Header-only CPU graphics library for C99 or C++, with a focus on ease-of-use.

Usage

#define PNTR_PIXELFORMAT_RGBA
#define PNTR_IMPLEMENTATION
#include "pntr.h"

int main() {
    pntr_image* image = pntr_new_image(200, 200);
    pntr_draw_circle_fill(image, 100, 100, 80, PNTR_RED);
    pntr_save_image(image, "output.png");
    pntr_unload_image(image);

    return 0;
}

Examples

Features

• Draw rectangles, circles, ellipses, triangles, lines, arcs, etc
• RGBA or ARGB pixel bit order
• Clipping
• Load and save images (PNG)
• Draw sprites with scaling and rotation
• Alpha-blending, alpha masks, invert, brightness, etc
• Font rendering (TTF, BMF, TTY)
• UTF-8
• Documentation

Integrations

| Name | Description | | ---- | ----------- | | pntr_app | Application wrapper for running the same pntr code in raylib, SDL, Web, libretro, or in a CLI | | pntr_assetsys | Load pntr assets from .zip files with assetsys.h | | pntr_physfs | Load pntr assets from .zip files with PhysicsFS | | pntr_nuklear | Nuklear immediate-mode graphical user interface for pntr | | pntr_aseprite | Use Aseprite animated sprites in pntr | | pntr_tiled | Display Tiled 2D level editor maps in pntr | | pntr_portablegl | Use the OpenGL-esque software rendering library, PortableGL, in pntr | | pntr_doom | Play DOOM via PureDOOM rendered through pntr | | pntr_pixelfont | Additional pixel fonts outside of the default | | zig_pntr | Zig wrapper for pntr |

API

In order to use pntr, you must define PNTR_IMPLEMENTATION prior in one of your .c files prior to including pntr.h.

#define PNTR_IMPLEMENTATION
#include "pntr.h"

Configuration

You can modify how pntr functions based on the following defines:

| Define | Description | | --- | --- | | PNTR_IMPLEMENTATION | Define this in one of your .c or .cpp files before including pntr.h | | PNTR_PIXELFORMAT_RGBA | Use the RGBA format | | PNTR_PIXELFORMAT_ARGB | Use the ARGB pixel format | | PNTR_ENABLE_DEFAULT_FONT | Enables the default 8x8 pixel font | | PNTR_ENABLE_MATH | Enables use of C's standard math.h linked library, rather than using the built in math functions | | PNTR_ENABLE_TTF | Enables support for loading TrueType fonts | | PNTR_ENABLE_UTF8 | Enables UTF-8 support for font loading and text rendering | | PNTR_LOAD_FILE | Callback to use when asked to load a file in pntr_load_file(). By default, will use stdio.h. | | PNTR_LOAD_IMAGE_FROM_MEMORY | Callback to use when loading an image from memory via pntr_load_image_from_memory(). By default, will use stb_image | | PNTR_SAVE_FILE | Callback to use when saving a file via pntr_save_file(). By default, uses stdio.h | | PNTR_SAVE_IMAGE_TO_MEMORY | Callback to use when saving an image to memory via pntr_save_image_to_memory(). By default, will use stb_image_write | | PNTR_NO_ALPHABLEND | Skips alpha blending when drawing pixels | | PNTR_NO_STDIO | Will disable the standard file loading/saving calls for PNTR_LOAD_FILE and PNTR_SAVE_FILE | | PNTR_NO_SAVE_IMAGE | Disables the default behavior of image saving | | PNTR_NO_LOAD_IMAGE | Disables the default behavior of image loading | | PNTR_NO_CUTE_PNG_IMPLEMENTATION | Skips defining CUTE_PNG_IMPLEMENTATION. Useful if you're using cute_png elsewhere | | PNTR_NO_STB_TRUETYPE_IMPLEMENTATION | Skips defining STB_TRUETYPE_IMPLEMENTATION. Useful if you're using stb_truetype elsewhere | | PNTR_NO_STB_IMAGE_WRITE_IMPLEMENTATION | Skips defining STB_IMAGE_WRITE_IMPLEMENTATION. useful if you're using stb_image_write elsewhere | | PNTR_NO_STB_IMAGE_IMPLEMENTATION | Skips defining STB_IMAGE_IMPLEMENTATION. useful if you're using stb_image_write elsewhere |

Functions

pntr_image* pntr_new_image(int width, int height);
pntr_image* pntr_gen_image_color(int width, int height, pntr_color color);
pntr_image* pntr_image_copy(pntr_image* image);
pntr_image* pntr_image_from_image(pntr_image* image, int x, int y, int width, int height);
pntr_image* pntr_image_subimage(pntr_image* image, int x, int y, int width, int height);
pntr_rectangle pntr_image_get_clip(pntr_image* image);
void pntr_image_set_clip(pntr_image* image, int x, int y, int width, int height);
void pntr_image_reset_clip(pntr_image* image);
void pntr_unload_image(pntr_image* image);
void pntr_clear_background(pntr_image* image, pntr_color color);

void pntr_draw_point(pntr_image* dst, int x, int y, pntr_color color);
void pntr_draw_point_vec(pntr_image* dst, pntr_vector* point, pntr_color color);
void pntr_draw_points(pntr_image* dst, pntr_vector* points, int pointsCount, pntr_color color);
void pntr_draw_line(pntr_image* dst, int startPosX, int startPosY, int endPosX, int endPosY, pntr_color color);
void pntr_draw_line_horizontal(pntr_image* dst, int posX, int posY, int width, pntr_color color);
void pntr_draw_line_horizontal_thick(pntr_image* dst, int posX, int posY, int width, int thickness, pntr_color color);
void pntr_draw_line_thick(pntr_image* dst, int startPosX, int startPosY, int endPosX, int endPosY, int thickness, pntr_color color);
void pntr_draw_line_thick_vec(pntr_image* dst, pntr_vector start, pntr_vector end, int thickness, pntr_color color);
void pntr_draw_line_vec(pntr_image* dst, pntr_vector start, pntr_vector end, pntr_color color);
void pntr_draw_line_vertical(pntr_image* dst, int posX, int posY, int height, pntr_color color);
void pntr_draw_line_vertical_thick(pntr_image* dst, int posX, int posY, int height, int thickness, pntr_color color);
void pntr_draw_rectangle(pntr_image* dst, int posX, int posY, int width, int height, pntr_color color);
void pntr_draw_rectangle_fill(pntr_image* dst, int posX, int posY, int width, int height, pntr_color color);
void pntr_draw_rectangle_fill_rec(pntr_image* dst, pntr_rectangle rect, pntr_color color);
void pntr_draw_rectangle_gradient(pntr_image* dst, int x, int y, int width, int height, pntr_color topLeft, pntr_color topRight, pntr_color bottomLeft, pntr_color bottomRight);
void pntr_draw_rectangle_gradient_rec(pntr_image* dst, pntr_rectangle rect, pntr_color topLeft, pntr_color topRight, pntr_color bottomLeft, pntr_color bottomRight);
void pntr_draw_rectangle_rec(pntr_image* dst, pntr_rectangle rec, pntr_color color);
void pntr_draw_rectangle_thick(pntr_image* dst, int posX, int posY, int width, int height, int thickness, pntr_color color);
void pntr_draw_rectangle_thick_rec(pntr_image* dst, pntr_rectangle rect, int thickness, pntr_color color);
void pntr_draw_triangle(pntr_image* dst, int x1, int y1, int x2, int y2, int x3, int y3, pntr_color color);
void pntr_draw_triangle_fill(pntr_image* dst, int x1, int y1, int x2, int y2, int x3, int y3, pntr_color color);
void pntr_draw_triangle_fill_vec(pntr_image* dst, pntr_vector point1, pntr_vector point2, pntr_vector point3, pntr_color color);
void pntr_draw_triangle_thick(pntr_image* dst, int x1, int y1, int x2, int y2, int x3, int y3, int thickness, pntr_color color);
void pntr_draw_triangle_thick_vec(pntr_image* dst, pntr_vector point1, pntr_vector point2, pntr_vector point3, int thickness, pntr_color color);
void pntr_draw_triangle_vec(pntr_image* dst, pntr_vector point1, pntr_vector point2, pntr_vector point3, pntr_color color);
void pntr_draw_ellipse(pntr_image* dst, int centerX, int centerY, int radiusX, int radiusY, pntr_color color);
void pntr_draw_ellipse_fill(pntr_image* dst, int centerX, int centerY, int radiusX, int radiusY, pntr_color color);
void pntr_draw_ellipse_thick(pntr_image* dst, int centerX, int centerY, int radiusX, int radiusY, int thickness, pntr_color color);
void pntr_draw_circle(pntr_image* dst, int centerX, int centerY, int radius, pntr_color color);
void pntr_draw_circle_fill(pntr_image* dst, int centerX, int centerY, int radius, pntr_color color);
void pntr_draw_circle_thick(pntr_image* dst, int centerX, int centerY, int radius, int thickness, pntr_color color);
void pntr_draw_polygon(pntr_image* dst, pntr_vector* points, int numPoints, pntr_color color);
void pntr_draw_polygon_fill(pntr_image* dst, pntr_vector* points, int numPoints, pntr_color color);
void pntr_draw_polygon_thick(pntr_image* dst, pntr_vector* points, int numPoints, int thickness, pntr_color color);
void pntr_draw_polyline(pntr_image* dst, pntr_vector* points, int numPoints, pntr_color color);
void pntr_draw_polyline_thick(pntr_image* dst, pntr_vector* points, int numPoints,
