============================================================================= Large-scale detection and calculation of alternative splicing with Outrigger_

Outrigger_ is a program which uses junction reads from RNA seq data, and a graph database to create a de novo alternative splicing annotation with a graph database, and quantify percent spliced-in (Psi) of the events.

• Free software: BSD license
• Documentation is available here: http://yeolab.github.io/outrigger/

Features

• Finds novel splicing events, including novel exons! (outrigger index) from .bam files
• (optional) Validates that exons have correct splice sites, e.g. GT/AG and AT/AC for mammalian systems (outrigger validate)
• Calculate "percent spliced-in" (Psi/Ψ) scores for all your samples given the validated events (or the original events if you opted not to validate) via outrigger psi

|OutriggerOverview|

.. |OutriggerOverview| image:: https://raw.githubusercontent.com/YeoLab/outrigger/master/docs/_static/outrigger_overview-300ppi.png :target: https://raw.githubusercontent.com/YeoLab/outrigger/master/docs/_static/outrigger_overview-300ppi.png

Installation

To install outrigger, we recommend using the Anaconda Python Distribution <http://anaconda.org/>__ and creating an environment.

You'll want to add the bioconda <https://bioconda.github.io/>__ channel to make installing bedtools <bedtools.readthedocs.io>__ and its Python wrapper, pybedtools <https://daler.github.io/pybedtools/>__ easy (these programs are necessary for both outrigger index and outrigger validate).

::

conda config --add channels r
conda config --add channels bioconda

Create an environment called outrigger-env. Python 2.7, Python 3.4, Python 3.5, and Python 3.6 are supported.

::

conda create --name outrigger-env outrigger

Now activate that environment:

::

source activate outrigger-env

To check that it installed properly, try the command with the help option (-h), outrigger -h. The output should look like this:

::

$ outrigger -h
usage: outrigger [-h] [--version] {index,validate,psi} ...

outrigger (1.0.0dev). Calculate "percent-spliced in" (Psi) scores of
alternative splicing on a *de novo*, custom-built splicing index -- just for
you!

positional arguments:
  {index,validate,psi}  Sub-commands
    index               Build an index of splicing events using a graph
                        database on your junction reads and an annotation
    validate            Ensure that the splicing events found all have the
                        correct splice sites
    psi                 Calculate "percent spliced-in" (Psi) values using the
                        splicing event index built with "outrigger index"

optional arguments:
  -h, --help            show this help message and exit
  --version             show program's version number and exit

Bleeding edge code from Github (here)

For advanced users, if you have git <https://git-scm.com/>__ and Anaconda Python <https://www.continuum.io/downloads>__ installed, you can:

#. Clone this repository #. Change into that directory #. Create an environment named outrigger-env with the necessary packages from Anaconda and the Python Package Index (PyPI). #. Activate the environment

These steps are shown in code below.

::

git clone https://github.com/YeoLab/outrigger.git
cd outrigger
conda env create --file environment.yml
source activate outrigger-env

Quick start

If you just want to know how to run this on your data with the default parameters, start here. Let's say you performed your alignment in the folder called ~/projects/tasic2016/analysis/tasic2016_v1, and that's where your SJ.out.tab files from the STAR aligner are (they're output into the same folder as the .bam files). First you'll need to change directories to that folder with cd.

::

cd ~/projects/tasic2016/analysis/tasic2016_v1

Then you need find all alternative splicing events, which you do by running outrigger index on the splice junction files and the gtf. Here is an example command:

Input: .SJ.out.tab files

::

outrigger index --sj-out-tab *SJ.out.tab \
    --gtf /projects/ps-yeolab/genomes/mm10/gencode/m10/gencode.vM10.annotation.gtf

Input: .bam files

If you're using .bam files instead of SJ.out.tab files, never despair! Below is an example command. Keep in mind that for this program to work, the events must be sorted and indexed.

::

outrigger index --bam *sorted.bam \
    --gtf /projects/ps-yeolab/genomes/mm10/gencode/m10/gencode.vM10.annotation.gtf

Next, you'll want to validate that the splicing events you found follow biological rules, such as being containing GT/AG (mammalian major spliceosome) or AT/AC (mammalian minor splicesome) sequences. To do that, you'll need to provide the genome name (e.g. mm10) and the genome sequences. An example command is below:

::

outrigger validate --genome mm10 \
    --fasta /projects/ps-yeolab/genomes/mm10/GRCm38.primary_assembly.genome.fa

Finally, you can calculate percent spliced in (Psi) of your splicing events! Thankfully this is very easy:

::

outrigger psi

It should be noted that ALL of these commands should be performed in the same directory, so no moving.

Quick start summary

Here is a summary the commands in the order you would use them for outrigger!

::

cd ~/projects/tasic2016/analysis/tasic2016_v1
outrigger index --sj-out-tab *SJ.out.tab \
    --gtf /projects/ps-yeolab/genomes/mm10/gencode/m10/gencode.vM10.annotation.gtf
outrigger validate --genome mm10 \
    --fasta /projects/ps-yeolab/genomes/mm10/GRCm38.primary_assembly.genome.fa
outrigger psi

This will create a folder called outrigger_output, which at the end should look like the one below. Each file and folder is annotated with which command produced it.

::

$ tree outrigger_output
outrigger_output..........................................................index
├── index.................................................................index
│   ├── gtf...............................................................index
│   │   ├── gencode.vM10.annotation.gtf...................................index
│   │   ├── gencode.vM10.annotation.gtf.db................................index
│   │   └── novel_exons.gtf...............................................index
│   ├── exon_direction_junction_triples.csv...............................index
│   ├── mxe...............................................................index
│   │   ├── event.bed.....................................................index
│   │   ├── events.csv....................................................index
│   │   ├── exon1.bed.....................................................index
│   │   ├── exon2.bed.....................................................index
│   │   ├── exon3.bed.....................................................index
│   │   ├── exon4.bed.....................................................index
│   │   ├── intron.bed....................................................index
│   │   ├── splice_sites.csv...........................................validate
│   │   └── validated..................................................validate
│   │       └── events.csv.............................................validate
│   └── se................................................................index
│       ├── event.bed.....................................................index
│       ├── events.csv....................................................index
│       ├── exon1.bed.....................................................index
│       ├── exon2.bed.....................................................index
│       ├── exon3.bed.....................................................index
│       ├── intron.bed....................................................index
│       ├── splice_sites.csv...........................................validate
│       └── validated..................................................validate
│           └── events.csv.............................................validate
├── junctions.............................................................index
│   ├── metadata.csv......................................................index
│   └── reads.csv.........................................................index
└── psi.....................................................................psi
    ├── mxe.................................................................psi
    |   ├── psi.csv.........................................................psi
    │   └── summary.csv.....................................
