PyQtSamples

Some examples written in PyQt, the Python binding for the Qt application framework.

Each example is voluntarily minimalist and simple as possible. Their purpose is only to illustrate the use of an aspect of PyQt. In fact it's more like code templates, intended to be reused and completed (for example because of lack of errors checking). Regularly when I develop and need a PyQt feature, I use these samples as code I can copy/paste to save time.

It's very usefull so I hope this repository will help some people :)

Minimal Requirements

• Python 3.5 (personnaly I use the 3.5.2 version)
• PyQt 5.7 (some samples need also PyQtChart and/or PyQtDataVisualization and/or PyQtPurchasing)
• numpy (required in few examples)
• Qt Creator (to open .pro projects and execute them)

How to install them

You can download Python from the official site and install it.

When the installation is done, we need to install the package pip and use it to install PyQt and some submodules. To do this, open a console and write:

cd C:\Python35
python -m pip install --upgrade pip
cd C:\Python35\Scripts
pip3 install pyqt5
pip3 install PyQtChat
pip3 install PyQtPurchasing
pip3 install PyQtDataVisualization

To execute some examples (like OpenGL ones), the Numpy package is required. To install it, as above, write this:

pip3 install numpy

Finally you can download Qt Creator from here and install it.

How To Run Examples

In this repository, each subfolder represents a standalone project and you can open the corresponding .pro with Qt Creator. Then to be able to run the example, you must set the project as follow:

Build Settings

<img src="./Screenshots/qt_creator_build_settings.png" alt="Qt Creator build settings"> ## Run Settings <img src="./Screenshots/qt_creator_run_settings.png" alt="Qt Creator run settings">

Examples

QML Painted Item

<img src="./Screenshots/qml_painted_item.png" height="96px" align="right"> The Painted Item example shows how to use the QML Scene Graph framework to implement custom scenegraph items using QPainter. <br><br>

OpenGL Under QML

<img src="./Screenshots/opengl_under_qml.png" height="96px" align="right"> The OpenGL under QML example shows how an application can draw custom OpenGL content under a Qt Quick scene. <br><br>

OpenGL Under QML With FBO

<img src="./Screenshots/opengl_under_qml_fbo.png" height="96px" align="right"> The OpenGL under QML example shows how an application can draw custom OpenGL on the scene graph rendering thread. Here we use a FBO, managed and displayed using the QQuickFramebufferObject convenience class. Compare to the previous method, this one is more flexible. <br><br>

VXYModelMapper

<img src="./Screenshots/line_series.png" height="96px" align="right"> This QML example shows how to use a VXYModelMapper, to bind a QAbstractTableModel (python side) with a LineSeries (QML side). <br><br>

HXYModelMapper

<img src="./Screenshots/line_series.png" height="96px" align="right"> This QML example shows how to use a HXYModelMapper, to bind a QAbstractTableModel (python side) with a LineSeries (QML side). <br><br>

VBarModelMapper

<img src="./Screenshots/bar_series.png" height="96px" align="right"> This QML example shows how to use a VBarModelMapper, to bind a QAbstractTableModel (python side) with a BarSeries (QML side). <br><br>

HBarModelMapper

<img src="./Screenshots/bar_series.png" height="96px" align="right"> This QML example shows how to use a HBarModelMapper, to bind a QAbstractTableModel (python side) with a BarSeries (QML side). <br><br>

VPieModelMapper

<img src="./Screenshots/pie_series.png" height="96px" align="right"> This QML example shows how to use a VPieModelMapper, to bind a QAbstractTableModel (python side) with a PieSeries (QML side). <br><br>

HPieModelMapper

<img src="./Screenshots/pie_series.png" height="96px" align="right"> This QML example shows how to use a HPieModelMapper, to bind a QAbstractTableModel (python side) with a PieSeries (QML side). <br><br>

VBoxPlotModelMapper

<img src="./Screenshots/box_plot_series.png" height="96px" align="right"> This QML example shows how to use a VBoxPlotModelMapper, to bind a QAbstractTableModel (python side) with a BoxPlotSeries (QML side). <br><br>

DonutChartBreakdown

<img src="./Screenshots/donut_chart_breakdown.png" height="96px" align="right"> This QML example shows how to generate a donut chart, thanks to multiple PieSeries in a ChartView. <br><br>

Triangle Simple

<img src="./Screenshots/triangle_simple.png" height="96px" align="right"> Renders a colored triangle in a QOpenGLWindow, using a QOpenGLVertexArrayObject. <br><br>

Textured Quad

<img src="./Screenshots/fbo_texture.png" height="96px" align="right"> Renders a textured quad in a QOpenGLWindow, using a QOpenGLTexture. <br><br>

Time Monitor Overlay

<img src="./Screenshots/time_monitor_overlay.png" height="96px" align="right"> Show how to use a QOpenGLTimeMonitor object. In addition, this example shows how to render a 2D text overlay on top of an existing OpenGL scene. Here we display the QOpenGLTimeMonitor output. <br><br>

QOffscreenSurface

<img src="./Screenshots/julia.png" height="96px" align="right"> This sample shows how to use a QOffscreenSurface. We use also a QOpenGLWindow to display result of the QOffscreenSurface rendering. Here we have only one thread and two shared QOpenGLContext. <br><br>

FBO Texture

<img src="./Screenshots/fbo_texture.png" height="96px" align="right"> Renders a textured quad with an offscreen pass (using QOpenGLFramebufferObject). With a mouse click we display the framebuffer content. <br><br>

Licenses

MIT
