Nim-Julia bridge

Prerequisite

• Install Julia version 1.5.3 or above. Version 1.6.6 or above is recommended.
• julia executable must be in your path.
  • By-default, nimjl will use Julia's Sys.BINDIR parent directory as the installation folder of Julia.
  • If you want nimjl to use a specific Julia installation, set the environment variable JULIA_PATH to the root of the installation folder.
• Run nimble install or nimble develop

After this steps, $JULIA_PATH/include should points to Julia header and $JULIA_PATH/lib should point to libjulia.so

You can also install Julia locally by running nimble install julia, in that case it will install Julia in the third_party folder

Ressources

How to embed Julia w/ C :

• https://docs.julialang.org/en/v1/manual/embedding/index.html#Working-with-Arrays-1

• https://github.com/JuliaLang/julia/tree/master/test/embedding

• Read the Scinim getting-started chapter on Nimjl

• legacy/ folder contains previous experiment and examples of wrapping in C.

• tests/testfull.nim is thet test suite

• examples/ contains several examples

Next steps

Julia is mostly oriented towards numerical computing so Arrays are THE most important data structure to support

In-progress

Mostly quality-of-life improvements, especially when handling arrays.

• Improve Julia Arrays interop. from Nim.
  • Supports complex Arrays
  • map / apply / reduce /fold

Backlog

• Support Julia chaining syntax
• Add support for Enum types

Limitations

• Avoid using global scope for Julia function call. Always have everything inse proc / func. It's good practice anyway

• Value conversion Nim -> Julia are done by copy.

  • Arrays are an exception to this rule and can be created from buffer / are accessible using a buffer.

• Value conversion Julia -> Nim s always done by copy

  • When using Arrays you can access the buffer as ptr UncheckedArray of the Julia Arrays with rawData().
  • Using to(seq[T]) or to(Tensor[T]) perform a copyMem of jlArray.rawData() in your seq/Tensor

• Julia allocated arrays only goes up to 3 dimensions (but Arrays can be allocated in Nim)

• Linux / WSL supports only

  • Windows dynamic library linking is different than Linux.
  • If you need Windows support, consider opening an issue or a PR :).
  • Otherwise, just use WSL

Examples & tips

Examples

Here is the basic example:

import nimjl
proc main() =
 Julia.init() # Initialize Julia VM. Subsequent call will be ignored

 var myval = 4.0'f64
 # Call Julia function "sqrt" and convert the result to a float
 var res = Julia.sqrt(myval).to(float64)
 echo res # 2.0

when isMainModule:
  main()

JlVmExit() seems optionnal. It's present in the C API but not calling it doesn't seem to cause any problem.

Nonetheless, if you use OS resources from Julia it is probably better to call Julia.exit() / JlVmExit() for a clean exit.

System Images (v0.9.0+)

For faster startup times, you can create and load precompiled Julia system images:

import nimjl/sysimage

# Create a system image with packages and code
createAppSysImage(
  "myapp.so",
  packages = ["DataFrames", "Plots"],
  sourceFiles = ["init.jl"],
  sourceDirs = ["src/"]  # Includes all .jl files recursively
)

# Initialize Julia with the custom image
initWithSysImage("myapp.so")

System images eliminate recompilation overhead and allow distributing precompiled binaries.

Error Handling (v0.9.0+)

Enhanced error messages with Julia stack traces in debug mode:

try:
  discard Julia.myFunction(42)
except JlError as e:
  echo "Julia error: ", e.msg  # Includes context and stack trace
except JlInitError as e:
  echo "VM not initialized: ", e.msg

Setting up Julia dependency

• It is now possible to embed Julia files inside a Nim compiled binary to easily distribute Julia code. To make distribution possible, an API to call Pkg.add("...") has also been added with version number easy to specify.

import nimjl

Julia.init:
  Pkg:
    add(name="Polynomials", version="3.0.0")
    add(name="LinearAlgebra")
    add("DSP")
    add(name="Wavelets", version="0.9.4")

  Embed:
    # embed all files with '*.jl' extension in folder ``JuliaToolBox/``
    dir("JuliaToolBox/")
    # embed all files with '*.jl' extension in the folder of he source file (at compilation) i.e. ``getProjectPath()``
    thisDir()
    # embed specific file; path should be relative to ``getProjectPath()``
    file("localfile.jl")

Note that the order of the file matters. See examples/ex09_embed_file.nim for a concrete example.

Take a look at tests/ or examples/ folder for typical examples.

• You can use Pkg: activate() to setup a virtual env
  • Alternatively, you can embed a Julia file that setup your environment and dependencies and embed it first.
  • Because files are evaluated in the order they are embedded, it will deterine the env for all the other files.

Cross-Compilation

nimjl supports cross-compilation for scenarios where you need to compile for a different architecture than your host machine (e.g., compiling on x86_64 for ARM64, or on macOS for Linux).

Prerequisites

Important: Cross-compilation requires the target architecture Julia libraries to be available on your build machine. You must specify the path using either:

• The -d:JuliaPath="/path/to/target-julia" compile flag, OR
• The JULIA_PATH environment variable

Usage

Enable cross-compilation mode by adding the -d:nimjl_cross_compile flag:

# Using compile flag (recommended for explicit control)
nim c -d:nimjl_cross_compile \
     -d:JuliaPath="/path/to/arm64-julia" \
     --cpu:arm64 --os:linux \
     myapp.nim

# Using environment variable
export JULIA_PATH=/path/to/arm64-julia
nim c -d:nimjl_cross_compile --cpu:arm64 --os:linux myapp.nim

How It Works

Normal Mode (default):

• Queries the Julia binary at compile time: julia -E VERSION
• Most reliable, but requires Julia to be installed and runnable on the host
• Auto-detects Julia from julia in PATH if not specified

Cross-Compilation Mode (-d:nimjl_cross_compile):

• Extracts Julia version from the library filename instead
• macOS: libjulia.1.11.7.dylib → version 1.11.7
• Linux: libjulia.so.1.11.7 → version 1.11.7
• Allows compilation when target Julia binary isn't runnable on host
• Requires explicit path via -d:JuliaPath or JULIA_PATH environment variable

Example: Compiling for ARM64 Linux from x86_64 macOS

# Install ARM64 Julia libraries in a known location
export JULIA_PATH=/path/to/arm64-julia

# Cross-compile with Nim
nim c -d:nimjl_cross_compile \
     --cpu:arm64 \
     --os:linux \
     -d:JuliaPath="/path/to/arm64-julia" \
     myapp.nim

Validation

To validate cross-compilation worked correctly:

1. Check library dependencies:

   # On Linux:
   ldd myapp | grep julia
   # On macOS:
   otool -L myapp | grep julia


   Should show paths to the correct Julia libraries

2. Verify architecture:

   # On Linux:
   file myapp
   # On macOS:
   lipo -info myapp


   Should show the target architecture (e.g., ARM64, x86_64)

3. Check embedded version:

   strings myapp | grep "Nimjl> Using"


   Should show the Julia version extracted from the library

4. Runtime test: Transfer the binary to the target platform and run it. If Julia initialization succeeds, the cross-compilation worked correctly.

Debugging

• Most error will come from incorrect type passed between Julia and Nim. Check function interface and return type first.

• If you have random segfault that are non-reproductible, that may be a cause of the Julia GC cleaning memory that Nim uses. Consider using jlGcRoot.

• If you do not work with fixed version package for Julia, you are at risk of code breaking when packages are updated / upgraded.

License

This project is released under MIT License.
