StepServo
A single channel step/direction/enable/endstop to DC quadrature encoder converter. Uses an L298N DC motor driver stacked on standoffs as a driver, and an Arduino Pro Micro as a processor. A single channel version of my other board, RAMPSSB.
Install / Use
/learn @SZiv/StepServoREADME
StepServo
Check out the wiki here: http://reprap.org/wiki/StepServo (under construction)
A single channel step/direction/enable/endstop to DC quadrature encoder converter for use with 3D printers or CNC machines. So, basically, a single channel version of my other board, RAMPSSB (https://github.com/SZiv/RAMPSSB), and many of the rules that apply there, apply here. The firmware is identical.
Uses an L298N DC motor driver stacked on standoffs as a driver, and an Arduino Pro Micro as a processor. Designed to need only an arduino Pro Micro, a L298N, some standoffs, an LED, a resistor, a 3mm terminal block, and a bunch of header. Can be assembled easily on your own.
