FiatMon
FiatMon is a device which takes certain CAN messages from Fiat 500L CAN network using OBD2 connector and displays them on the LCD/OLED screen. Most CAN messages are captured from a broadcast stream, but few are requested/received.
Install / Use
/learn @VeryBusyBee/FiatMonREADME
FiatMon is a device which takes certain CAN messages from Fiat 500L CAN network using OBD2 connector and displays them on the LCD/OLED screen. Most CAN messages are captured from a broadcast stream, but few are requested/received.
Current version of FialMon is based on STM32F103C8T6 MCU on a BluePill board and GMG12864-06D monochrome 128x64 LCD screen with ST7565 controller.
STM32CubeIDE is used as a develoment tool.
Now FiatMon captures and displays the following parameters:
- speed
- engine coolant temperature, with alarm on values higher than 85 C
- instant fuel consumption
- fuel consumption averaged by 30 seconds
- handbrake activation
- marker lights when turned on change the display backlit brightness
FiatMon v. 0.4
- implementation of CANsniffer protocol
FiatMon v. 0.3
- screen items implemented as classes
- added a queue for CAN messages
FiatMon v. 0.2
- added support of a variable width fonts
- added alignment of text to the right
- medium and big fonts changed to Arial
