below is an example for generating fancy GIF figures using pyseistr
Generated by demos/test_second_wfd3ds
<p align="center"> <img src='https://github.com/chenyk1990/gallery/blob/main/pywave/wfd3ds.gif' alt='comp' width=960/> </p>Below is an example for generating fancy wiping-style animation using pyseistr
Generated by demos/test_pyseistr_das_animation
<p align="center"> <img src='https://github.com/aaspip/gallery/blob/main/pyseistr/test_pyseistr_das_animation.gif' alt='comp' width=960/> </p>Below is an example for visualizing 3D patches
Generated by mlnb/DL_denoise_simple3D.ipynb
<p align="center"> <img src='https://github.com/aaspip/gallery/blob/main/pyseistr/patches.png' alt='comp' width=960/> </p>We now can highlight the slices in the plot3d function
Generated by Example 6 in plot3d documentation
<p align="center"> <img src='https://github.com/aaspip/gallery/blob/main/pyseistr/pyseistr_plot3d_slices.jpg' alt='comp' width=960/> </p>We now can show the inside of the 3D cube in the plot3d function
Generated by [Example 7
