MVSNet & R-MVSNet

[News] BlendedMVS dataset is released!!! (project link).

About

MVSNet is a deep learning architecture for depth map inference from unstructured multi-view images, and R-MVSNet is its extension for scalable learning-based MVS reconstruction. If you find this project useful for your research, please cite:

@article{yao2018mvsnet,
  title={MVSNet: Depth Inference for Unstructured Multi-view Stereo},
  author={Yao, Yao and Luo, Zixin and Li, Shiwei and Fang, Tian and Quan, Long},
  journal={European Conference on Computer Vision (ECCV)},
  year={2018}
}

@article{yao2019recurrent,
  title={Recurrent MVSNet for High-resolution Multi-view Stereo Depth Inference},
  author={Yao, Yao and Luo, Zixin and Li, Shiwei and Shen, Tianwei and Fang, Tian and Quan, Long},
  journal={Computer Vision and Pattern Recognition (CVPR)},
  year={2019}
}

If BlendedMVS dataset is used in your research, please also cite:

@article{yao2020blendedmvs,
  title={BlendedMVS: A Large-scale Dataset for Generalized Multi-view Stereo Networks},
  author={Yao, Yao and Luo, Zixin and Li, Shiwei and Zhang, Jingyang and Ren, Yufan and Zhou, Lei and Fang, Tian and Quan, Long},
  journal={Computer Vision and Pattern Recognition (CVPR)},
  year={2020}
}

How to Use

Installation

Check out the source code git clone https://github.com/YoYo000/MVSNet
Install cuda 9.0, cudnn 7.0 and python 2.7
Install Tensorflow and other dependencies by sudo pip install -r requirements.txt

Download

Preprocessed training/validation data: BlendedMVS, DTU and ETH3D. More training resources could be found in BlendedMVS github page
Preprocessed testing data: DTU testing set, ETH3D testing set, Tanks and Temples testing set and training set
Pretrained models: pretrained on BlendedMVS, on DTU and on ETH3D

Training

Enter mvsnet script folder: cd MVSNet/mvsnet
Train MVSNet on BlendedMVS, DTU and ETH3D: python train.py --regularization '3DCNNs' --train_blendedmvs --max_w 768 --max_h 576 --max_d 128 --online_augmentation python train.py --regularization '3DCNNs' --train_dtu --max_w 640 --max_h 512 --max_d 128 python train.py --regularization '3DCNNs' --train_eth3d --max_w 896 --max_h 480 --max_d 128
Train R-MVSNet: python train.py --regularization 'GRU' --train_blendedmvs --max_w 768 --max_h 576 --max_d 128 --online_augmentation python train.py --regularization 'GRU' --train_dtu --max_w 640 --max_h 512 --max_d 128 python train.py --regularization 'GRU' --train_eth3d --max_w 896 --max_h 480 --max_d 128
Specify your input training data folders using --blendedmvs_data_root, --dtu_data_root and --eth3d_data_root
Specify your output log and model folders using --log_folder and --model_folder
Switch from BlendeMVS to BlendedMVG by replacing using --train_blendedmvs with --train_blendedmvg

Validation

Validate MVSNet on BlendedMVS, DTU and ETH3D: python validate.py --regularization '3DCNNs' --validate_set blendedmvs --max_w 768 --max_h 576 --max_d 128 python validate.py --regularization '3DCNNs' --validate_set dtu --max_w 640 --max_h 512 --max_d 128 python validate.py --regularization '3DCNNs' --validate_set eth3d --max_w 896 --max_h 480 --max_d 128
Validate R-MVSNet: python validate.py --regularization 'GRU' --validate_set blendedmvs --max_w 768 --max_h 576 --max_d 128 python validate.py --regularization 'GRU' --validate_set dtu --max_w 640 --max_h 512 --max_d 128 python validate.py --regularization 'GRU' --validate_set eth3d --max_w 896 --max_h 480 --max_d 128
Specify your input model check point using --pretrained_model_ckpt_path and --ckpt_step
Specify your input training data folders using --blendedmvs_data_root, --dtu_data_root and --eth3d_data_root
Specify your output result file using --validation_result_path

Testing

Download test data scan9 and unzip it to TEST_DATA_FOLDER folder
Run MVSNet (GTX1080Ti): python test.py --dense_folder TEST_DATA_FOLDER --regularization '3DCNNs' --max_w 1152 --max_h 864 --max_d 192 --interval_scale 1.06
Run R-MVSNet (GTX1080Ti): python test.py --dense_folder TEST_DATA_FOLDER --regularization 'GRU' --max_w 1600 --max_h 1200 --max_d 256 --interval_scale 0.8
Specify your input model check point using --pretrained_model_ckpt_path and --ckpt_step
Specify your input dense folder using --dense_folder
Inspect the .pfm format outputs in TEST_DATA_FOLDER/depths_mvsnet using python visualize.py .pfm. For example, the depth map and probability map for image 00000012 should look like:

<img src="doc/image.png" width="250"> | <img src="doc/depth_example.png" width="250"> | <img src="doc/probability_example.png" width="250"> :---------------------------------------:|:---------------------------------------:|:---------------------------------------: reference image |depth map | probability map

Post-Processing

R/MVSNet itself only produces per-view depth maps. To generate the 3D point cloud, we need to apply depth map filter/fusion for post-processing. As our implementation of this part is depended on the Altizure internal library, currently we could not provide the corresponding code. Fortunately, depth map filter/fusion is a general step in MVS reconstruction, and there are similar implementations in other open-source MVS algorithms. We provide the script depthfusion.py to utilize fusibile for post-processing (thank Silvano Galliani for the excellent code!).

To run the post-processing:

Check out the modified version fusibile git clone https://github.com/YoYo000/fusibile
Install fusibile by cmake . and make, which will generate the executable at FUSIBILE_EXE_PATH
Run post-processing (--prob_threshold 0.8 if using 3DCNNs): python depthfusion.py --dense_folder TEST_DATA_FOLDER --fusibile_exe_path FUSIBILE_EXE_PATH --prob_threshold 0.3
The final point cloud is stored in TEST_DATA_FOLDER/points_mvsnet/consistencyCheck-TIME/final3d_model.ply.

We observe that depthfusion.py produce similar but quantitatively worse result to our own implementation. For detailed differences, please refer to MVSNet paper and Galliani's paper. The point cloud for scan9 should look like:

<img src="doc/fused_point_cloud.png" width="375"> | <img src="doc/gt_point_cloud.png" width="375"> :--------------------------------------------------:|:----------------------------------------------: point cloud result |ground truth point cloud

Reproduce Paper Results

The following steps are required to reproduce depth map/point cloud results:

Generate R/MVSNet inputs from SfM outputs.You can use our preprocessed testing data in the download section. (provided)
Run R/MVSNet testing script to generate depth maps for all views (provided)
Run R/MVSNet validation script to generate depth map validation results. (provided)
Apply variational depth map refinement for all views (optional, not provided)
Apply depth map filter and fusion to generate point cloud results (partially provided via fusibile)

R-MVSNet point cloud results with full post-processing are also provided: DTU evaluation point clouds

File Formats

Each project folder should contain the following

.
├── images
│   ├── 00000000.jpg
│   ├── 00000001.jpg
│   └── ...
├── cams
│   ├── 00000000_cam.txt
│   ├── 00000001_cam.txt
│   └── ...
└── pair.txt

If you want to apply R/MVSNet to your own data, please structure your data into such a folder. We also provide a simple script colmap2mvsnet.py to convert COLMAP SfM result to R/MVSNet input.

Image Files

All image files are stored in the images folder. We index each image using an 8 digit number starting from 00000000. The following camera and output files use the same indexes as well.

Camera Files

The camera parameter of one image is stored in a cam.txt file. The text file contains the camera extrinsic E = [R|t], intrinsic K and the depth range:

extrinsic
E00 E01 E02 E03
E10 E11 E12 E13
E20 E21 E22 E23
E30 E31 E32 E33

intrinsic
K00 K01 K02
K10 K11 K12
K20 K21 K22

DEPTH_MIN DEPTH_INTERVAL (DEPTH_NUM DEPTH_MAX)

Note that the depth range and depth resolution are determined by the minimum depth DEPTH_MIN, the interval
