SOAR

<div align="center"> <h1> <img src="assets/imgs/logo.svg" width="35" height="35" /> SOAR </h1> </h1> <h2>Simultaneous Exploration and Photographing with Heterogeneous UAVs for Fast Autonomous Reconstruction</h2> <strong>IROS 2024 Oral</strong> <br> <a href="https://zager-zhang.github.io" target="_blank">Mingjie Zhang</a>^1,3,*, <a href="https://chen-albert-feng.github.io/AlbertFeng.github.io" target="_blank">Chen Feng</a>^2,*, <a href="https://robotics-star.com/people" target="_blank">Zengzhi Li</a>^1,4, <a href="https://robotics-star.com/people" target="_blank">Guiyong Zheng</a>¹, <a href="https://robotics-star.com/people" target="_blank">Yiming Luo</a>¹, <br> <a href="https://zdh.ncepu.edu.cn/szdw/fjs/2e5352e61fb648aa890d5aaaf1f1447f.htm" target="_blank">Zhu Wang</a>⁴, <a href="https://facultyprofiles.hkust-gz.edu.cn/faculty-personal-page/ZHOU-Jinni/eejinni" target="_blank">Jinni Zhou</a>⁵, <a href="https://uav.hkust.edu.hk/group" target="_blank">Shaojie Shen</a>², <a href="https://robotics-star.com/people" target="_blank">Boyu Zhou</a>^1,† <p> <h45> ¹ Sun Yat-Sen University. &nbsp;&nbsp; ² The Hong Kong University of Science and Technology. &nbsp;&nbsp; <br> ³ Northwestern Polytechnical University. &nbsp;&nbsp; ⁴ North China Electric Power University. &nbsp;&nbsp; <br> ⁵ The Hong Kong University of Science and Technology (Guangzhou). &nbsp;&nbsp; <br> </h45> ^*Equal Contribution &nbsp;&nbsp; ^†Corresponding Authors </p> <a href="https://ieeexplore.ieee.org/abstract/document/10801474"><img alt="Paper" src="https://img.shields.io/badge/Paper-IEEE-blue"/></a> <a href="https://arxiv.org/abs/2409.02738"><img alt="Paper" src="https://img.shields.io/badge/Paper-arXiv-red"/></a> <a href='https://robotics-star.com/SOAR'><img src='https://img.shields.io/badge/Project_Page-SOAR-green' alt='Project Page'></a> <a href="https://www.bilibili.com/video/BV1G1421Q79m"><img alt="Bilibili" src="https://img.shields.io/badge/Video-Bilibili-purple"/></a> <a href="https://www.bilibili.com/video/BV1wEyHYjEAq"><img alt="Bilibili" src="https://img.shields.io/badge/Talk-Bilibili-pink"/></a> </div>

📢 News

• [09/10/2024]: The code of SOAR is released.
• [30/06/2024]: SOAR is accepted to IROS 2024 and selected as oral presentation (acceptance rate: 10%).

📜 Introduction

[IROS'24] This repository maintains the implementation of "SOAR: Simultaneous Exploration and Photographing with Heterogeneous UAVs for Fast Autonomous Reconstruction".

The key modules of SOAR are detailed in this overview.

<p align="center"> <img src="assets/videos/overview.gif" width = 90% /> </p>

And we also provide a special demo for IROS2024.

<p align="center"> <img src="assets/videos/iros_demo.gif" width = 90% /> </p>

If you find this work useful in your research, please consider citing:

@inproceedings{zhang2024soar,
  title={SOAR: Simultaneous Exploration and Photographing with Heterogeneous UAVs for Fast Autonomous Reconstruction},
  author={Zhang, Mingjie and Feng, Chen and Li, Zengzhi and Zheng, Guiyong and Luo, Yiming and Wang, Zhu and Zhou, Jinni and Shen, Shaojie and Zhou, Boyu},
  booktitle={2024 IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS)},
  pages={10975--10982},
  year={2024},
  organization={IEEE}
}

Please kindly star ⭐️ this project if it helps you. We take great efforts to develop and maintain it 😁.

🛠️ Installation

Prerequisite

• ROS Noetic (Ubuntu 20.04) or ROS Melodic (Ubuntu 18.04)
• PCL
• Eigen

For Marsim:

sudo apt update
sudo apt install libglfw3-dev libglew-dev

For GCOPTER:

sudo apt update
sudo apt install libompl-dev

Compilation

Project:

git clone https://github.com/Robotics-STAR-Lab/SOAR.git
cd SOAR
catkin_make

If you have installed Anaconda, please use catkin_make -DPYTHON_EXECUTABLE=/usr/bin/python3.

LKH-3.0.6:

cd src/planner/utils/lkh_mtsp_solver/LKH
make -j

🚀 Quick Start

Pisa Cathedral

source devel/setup.bash && roslaunch heterogeneous_manager rviz.launch
source devel/setup.bash && roslaunch heterogeneous_manager pisa.launch

<p align="center"> <img src="assets/videos/pisa.gif" width = 60% /> </p>

Sydney Opera House

source devel/setup.bash && roslaunch heterogeneous_manager rviz.launch
source devel/setup.bash && roslaunch heterogeneous_manager sydney.launch

<p align="center"> <img src="assets/videos/sydney.gif" width = 60% /> </p>

NOTE

Trigger the quadrotors to start planning with the 2D Nav Goal when the terminal displays wait for trigger. All scenes are provided in src/heterogeneous_manager/launch/XXX.launch

If you want to use the GPU version of MARSIM, you can change the parameter "use_gpu" to true in src/heterogeneous_manager/launch/XXX.launch

<arg name="use_gpu" value="true" />

Adjusting the Number of Photographers

The current version temporarily only supports a single explorer.

You can modify the pisa.launch or sydney.launch file as follows:

  <!-- TODO: _NUM_ is the total number of explorer and photographers -->
  <arg name="drone_num" value="_NUM_" />

  ... ...

  <!-- Explorer -->
  <group ns="quad_0">
    <include file="$(find heterogeneous_manager)/launch/single_lidar_uav_exploration.xml">
      <arg name="drone_id" value="0" />

      ... ...

    </include>

    <group if="$(arg use_sim)">
      <include file="$(find heterogeneous_manager)/launch/single_lidar_uav.xml">
        <arg name="drone_id" value="0" />

        ... ...

        <!-- TODO: Adjust to the appropriate initial position. -->
        <arg name="init_x_" value="" />
        <arg name="init_y_" value="" />
        <arg name="init_z_" value="" />
        <arg name="init_yaw" value="" />

        ... ...

      </include>
    </group>
  </group>

  <!-- Photographer1 -->
  <group ns="quad_1">
    <include file="$(find heterogeneous_manager)/launch/single_camera_uav_exploration.xml">
      <arg name="drone_id" value="1" />

      ... ...

    </include>

    <group if="$(arg use_sim)">
      <include file="$(find heterogeneous_manager)/launch/single_camera_uav.xml">
        <arg name="drone_id" value="1"/>
        <!-- TODO: Adjust to the appropriate initial position. -->
        <arg name="init_x_" value=""/>
        <arg name="init_y_" value=""/>
        <arg name="init_z_" value=""/>
        <arg name="init_yaw" value=""/>
        <arg name="odom_topic" value="$(arg odom_topic)"/>
      </include>
    </group>
  </group>

  <!-- Other photographers' groups -->
  ... ...

  <!-- PhotographerX (X = _NUM_-1) -->
  <group ns="quad_X">
    <include file="$(find heterogeneous_manager)/launch/single_camera_uav_exploration.xml">
      <!-- TODO: Adjust to the appropriate drone_id = _NUM_-1 -->
      <arg name="drone_id" value="X" />

      ... ...

    </include>

    <group if="$(arg use_sim)">
      <include file="$(find heterogeneous_manager)/launch/single_camera_uav.xml">
        <!-- TODO: Adjust to the appropriate drone_id = _NUM_-1 -->
        <arg name="drone_id" value="X"/>
        <!-- TODO: Adjust to the appropriate initial position. -->
        <arg name="init_x_" value=""/>
        <arg name="init_y_" value=""/>
        <arg name="init_z_" value=""/>
        <arg name="init_yaw" value=""/>
        <arg name="odom_topic" value="$(arg odom_topic)"/>
      </include>
    </group>
  </group>

🤓 Acknowledgments

• FC-Planner: An Efficient Global Planner for Aerial Coverage.
• FUEL: An Efficient Framework for Fast UAV Exploration.
• RACER: A Rapid Exploration Framework for Multiple UAVs.
• GCOPTER: A General-Purpose Trajectory Optimizer for Multicopters.
• MARSIM: A Light-weight Point-realistic Simulator for LiDAR-based UAVs.

🤗 FC-family Works

1. What is FC-family?

We aim to develop intelligent perception-centric flight to realize Fast Coverage / reConstruction / inspeCtion etc.

2. Projects list

• PredRecon (ICRA2023): Prediction-boosted Planner for Aerial Reconstruction.
• FC-Planner (ICRA2024): Highly Efficient Global Planner for Aerial Coverage.
• SOAR (IROS2024): Heterogenous Multi-UAV Planner for Aerial Reconstruction.
