IAMOVPN

Administrate OpenVPN user and connections with Web UI in single server.

Feature

• OpenVPN auto-setup
• User management dashboard

How it work

OpenVPN server have provide management terminal and callback scripts when client event occured. In this project, use below commands and callbacks.

• kill cn: Force disconnect user
• auth-user-pass-verify: User auth
• client-connect: connection log
• client-disconnect: disconnection log

Tested on

Tested only Ubuntu 18.04, so it can be broken other version of Linux.

Requirement

• Stable Linux distribution which support IPv4 forwarding like Ubuntu or Debian.
• Two open ports which can accessed by Internet IP. One port for OpenVPN, the other for WebUI.
• Not configured OpenVPN
• Python3
• NodeJS(>= 8.x)

Installation

1. Make sure requirements were installed

   # apt install git python3 python3-pip openvpn npm


2. Clone the project

   $ git clone https://github.com/StdCarrot/iamovpn.git
   $ cd iamovpn


3. Setup config

   $ cp config.json.dist config.json


   You must change secret and openvpn.host.

   If you want to set custom route, append subnet information like below to openvpn.routes:

   {
     "network": "172.16.0.0",
     "netmask": "255.255.255.0"
   }


   If you set openvpn.redirect_gateway as false, Internet traffic will not pass through VPN.

4. (Optional) Prepare database
   Create user and database and make db connection url and set it db_url in config.json.
   See also: https://docs.sqlalchemy.org/en/13/faq/connections.html

5. (Optional) Init virtualenv

   # apt install virtualenv
   $ virtualenv -p python3 env
   $ source env/bin/activate


6. Install python libraries

   $ pip3 install -r requirements.txt


7. Install IAMOVPN with root permission In this process, you may enter information to generate RSA keys.

   # python3 iamovpn install --config <path/to/config.json>


   If you use virtualenv, follow this:

   # <path/to/env>/bin/python3 iamovpn install --config <path/to/config.json>


8. (Optional) Build reverse proxy with nginx or apache2. And all tsl layer for https.
   See also: https://certbot.eff.org/instructions

   If you build reverse proxy, MUST check /etc/openvpn/scripts/util.py.
   You may modify api_host's port information.

9. Start server.

   # systemctl restart openvpn@server
   $ python3 iamovpn run standalone --config <path/to/config.json>


   You can use gunicorn or uWSGI to serving and also register as service.

10. Open Web UI In browser, go http://<yout host ip>/
    Login default account:

    • ID: admin
    • Password: need2change

    MUST change password as soon as possible.

Warning

IAMOVPN api server MUST BE RUN while using vpn.
User authorization and connection logging uses apis.

Road map

• Force disconnect client
• Server utilization view
• Docker compose
