👑 Welcome to the RoyalMD

✨ Click on the image to watch the video in 4K:

🧬 QUICK LAUNCH

python ./RoyalMD.py ./test_systems/short_and_flexible.pdb

🔭 Overview

RoyalMD is a lightweight, educational molecular dynamics pipeline built on OpenMM, designed to run protein simulations on portable hardware. It automates on the fly common MD setup steps: from PDB fixing to solvation, minimization, multi-step equilibration and production runs, with a single command-line interface. The current version allows running molecular dynamics of any molecular system composed of proteins, nucleic acids and their complexes. It automatically detects your hardware and uses GPU if available.

👤 Author

This script was developed and benchmarked by Gleb Novikov

✨ Features

• Automatic PDB fixing (missing atoms, residues, protonation via pdbfixer)
• Flexible force field selection for protein & water models (AMBER, CHARMM36)
• Solvation and ion placement with configurable box geometry
• Support for three-site (TIP3P) and four-site water models
• Energy minimization and multi-step NPT equilibration
• Production MD runs with benchmark-ready logging
• Cross-platform optimization with GPU detection

---

🪄 Requirements

• Python 3.12
• OpenMM
• pdbfixer
• mdtraj (for saving MD trajectories in the NetCDF format)

conda create -n MDsims python=3.12
conda activate MDsims
conda install -c conda-forge openmm pdbfixer mdtraj
conda install -c conda-forge "numpy<2.0" # <<< if you have any numpy-related errors"

⚜️ Usage Examples

# Short peptide devived from 3CL protease (PDB: 6LU7):
python ./RoyalMD.py ./test_systems/short_and_flexible.pdb

# Open-state calmodulin bound to 4 calcium ions (PDB: 1CLL):
python ./RoyalMD.py ./test_systems/calmodulin_open.pdb

# Protein-Nucleic Acid complex (RNase H, PDB: 2QKB):
python ./RoyalMD.py ./test_systems/DNA_RNA_prot.pdb

# Nucleosome (Histone octamer core wrapped by DNA, PDB: 1KX5):
python ./RoyalMD.py ./test_systems/nucleosome.pdb

# BIG SYSTEMS --> protein-protein complexes:
# MraZ octamer bound to a DNA promoter (PDB: 9SX6):
python ./RoyalMD.py ./test_systems/MraZ_DNA.pdb

# Immunoglobulin (PDB: 1IGT):
python ./RoyalMD.py ./test_systems/antibody.pdb

⚙️ Configuration

Customize these variables in the MAIN function of the script.

 # --- CONFIGURATION ---
 input_pdb = sys.argv[1]
    pre_sim_pdb = 'solvated.pdb'
    output_nc = 'production.nc'
    timestep = 0.002
    equil_time = 200 # 200ps of NPT equilibration (after 100ps of heating)
    production_time = 1000 # 1 ns of production
    report_interval = 1500 # report info every 1500 steps
    log_freq = 10
    # conditions
    temperature = 310
    pressure = 1.0
    # box and solvation: dodecahedron or octahedron
    box_type = 'dodecahedron'
    box_padding = 1.0 # if temperature fluctuates (with very flexible systems), increase it to 1.5
    ionic_strength = 0.15
    env_pH = 7.0
    # main params
    ff_protein = 'amber14' # NB: use amber14 with tip3p water
    ff_water = 'tip3p' # tip3p - with amber14/ amber99; opc - with amber19; water - with charmm36
    ligands_to_remove = ['SO4','HOH', 'EDO', 'LIH', 'LIG'] # .. add more from your PDBs

🌀 Supported force fields and water models

#Customize these variables in the MAIN function of the script.
  ff_map = {
        'amber19': 'amber19-all.xml', # with OPC (4 point water model)
        'amber14': 'amber14-all.xml', # with TIP3P (3 point water model)
        'amber99sb': 'amber99sb.xml', # with TIP3P water
        'amber99sbildn': 'amber99sbildn.xml', # with TIP3P water
        'amber03': 'amber03.xml', # with TIP3P water
        'charmm36': 'charmm36.xml' # with "water" (TIP3P water for CHARMM)
    }
