Quest2ROS2

A framework for using Meta Quest 2/3 VR controllers to teleoperate a robot system through ROS2 and ROS–TCP communication. Built based on Quest2ROS.
Accepted to HRI 2026, see paper here.

https://github.com/user-attachments/assets/f153b410-1828-4f67-8ec8-fc7ae9254131

System Requirements

Operating Systems

• Ubuntu 22.04 LTS

ROS Version

• ROS2 Humble

VR Hardware

• Meta Quest 2 / Quest 3 headset with hand controllers

Prerequisites

• The robot must have a ROS2 controller that supports Cartesian end-effector position control.

Setup and Configuration

1. For the VR device, install and configure the quest2ros app on your VR headset. Follow instructions at: Quest2ROS

2. On PC side, install ROS2 Humble on Ubuntu: https://docs.ros.org/en/humble/Installation.html, make sure to install Python modules numpy and tf_transformation.

3. Assume the workspace path is workspace, go to workspace/src, clone this project with git clone https://github.com/Taokt/Quest2ROS2.git

4. NOTE: The upstream ROS–TCP–Endpoint repository is not fully compatible with our current implementation. To avoid manual patching and reproduction issues, please use our maintained package ros_tcp_communication instead.

   Under workspace/src, install & build:

   git clone https://github.com/guguroro/ros_tcp_communication.git

   cd ..

   colcon build --packages-select ros_tcp_communication

   source install/setup.bash

   In ros_tcp_communication/launch/endpoint.py, update the ROS_IP variable in the launch file from the default "0.0.0.0" to match your robot's actual IP address.

5. The Quest2ROS application only looking for ros2 message with the specific package name quest2ros, therefore one would have to create a seperate package for the the custom messages definitions. Under /src, create a new ROS2 package as

   ros2 pkg create --build-type ament_cmake quest2ros


   This command generates an empty package named quest2ros. Then copy the corrsponding required files into the newly created package:

   Under /src, do

   cp -r Quest2ROS2/Files_for_msg_pkg/* quest2ros/


6. Configure this project:

   All robot-specific parameters are explicitly exposed in left_arm_controller.py and right_arm_controller.py. Users should modify the constructor arguments in these two files to match their robot setup.

   The key parameters to customize include:

   • robot_name: your robot type or model name (e.g. kuka)
   • arm_name: arm identifier (e.g. left or right)
   • base_frame_id: root reference frame of the robot (e.g. bh_robot_base)
   • end_effector_link_name: end-effector link name for each arm
   • ctrl_prefix: namespace of the arm inverse kinematics controller
   • gripper_action_topic: action server topic for gripper control
   • filter_window_size: moving average filter size for motion smoothing
   • mirror: whether to mirror controller input between two arms, note this flag has to be the same for both left_arm_controller.py and right_arm_controller.py.

7. Build your ROS2 Humble workspace:

   colcon build
   source install/setup.bash


8. Quick varify: One way to varify the success building of Quest2ROS2 package is to try run VR input simulator inclueded in file SimulationInput.py. It publishes simulated Quest controller data at 30 Hz, including button states, hand pose and velocity. Try it with:

   ros2 run q2r2_bringup SimulationInput


   Optional modes:

   # Simulate LEFT Hand:
   ros2 run q2r2_bringup SimulationInput --ros-args -p side:=left

   # Simulate Only Velocity (Twist) Mode:
   ros2 run q2r2_bringup SimulationInput --ros-args -p mode:=velocity

   # Simulate Left Hand with Only Teleop Data (Pose + Inputs):
   ros2 run q2r2_bringup SimulationInput --ros-args -p side:=left -p mode:=teleop


   If you can see the topics publishing (e.g., via ros2 topic list or ros2 topic echo), you can proceed to the next step.

9. Launch ROS–TCP Endpoint

   ros2 launch ros_tcp_endpoint endpoint.py


10. Configure the connection in the Quest2ROS app on the VR device.

    On your VR headset, open the Quest2ROS app, set your robot’s IP address (<YOUR_IP>) and the same port number as defined in endpoint.py, then press Apply to confirm.

11. Run CheckTCPconnection

    To verify VR → ROS2 communication:

    ros2 run q2r2_bringup CheckTCPconnection

    This node subscribes to all Quest topics for both hands and all message types:

    • /q2r_left_hand_pose
    • /q2r_left_hand_inputs
    • /q2r_left_hand_twist
    • /q2r_right_hand_pose
    • /q2r_right_hand_inputs
    • /q2r_right_hand_twist

    If the connection is working, it prints the latest received values every second (pose / inputs / twist).

    If no messages are received more than 2 seconds, it reports a timeout.

12. Run left_arm_controller.py and right_arm_controller.py

    Running the code, move the handle to control the movement of the robotic arm

    ros2 run q2r2_bringup left_arm_controller
    ros2 run q2r2_bringup right_arm_controller


Running and Interaction

Start your robot hardware, RViz, and controller.

Ensure your physical robot, RViz visualization, and motion controller are all running.

Expected Output

• RViz visualization of dual-arm robot.

• Real-time motion following VR hand controllers.

Button functions

• Upper Button : Toggles gripper state (each press switchs between open and close).

• Lower Button : Toggles the robot arm movement (each press switches between enable and disable), and also pauses/resumes pose streaming while performing an Anchor Reset that snaps the virtual target back to the robot’s current position to prevent movement jumps due to kinematic limits or drift.
