Hey! All the energy and improvements in this project are going into SolidPython V2. Check it out at Github <https://github.com/jeff-dh/SolidPython>_ or on its PyPI page <https://pypi.org/project/solidpython2/>_ before you commit to an older version.

SolidPython

.. image:: https://github.com/SolidCode/SolidPython/actions/workflows/ci.yml/badge.svg :target: https://github.com/SolidCode/SolidPython/actions/workflows/ci.yml .. image:: https://readthedocs.org/projects/solidpython/badge/?version=latest :target: http://solidpython.readthedocs.io/en/latest/?badge=latest :alt: Documentation Status

• SolidPython: OpenSCAD for Python <#solidpython--openscad-for-python>__

• Advantages <#advantages>__

• Installing SolidPython <#installing-solidpython>__

• Using SolidPython <#using-solidpython>__

• Importing OpenSCAD Code <#importing-openscad-code>__

• Example Code <#example-code>__

• Extra syntactic sugar <#extra-syntactic-sugar>__

  • Basic operators <#basic-operators>__
  • First-class Negative Space (Holes) <#first-class-negative-space-holes>__
  • Animation <#animation>__

• solid.utils <#solidutils>__

  • Directions: (up, down, left, right, forward, back) for arranging things: <#directions-up-down-left-right-forward-back-for-arranging-things>__
  • Arcs <#arcs>__
  • Extrude Along Path <#extrude_along_path>__
  • Bill Of Materials <#bill-of-materials>__

• solid.screw\_thread <#solidscrew_thread>__

• solid.splines <#solidsplines>__

• Jupyter Renderer <#jupyter-renderer>__

• Contact <#contact>__

• License <#license>__

SolidPython: OpenSCAD for Python

SolidPython is a generalization of Phillip Tiefenbacher's openscad module, found on Thingiverse <http://www.thingiverse.com/thing:1481>__. It generates valid OpenSCAD code from Python code with minimal overhead. Here's a simple example:

This Python code:

.. code:: python

from solid import *
d = difference()(
    cube(10),
    sphere(15)
)
print(scad_render(d))

Generates this OpenSCAD code:

.. code:: python

difference(){
    cube(10);
    sphere(15);
}

That doesn't seem like such a savings, but the following SolidPython code is a lot shorter (and I think clearer) than the SCAD code it compiles to:

.. code:: python

from solid import *
from solid.utils import *
d = cube(5) + right(5)(sphere(5)) - cylinder(r=2, h=6)

Generates this OpenSCAD code:

.. code::

difference(){
    union(){
        cube(5);
        translate( [5, 0,0]){
            sphere(5);
        }
    }
    cylinder(r=2, h=6);
}

Advantages

Because you're using Python, a lot of things are easy that would be hard or impossible in pure OpenSCAD. Among these are:

• built-in dictionary types
• mutable, slice-able list and string types
• recursion
• external libraries (images! 3D geometry! web-scraping! ...)

Installing SolidPython

• Install latest release via PyPI <https://pypi.python.org/pypi/solidpython>__:

  .. code:: bash

  pip install solidpython


  (You may need to use sudo pip install solidpython, depending on your environment. This is commonly discouraged though. You'll be happiest working in a virtual environment <https://docs.python.org/3/tutorial/venv.html>__ where you can easily control dependencies for a given project)

• Install current master straight from Github:

  .. code:: bash

  pip install git+https://github.com/SolidCode/SolidPython.git


Using SolidPython

• Include SolidPython at the top of your Python file:

  .. code:: python

  from solid import *
  from solid.utils import *  # Not required, but the utils module is useful


  (See this issue <https://github.com/SolidCode/SolidPython/issues/114>__ for a discussion of other import styles)

• OpenSCAD uses curly-brace blocks ({}) to create its tree. SolidPython uses parentheses with comma-delimited lists.

  OpenSCAD:

  .. code::

  difference(){
      cube(10);
      sphere(15);
  }


  SolidPython:

  .. code::

  d = difference()(
      cube(10),  # Note the comma between each element!
      sphere(15)
  )


• Call scad_render(py_scad_obj) to generate SCAD code. This returns a string of valid OpenSCAD code.

• or: call scad_render_to_file(py_scad_obj, filepath.scad) to store that code in a file.

• If filepath.scad is open in the OpenSCAD IDE and Design => 'Automatic Reload and Compile' is checked in the OpenSCAD IDE, running scad_render_to_file() from Python will load the object in the IDE.

• Alternately, you could call OpenSCAD's command line and render straight to STL.

Importing OpenSCAD code

• Use solid.import_scad(path) to import OpenSCAD code. Relative paths will check the current location designated in OpenSCAD library directories <https://en.wikibooks.org/wiki/OpenSCAD_User_Manual/Libraries>__.

Ex:

scadfile.scad

.. code::

module box(w,h,d){
    cube([w,h,d]);
}

your_file.py

.. code:: python

from solid import *

scadfile = import_scad('/path/to/scadfile.scad')
b = scadfile.box(2,4,6)
scad_render_to_file(b, 'out_file.scad')

• Recursively import OpenSCAD code by calling import_scad() with a directory argument.

.. code:: python

from solid import *

# MCAD is OpenSCAD's most common utility library: https://github.com/openscad/MCAD
# If it's installed for OpenSCAD (on MacOS, at: ``$HOME/Documents/OpenSCAD/libraries``)
mcad = import_scad('MCAD')

# MCAD contains about 15 separate packages, each included as its own namespace
print(dir(mcad)) # => ['bearing', 'bitmap', 'boxes', etc...]
mount = mcad.motors.stepper_motor_mount(nema_standard=17)
scad_render_to_file(mount, 'motor_mount_file.scad')

• OpenSCAD has the use() and include() statements for importing SCAD code, and SolidPython has them, too. They pollute the global namespace, though, and you may have better luck with import_scad(),

Ex:

scadfile.scad

.. code::

module box(w,h,d){
    cube([w,h,d]);
}

your_file.py

.. code:: python

from solid import *

# use() puts the module `box()` into the global namespace
use('/path/to/scadfile.scad')
b = box(2,4,6)
scad_render_to_file(b, 'out_file.scad')

Example Code

The best way to learn how SolidPython works is to look at the included example code. If you've installed SolidPython, the following line of Python will print(the location of ) the examples directory:

.. code:: python

import os, solid; print(os.path.dirname(solid.__file__) + '/examples')


Or browse the example code on Github here <https://github.com/SolidCode/SolidPython/tree/master/solid/examples>__

Adding your own code to the example file solid/examples/solidpython_template.py <https://github.com/SolidCode/SolidPython/blob/master/solid/examples/solidpython_template.py>__ will make some of the setup easier.

Extra syntactic sugar

Basic operators

Following Elmo Mäntynen's suggestion, SCAD objects override the basic operators + (union), - (difference), and * (intersection). So

.. code:: python

c = cylinder(r=10, h=5) + cylinder(r=2, h=30)

is the same as:

.. code:: python

c = union()(
    cylinder(r=10, h=5),
    cylinder(r=2, h=30)
)

Likewise:

.. code:: python

c = cylinder(r=10, h=5)
c -= cylinder(r=2, h=30)

is the same as:

.. code:: python

c = difference()(
    cylinder(r=10, h=5),
    cylinder(r=2, h=30)
)

First-class Negative Space (Holes)

OpenSCAD requires you to be very careful with the order in which you add or subtract objects. SolidPython's hole() function makes this process easier.

Consider making a joint where two pipes come together. In OpenSCAD you need to make two cylinders, union them, then make two smaller cylinders, union them, then subtract the smaller from the larger.

Using hole(), you can make a pipe, specify that its center should remain open, and then add two pipes together knowing that the central void area will stay empty no matter what other objects are added to that structure.

Example:

.. code:: python

outer = cylinder(r=pipe_od, h=seg_length)
inner = cylinder(r=pipe_id, h=seg_length)
pipe_a = outer - hole()(inner)

Once you've made something a hole, eventually you'll want to put something, like a bolt, into it. To do this, we need to specify that there's a given 'part' with a hole and that other parts may occupy the space in that hole. This is done with the part() function.

See solid/examples/hole_example.py <https://github.com/SolidCode/SolidPython/blob/master/solid/examples/hole_example.py>__ for the complete picture.

Animation

OpenSCAD has a special variable, $t, that can be used to animate motion. SolidPython can do this, too, using the special function scad_render_animated_file().

See solid/examples/animation_example.py <https://github.com/SolidCode/SolidPython/blob/master/solid/examples/animation_example.py>__ for more details.

solid.utils

SolidPython includes a number of useful functions in solid/utils.py <https://github.com/SolidCode/SolidPython/blob/master/solid/utils.py>__. Currently these include:

Directions: (up, down, left, right, forward, back) for arranging things:

.. code:: python

up(10)(
    cylinder()
)

seems a lot clearer to me than:

.. code:: python

translate( [0,0,10])(
    cylinder()
)

| I took this from someone's SCAD work and have lost track of the original aut
