IPsolve – Python

A Python implementation of the interior-point solver for piecewise linear-quadratic (PLQ) composite problems, based on the JMLR paper:

Aravkin, Burke, Pillonetto. Sparse/Robust Estimation and Kalman Smoothing with Nonsmooth Log-Concave Densities: Modeling, Computation, and Theory. JMLR 14(82):2689–2728, 2013.

Quick start

cd python
pip install -e ".[test]"           # editable install with test deps
pytest                             # run 12 tests (verified vs CVXPY)

from ipsolve import solve, huber, l1, l2, hinge, qreg

# Least squares
x = solve(H, z)

# Robust regression
x = solve(H, z, meas=huber(kappa=1.0))

# Lasso
x = solve(H, z, proc=l1(lam=0.5))

# Huber + L1 (robust sparse)
x = solve(H, z, meas=huber(kappa=1.0), proc=l1(lam=0.5))

# SVM  (was: proc_mMult=1.0/lam ... now just proc=l2(lam=lam))
w = solve(yX, np.ones(m), meas=hinge(), proc=l2(lam=0.01))

# Quantile regression
x = solve(H, z, meas=qreg(tau=0.25))

# Box constraints
x = solve(H, z, bounds=(-1, 1))

What it solves

$$ \min_{x} ;; \ell^{!\top} x ;+; \rho_{\text{meas}}!\bigl(z - Hx\bigr) ;+; \rho_{\text{proc}}!\bigl(Kx - k\bigr) \quad\text{s.t.}\quad Ax \le a $$

where $\rho_{\text{meas}}$ and $\rho_{\text{proc}}$ are PLQ penalties (ℓ₁, ℓ₂, Huber, hinge, quantile, Vapnik, …) represented in their conjugate/dual form via matrices $(M, B, C, c, b)$.

The solver uses a barrier interior-point method with Schur-complement elimination and optional Mehrotra predictor-corrector.

Design

| Module | Purpose | |--------|---------| | ipsolve.plq | PLQ dataclass, compose(), ensure_sparse helpers | | ipsolve.penalties | Penalty library (10 penalties -- see table below) | | ipsolve.kkt | SchurOperator for mat-vec/dense Schur complement; KKT residual & solve | | ipsolve.solver | Interior-point loop with extracted _max_step / _armijo_search helpers | | ipsolve.api | High-level solve(H, z, meas, proc, ...) entry point |

Penalties

Each penalty is a factory function. Call without a dimension for solve():

meas=huber(kappa=1.0)   # lazy spec -- dimension filled in by solve()
proc=l1(lam=0.5)

Call with a dimension to get the raw PLQ object:

plq = huber(100, kappa=1.0)   # returns PLQ directly

| Name | Formula | Key parameter | |------|---------|---------------| | l2 | (lam/2) \|v\|^2 | lam (or mMult) | | l1 | lam * \|v\|_1 | lam | | huber | Huber loss | kappa | | hinge | lam * sum pos(v) | lam | | vapnik | lam * sum max(\|v\| - eps, 0) | lam, eps | | qreg | check / pinball loss | tau, lam | | qhuber | quantile Huber (smooth quantile) | tau, kappa | | infnorm | lam * \|v\|_inf | lam | | logreg | sum log(1 + exp(v)) | alpha | | hybrid | sum(sqrt(1 + v^2/s) - 1) | scale |

Examples

All examples produce figures saved to figures/. Run from the repo root:

python examples/lasso.py
python examples/robust_regression.py
python examples/svm.py
python examples/huber_l1.py
python examples/quantile_regression.py
python examples/cvar_portfolio.py
python examples/infnorm.py
python examples/kalman_demo.py

| Example | Description | MATLAB equivalent | |---------|-------------|-------------------| | lasso.py | Sparse signal recovery via ℓ₂ + ℓ₁ | lassoAndEnet.m | | robust_regression.py | Huber loss vs LS with outliers | RobustRegression.m | | svm.py | Binary classification with hinge + ℓ₂ | SVMdemo.m | | huber_l1.py | Robust sparse regression, verified vs CVXPY | HuberL1Example.m | | quantile_regression.py | Multi-quantile curves with pinball loss | — | | cvar_portfolio.py | CVaR portfolio with simplex constraints | CvarDemo.m | | infnorm.py | ℓ∞-norm regularisation (simplex dual) | infNorm.m | | kalman_demo.py | Kalman smoothing: LS, robust, constrained | KalmanDemo.m |

Tests

12 tests verify all penalties against CVXPY ground truth:

pytest -v

Tests cover: ℓ₂, Huber, lasso, Huber+ℓ₁, SVM, ℓ₁ fitting, quantile regression, ℓ₁+ℓ₁, Vapnik, box constraints, ℓ∞ norm, and Kalman smoothing.

Future work

Nonlinear extension -- Gauss-Newton outer loop for rho(F(x)) where F is nonlinear
Logistic regression / hybrid examples

Inexact (CG) Schur solve

The SchurOperator class in kkt.py encapsulates the Schur complement Omega = B' T^{-1} B as either a dense matrix (for direct LU) or a matrix-free LinearOperator (for conjugate-gradient).

Pass inexact=True to solve() to use the CG path. This avoids forming and factoring the dense (N x N) Schur complement, reducing memory from O(N^2) to O(nnz) and scaling better for overdetermined problems (m >> n).

Scaling benchmark

python benchmarks/scaling_demo.py

Part 1 — Direct (LU) vs CG comparison

Lasso (ℓ₂ + ℓ₁, underdetermined m < n):

| m | n | Direct (s) | IP | CG | CG (s) | IP | CG | Rel diff | |---|---|-----------|---|---|--------|---|---|----------| | 100 | 200 | 0.08 | 17 | 0 | 0.22 | 17 | 1960 | 3.4e-8 | | 200 | 500 | 0.66 | 20 | 0 | 1.15 | 20 | 4588 | 6.9e-8 | | 500 | 1000 | 3.89 | 20 | 0 | 5.26 | 20 | 4499 | 5.1e-5 |

Huber regression (overdetermined m ≫ n) — CG wins:

| m | n | Direct (s) | IP | CG | CG (s) | IP | CG | Speedup | Rel diff | |---|---|-----------|---|---|--------|---|---|---------|----------| | 500 | 200 | 0.09 | 10 | 0 | 0.08 | 10 | 233 | 1.2× | 4.5e-9 | | 1000 | 500 | 1.09 | 13 | 0 | 0.55 | 13 | 413 | 2.0× | 1.7e-9 | | 2000 | 1000 | 10.14 | 16 | 0 | 2.84 | 16 | 522 | 3.6× | 5.4e-10 |

Part 2 — CG-only scaling (large problems)

Lasso (CG-only):

| m | n | Time (s) | IP iters | CG iters | Objective | |---|---|---------|---------|---------|-----------| | 500 | 1000 | 5.4 | 20 | 4499 | 24.59 | | 1000 | 2000 | 29.4 | 23 | 6209 | 45.15 | | 2000 | 5000 | 369.5 | 36 | 16221 | 120.27 |

Huber (CG-only):

| m | n | Time (s) | IP iters | CG iters | |---|---|---------|---------|---------| | 2000 | 1000 | 2.5 | 16 | 522 | | 5000 | 2000 | 9.0 | 14 | 351 | | 10000 | 5000 | 70.6 | 16 | 536 |
