UIWidgets

中文

Introduction

UIWidgets is a plugin package for Unity Editor which helps developers to create, debug and deploy efficient, cross-platform Apps using the Unity Engine.

UIWidgets is mainly derived from Flutter. However, taking advantage of the powerful Unity Engine, it offers developers many new features to improve their Apps as well as the develop workflow significantly.

Efficiency

Using the latest Unity rendering SDKs, a UIWidgets App can run very fast and keep >60fps in most times.

Cross-Platform

A UIWidgets App can be deployed on all kinds of platforms including PCs, mobile devices and web page directly, like any other Unity projects.

Multimedia Support

Except for basic 2D UIs, developers are also able to include 3D Models, audios, particle-systems to their UIWidgets Apps.

Developer-Friendly

A UIWidgets App can be debug in the Unity Editor directly with many advanced tools like CPU/GPU Profiling, FPS Profiling.

Example

<div style="text-align: center"><table><tr> <td style="text-align: center"> <img src="https://connect-prd-cdn.unity.com/20190323/p/images/2a27606f-a2cc-4c9f-9e34-bb39ae64d06c_uiwidgets1.gif" width="200"/> </td> <td style="text-align: center"> <img src="https://connect-prd-cdn.unity.com/20190323/p/images/097a7c53-19b3-4e0a-ad27-8ec02506905d_uiwidgets2.gif" width="200" /> </td> <td style="text-align: center"> <img src="https://connect-prd-cdn.unity.com/20190323/p/images/1f03c1d0-758c-4dde-b3a9-2f5f7216b7d9_uiwidgets3.gif" width="200"/> </td> <td style="text-align: center"> <img src="https://connect-prd-cdn.unity.com/20190323/p/images/a8884fbd-9e7c-4bd7-af46-0947e01d01fd_uiwidgets4.gif" width="200"/> </td> </tr></table></div>

Projects using UIWidgets

Unity Connect App

The Unity Connect App is created using UIWidgets and available for both Android (https://connect.unity.com/connectApp/download) and iOS (Searching for "Unity Connect" in App Store). This project is open-sourced @https://github.com/UnityTech/ConnectAppCN.

Unity Chinese Doc

The official website of Unity Chinese Documentation (https://connect.unity.com/doc) is powered by UIWidgets and open-sourced @https://github.com/UnityTech/DocCN.

Requirements

Unity

Install Unity 2018.4.10f1 (LTS) or Unity 2019.1.14f1 and above. You can download the latest Unity on https://unity3d.com/get-unity/download.

UIWidgets Package

Visit our Github repository https://github.com/UnityTech/UIWidgets to download the latest UIWidgets package.

Move the downloaded package folder into the Package folder of your Unity project.

Generally, you can make it using a console (or terminal) application by just a few commands as below:

 cd <YourProjectPath>/Packages
 git clone https://github.com/UnityTech/UIWidgets.git com.unity.uiwidgets

Getting Start

i. Overview

In this tutorial, we will create a very simple UIWidgets App as the kick-starter. The app contains only a text label and a button. The text label will count the times of clicks upon the button.

First of all, please open or create a Unity Project and open it with Unity Editor.

And then open Project Settings, go to Player section and add "UIWidgets_DEBUG" to the Scripting Define Symbols field. This enables the debug mode of UIWidgets for your development. Remove this for your release build afterwards.

ii. Scene Build

A UIWidgets App is usually built upon a Unity UI Canvas. Please follow the steps to create a UI Canvas in Unity.

1. Create a new Scene by "File -> New Scene";
2. Create a UI Canvas in the scene by "GameObject -> UI -> Canvas";
3. Add a Panel (i.e., Panel 1) to the UI Canvas by right click on the Canvas and select "UI -> Panel". Then remove the Image Component from the Panel.

iii. Create Widget

A UIWidgets App is written in C# Scripts. Please follow the steps to create an App and play it in Unity Editor.

1. Create a new C# Script named "UIWidgetsExample.cs" and paste the following codes into it.

    using System.Collections.Generic;
    using Unity.UIWidgets.animation;
    using Unity.UIWidgets.engine;
    using Unity.UIWidgets.foundation;
    using Unity.UIWidgets.material;
    using Unity.UIWidgets.painting;
    using Unity.UIWidgets.ui;
    using Unity.UIWidgets.widgets;
    using UnityEngine;
    using FontStyle = Unity.UIWidgets.ui.FontStyle;

    namespace UIWidgetsSample {
        public class UIWidgetsExample : UIWidgetsPanel {
            protected override void OnEnable() {
                // if you want to use your own font or font icons.
                // FontManager.instance.addFont(Resources.Load<Font>(path: "path to your font"), "font family name");

                // load custom font with weight & style. The font weight & style corresponds to fontWeight, fontStyle of
                // a TextStyle object
                // FontManager.instance.addFont(Resources.Load<Font>(path: "path to your font"), "Roboto", FontWeight.w500,
                //    FontStyle.italic);

                // add material icons, familyName must be "Material Icons"
                // FontManager.instance.addFont(Resources.Load<Font>(path: "path to material icons"), "Material Icons");

                base.OnEnable();
            }

            protected override Widget createWidget() {
                return new WidgetsApp(
                    home: new ExampleApp(),
                    pageRouteBuilder: (RouteSettings settings, WidgetBuilder builder) =>
                        new PageRouteBuilder(
                            settings: settings,
                            pageBuilder: (BuildContext context, Animation<float> animation,
                                Animation<float> secondaryAnimation) => builder(context)
                        )
                );
            }

            class ExampleApp : StatefulWidget {
                public ExampleApp(Key key = null) : base(key) {
                }

                public override State createState() {
                    return new ExampleState();
                }
            }

            class ExampleState : State<ExampleApp> {
                int counter = 0;

                public override Widget build(BuildContext context) {
                    return new Column(
                        children: new List<Widget> {
                            new Text("Counter: " + this.counter),
                            new GestureDetector(
                                onTap: () => {
                                    this.setState(()
                                        => {
                                        this.counter++;
                                    });
                                },
                                child: new Container(
                                    padding: EdgeInsets.symmetric(20, 20),
                                    color: Colors.blue,
                                    child: new Text("Click Me")
                                )
                            )
                        }
                    );
                }
            }
        }
    }


2. Save this script and attach it to Panel 1 as its component.

3. Press the "Play" Button to start the App in Unity Editor.

iv. Build App

Finally, the UIWidgets App can be built to packages for any specific platform by the following steps.

1. Open the Build Settings Panel by "File -> Build Settings..."
2. Choose a target platform and click "Build". Then the Unity Editor will automatically assemble all relevant resources and generate the final App package.

How to load images?

1. Put your images files in Resources folder. e.g. image1.png.
2. You can add image1@2.png and image1@3.png in the same folder to support HD screens.
3. Use Image.asset("image1") to load the image. Note: as in Unity, ".png" is not needed.

UIWidgets supports Gif as well!

1. Suppose you have loading1.gif. Rename it to loading1.gif.bytes and copy it to Resources folder.
2. You can add loading1@2.gif.bytes and loading1@3.gif.bytes in the same folder to support HD screens.
3. Use Image.asset("loading1.gif") to load the gif images.

Using Window Scope

If you see the error AssertionError: Window.instance is null or null pointer error of Window.instance, it means the code is not running in the window scope. In this case, you can enclose your code with window scope as below:

using(WindowProvider.of(your gameObject with UIWidgetsPanel).getScope()) {
    // code dealing with UIWidgets,
    // e.g. setState(() => {....})
}

This is needed if the code is in methods not invoked by UIWidgets. For example, if the code is in completed callback of UnityWebRequest, you need to enclose them with window scope. Please see HttpRequestSample for detail. For callback/event handler methods from UIWidgets (e.g Widget.build, State.initState...), you don't need do it yourself, since the framework ensure it's in window scope.

Show Status Bar on Android

Status bar is always hidden by default when an Unity project is running on an Android device. If you want to show the status bar in your App, this solution seems to be compatible to UIWidgets, therefore can be used as a good option before we release our full support solution on this issue.

Besides, please set "Render Outside Safe Area" to true in the "Player Settings" to make this plugin working properly on Android P or later.

Automatically Adjust Frame Rate

To build an App that is able to adjust the frame rate automatically, please open Project Settin
