Data Compare Made Simple

data Compare is a Java-based tool for validating data consistency after replication or migration between databases. It's designed for scenarios like:

• Data migration from Oracle/DB2/MariaDB/MySQL/MSSQL to Postgres: Compare data post-migration.

• Logical replication between same or different database platforms: Validate data across platforms while minimizing database overhead.

• Active-Active replication configuration: Regularly verify data consistency to mitigate risks.

DataCompare uses hashing to compare table data efficiently. Hash values for primary keys and remaining columns are stored in a repository, reducing storage and network demands. Comparisons are processed in parallel, improving performance.

Features

• Supports Oracle, PostgreSQL, DB2, MariaDB, MySQL, and MSSQL.
• Efficient parallel comparisons using hashing.
• Handles batch processing for performance tuning.
• Stores configurations for multiple comparison projects in a central repository.

Installation

Requirements

Before initiating the build and installation process, ensure the following prerequisites are met:

1. Java 17 or later.
2. Maven 3.8 or later.
3. Postgres 15 or later (for the repository).
4. Supported JDBC drivers (DB2, Postgres, MySQL, MSSQL and Oracle currently supported).
5. Direct Postgres connections.
6. Vue3、pnpm、TypeScript、NaiveUI、Vite5、UnoCSS
7. node 20 or later
8. pnpm 9 or later

Limitations

• Date/Timestamps compared only to the second (format: DDMMYYYYHH24MISS).
• Unsupported data types: blob, long, longraw, bytea.
• Cross-platform comparison limitations with boolean type.
• Low precission types (float, real) cannot be compared to high precission types (double).

Getting Started

1. Fork && star the repository

2. Clone and Build

git clone git@github.com:WJX20/dataCompare.git
cd dataCompare
mvn clean install -U

change application.yml(redis:your password、postgresql:your password)

```run sql
run doc/datacompare.sql

```start
run DataCompareApplication


```start frontenddataCompareUI
cd dataCompareUI

```Install dependencies

pnpm install

```start
pnpm dev

```build
pnpm build

```Enter the website address in the browser.
http://localhost:9725/

```login && password

default login: admin
default password: 123456


```notice
cd dataCompareUI/package.json
I temporarily disabled simple-git-hooks and lint-staged to prevent code errors in the front-end and back-end of a single project. Therefore, I added an "_" prefix and removed .git/hooks/commit-msg and .git/hooks/pre-commit. If you need this feature, simply remove the prefix and it will be automatically generated during the commit process as .git/hooks/commit-msg and .git/hooks/pre-commit.

Reference

System

System

batch-fetch-size

Sets the fetch size for retrieving rows from the source or target database.

Default: 2000

batch-commit-size

The commit size controls the array size and number of rows concurrently inserted into the dc_source/dc_target staging tables.

Default: 2000

batch-progress-report-size

Defines the number of rows used in mod to report progress.

Default: 1000000

column-hash-method

Determines how the hash is performed. Valid values are database and hybrid. When set to database the column value hash is performed on the source/target database. For hybrid the hash is performed by the pgCompare thread.

Default: database

database-sort

Determines if the sorting of the rows based on primary key occurs on the source/target database. If set to true, the default, the rows will be sorted before being compared. If set to false, the sorting will take place in the repository database.

Default: true

float-cast

Defines how float and double data types are cast for hash function (notation|standard).

Default is notation (for scientific notation).

float-scale

Set the preferred scale used to cast low precision numbers.

Default: 3

loader-threads

Sets the number of threads to load data into the temporary tables. Set to 0 to disable loader threads.

Default: 0

log-level

Level to determine the amount of log messages written to the log destination.

Default: INFO

log-destination

Location where log messages will be written.

Default: stdout

message-queue-size

Size of message queue used by loader threads (nbr messages).

Default: 100

number-cast

Defines how numbers are cast for hash function (notation|standard). Valid values are notation for scientific notation and standard for standard number casting.

Default: notation

observer-throttle

Set to true or false, instructs the loader threads to pause and wait for the observer thread to catch up before continuing to load more data into the staging tables.

Default: true

observer-throttle-size

Number of rows loaded before the loader thread will sleep and wait for clearance from the observer thread.

Default: 2000000

observer-vacuum

Set to true or false, instructs the observer whether to perform a vacuum on the staging tables during checkpoints.

Default: true

stage-table-parallel

Default parallel degree to set on staging table.

Default: 0

standard-number-format

Format used to cast numbers

Default: 0000000000000000000000.0000000000000000000000

batch-offset-size

This configuration indicates that the first n data entries will be skipped, and the hash values will be generated starting from the (n + 1)th data entry for comparison.

Default: 0

batch-compare-size

This configuration indicates how many Hash values will be generated.

Default: 2000

"batch-offset-size" & "batch-compare-size": These two configurations are used to paginate the data for querying when generating "hash comparison". For instance, only compare the data ranging from 1001 to 2000 or from 5001 to 10000.

batch-check-size

This configuration indicates how many "check validations" are to be performed.

Default: 1000


<img width="1860" height="923" alt="login" src="https://github.com/user-attachments/assets/3ce94f66-1de6-41c0-8d5c-f7b1bc168775" /> <img width="1860" height="923" alt="home" src="https://github.com/user-attachments/assets/6787526d-022c-4d79-93d9-d558c31b545c" /> <img width="1860" height="923" alt="datasource" src="https://github.com/user-attachments/assets/6d03913c-9579-4097-86ef-e0679de51577" /> <img width="1860" height="923" alt="user" src="https://github.com/user-attachments/assets/96f1c046-52ad-4e0a-a424-53e2b90226b1" /> <img width="1860" height="923" alt="verify" src="https://github.com/user-attachments/assets/9054f2ac-5ee3-4764-95d1-bcce67e504ca" /> <img width="1860" height="923" alt="verifyConfig" src="https://github.com/user-attachments/assets/ff1b4a39-289f-46d5-af49-75dd35408ffa" /> <img width="1562" height="843" alt="verifyDetails" src="https://github.com/user-attachments/assets/de3694a2-4ef6-4ae7-98ae-e1da1d9b9c6b" /> <img width="1446" height="836" alt="verifyDiffDetails" src="https://github.com/user-attachments/assets/5e5b6889-d1f7-4559-a730-1479fa093f38" />

License

dataCompare is licensed under the Apache 2.0 license.
