EasyUIBuilder v2.1.0

A PHP library for generating Minecraft Bedrock Edition JSON UI files using a fluent builder pattern. Build complex UI screens with clean, readable code — and output Minecraft-compatible resource packs automatically.

Features

Fluent API — chainable methods for all UI elements
Auto-generation of _ui_defs.json and server_form.json
All Bedrock UI types — Label, Panel, Button, Image, Grid, StackPanel, Toggle, Slider, EditBox, ScrollView, Dropdown, InputPanel, Screen, CustomRender
Binding system — global, view, collection and visibility bindings
Animation system — alpha, offset, size, color, clip, flip_book with 30+ easings
Variable system — conditional variables for platform/input-specific layouts
Utility elements — CloseButton, PlayerRender (pre-built components)
Color utilities — predefined colors, RGB, random, pastel, complementary
Anchoring system — 9-point anchor positioning with offsets
Sizing modes — pixel, percentage, custom array sizes
RootBuild system — register screen definitions and auto-generate packs

Installation

Requirements: PHP 8.0 or higher

Via Composer

composer require refaltor/easy-ui-builder

Manual

Clone the repository and include the autoloader:

spl_autoload_register(function (string $classname): void {
    if (str_contains($classname, "refaltor\\")) {
        require_once("./src/" . str_replace("\\", "/", $classname) . ".php");
    }
});

Quick Start

use refaltor\ui\builders\Root;
use refaltor\ui\elements\Label;
use refaltor\ui\colors\BasicColor;

$root = Root::create("my_namespace");
$root->addElement(
    Label::create("hello", "Hello Minecraft!")
        ->setFontSize(Label::FONT_EXTRA_LARGE)
        ->setShadow()
        ->setColor(BasicColor::yellow())
);
$root->generateAndSaveJson("ui/my_screen.json");

UI Elements

Core Elements

| Element | Description | |---------|-------------| | Label | Text with font size/type/scale, shadow, color | | Panel | Container with visibility, alpha, clipping, scissor | | Button | Interactive button with 4-state textures, factory system | | Image | Texture with UV, 9-slice, tiling, clip, grayscale | | Grid | Dynamic grid layout with templates and fill direction | | StackPanel | Auto-layout container (vertical/horizontal) |

Extended Elements (v2.1)

| Element | Description | |---------|-------------| | Toggle | Checkbox/switch with radio groups, checked/unchecked controls | | Slider | Value cursor with steps, direction, box/track controls | | EditBox | Text input with placeholder, max length, text types | | ScrollView | Scrollable container (vertical/horizontal) | | Dropdown | Dropdown menu with items | | InputPanel | Input handling with focus navigation, button mappings, modal | | Screen | Screen root element with render flags, input absorption | | CustomRender | Native renderers (paper_doll, inventory_item, panorama...) |

Utility Elements

| Element | Description | |---------|-------------| | CloseButton | Pre-built close button extending Bedrock's common dialog | | PlayerRender | Pre-built player skin viewer |

Component Systems (v2.1)

| Component | Description | |-----------|-------------| | Binding | Data bindings (global, view, collection, visibility) | | Animation | UI animations with 30+ easings and chaining | | Variable | Conditional variables for adaptive layouts |

RootBuild System

To create a new UI screen, implement the RootBuild interface:

class MyScreen implements RootBuild
{
    public function root(): Root
    {
        $root = Root::create();
        $root->addElement(
            Label::create("title", "My Screen")
                ->setFontSize(Label::FONT_EXTRA_LARGE)
                ->setShadow()
        );
        return $root;
    }

    public function getNamespace(): string { return "my_screen"; }
    public function getPathName(): string { return "./resources/pack_example/"; }
    public function titleCondition(): string { return "MY_SCREEN"; }
}

Examples

The tests/ directory contains complete examples for every feature:

| File | Description | |------|-------------| | LabelExample.php | Font sizes, types, colors, shadows, scaling | | PanelExample.php | Nested panels, background images, alpha, clipping | | ButtonExample.php | Custom textures, visibility conditions, factory | | ImageExample.php | Tiling, nineslice, UV mapping, grayscale, fill | | GridExample.php | Grid dimensions, item templates, fill direction | | StackPanelExample.php | Vertical and horizontal layouts | | FullMenuExample.php | Complete game menu combining all elements | | ColorExample.php | All BasicColor functions | | ToggleExample.php | Toggle, radio groups, checked/unchecked controls | | SliderExample.php | Horizontal/vertical sliders, steps, controls | | EditBoxExample.php | Text/number input, placeholder, locked fields | | ScrollViewExample.php | Vertical/horizontal scroll, chat jump-to-bottom | | DropdownExample.php | Gamemode, difficulty, language dropdowns | | InputPanelExample.php | Modal dialog, focus nav, gesture tracking | | ScreenExample.php | Modal/HUD/cached screens, close on hurt | | CustomRenderExample.php | Paper doll, item renderer, gradient, vignette | | BindingExample.php | Global, view, collection bindings, visibility | | AnimationExample.php | Fade, slide, pulse, bounce, elastic, chain, clip | | VariableExample.php | Platform, input-mode, screen-size conditionals |

Running

php start.php

Generated files are output to resources/pack_example/:

ui/_ui_defs.json — UI definitions registry
ui/server_form.json — Server form configuration
ui/custom_ui/<namespace>.json — Individual UI screen files

Wiki

For full API documentation: https://github.com/Refaltor77/EasyUIBuilder/wiki
