StereoNinjaFPGA

Experimental FPGA project for streaming two MIPI CSI camera IMX219 streams to an HDMI monitor using a ULX3S FPGA board

Todos

• [x] HDMI Stream 640x480 60FPS
• [x] HDMI Stream 800x600 60 FPS
• [x] HDMI Stream 1280x720 60 FPS
• [ ] HDMI Stream 1920x1080 60FP -not possible
• [x] Initialisation Videostream IMX219 at 916Mbit/s per Lane
• [x] MIPI SoT Decoding
• [x] MIPI Syncbyte Decoding
• [x] MIPI Header Decoding
• [x] MIPI Protocoll Decoding
• [x] Writing MIPI Videostream in Dualport Ram
• [x] Passthrough IMX219 to HDMI at 640x480 Pixel in greyscale
• [x] Debayering for Colors -works partially
• [ ] Testing IMX219 at other Resolutions
• [ ] Testing Design with two Cameras
• [ ] Creating Side-by-Side(Half) HDMI 3D Output at 1280x720

• /DOCS_ULX3S Some Documentations for used Hardware and Protocoll Spezifications
• /ULX3S_ninja PCB for Adapterboard
• /old Some old Projects for Testing
• /src Source Code for StereoninjaFPGA
