{msm.stacked}
<!-- badges: start -->
The {msm.stacked} package can be used to simplify the calculation of state transition probabilities over time and the creation of stacked probabilities plot from multi-state model fits from the {msm} package.
Installation
You can install the development version of {msm.stacked} from GitHub with:
# install.packages("devtools")
devtools::install_github("RedDoorAnalytics/msm.stacked", build_vignettes = TRUE)
Example
To illustrate the functionality of {msm.stacked}, we build upon the
documentation for the msm::msm() function. We will be using the heart
transplant data:
library(msm)
head(cav)
#> PTNUM age years dage sex pdiag cumrej state firstobs statemax
#> 1 100002 52.49589 0.000000 21 0 IHD 0 1 1 1
#> 2 100002 53.49863 1.002740 21 0 IHD 2 1 0 1
#> 3 100002 54.49863 2.002740 21 0 IHD 2 2 0 2
#> 4 100002 55.58904 3.093151 21 0 IHD 2 2 0 2
#> 5 100002 56.49589 4.000000 21 0 IHD 3 2 0 2
#> 6 100002 57.49315 4.997260 21 0 IHD 3 3 0 3
Further details on this example dataset are included in the vignette of the {msm} package.
We start with a matrix of possible transitions:
twoway4.q <- rbind(
c(-0.5, 0.25, 0, 0.25),
c(0.166, -0.498, 0.166, 0.166),
c(0, 0.25, -0.5, 0.25),
c(0, 0, 0, 0)
)
twoway4.q
#> [,1] [,2] [,3] [,4]
#> [1,] -0.500 0.250 0.000 0.250
#> [2,] 0.166 -0.498 0.166 0.166
#> [3,] 0.000 0.250 -0.500 0.250
#> [4,] 0.000 0.000 0.000 0.000
This is then used to provide starting values for the model without additional covariates:
cav.msm <- msm(
formula = state ~ years,
subject = PTNUM,
data = cav,
qmatrix = twoway4.q,
deathexact = 4
)
cav.msm
#>
#> Call:
#> msm(formula = state ~ years, subject = PTNUM, data = cav, qmatrix = twoway4.q, deathexact = 4)
#>
#> Maximum likelihood estimates
#>
#> Transition intensities
#> Baseline
#> State 1 - State 1 -0.17037 (-0.19027,-0.15255)
#> State 1 - State 2 0.12787 ( 0.11135, 0.14684)
#> State 1 - State 4 0.04250 ( 0.03412, 0.05294)
#> State 2 - State 1 0.22512 ( 0.16755, 0.30247)
#> State 2 - State 2 -0.60794 (-0.70880,-0.52143)
#> State 2 - State 3 0.34261 ( 0.27317, 0.42970)
#> State 2 - State 4 0.04021 ( 0.01129, 0.14324)
#> State 3 - State 2 0.13062 ( 0.07952, 0.21457)
#> State 3 - State 3 -0.43710 (-0.55292,-0.34554)
#> State 3 - State 4 0.30648 ( 0.23822, 0.39429)
#>
#> -2 * log-likelihood: 3968.798
We can use the plot.msm() function to plot survival curves from every
transient state to the final, absorbing state (e.g., a state denoting
death). This is denoted in the cav dataset by state 4:
plot(cav.msm, from = 1:3, to = 4)
The {msm} package also provides functionality to calculate state
transition probabilities at a given point in time. Say we are interested
in estimating the probability of being in a given state, from each
state, five years after baseline; we can use the pmatrix.msm()
function to obtain just that:
pmatrix.msm(x = cav.msm, t = 5)
#> State 1 State 2 State 3 State 4
#> State 1 0.51965804 0.13851775 0.09119847 0.2506257
#> State 2 0.24386420 0.13881410 0.18090731 0.4364144
#> State 3 0.06121333 0.06897186 0.16909991 0.7007149
#> State 4 0.00000000 0.00000000 0.00000000 1.0000000
This shows that, for instance, study participants in State 1 at time zero have (approximately) a 52% probability of still being in State 1 after years, 14% probability of being in State 2, 9% probability of being in State 3, and 25% probability of being in State 4.
We can repeatedly call the pmatrix.msm() function to obtain
probabilities over time, but that’s a bit tedious. This is where the
{msm.stacked} package comes in handy.
Specifically, we can use the stacked.data.msm() function to calculate
transition probabilities over time, say, at 1 to 5 years:
library(msm.stacked)
sdd <- stacked.data.msm(model = cav.msm, tstart = 0, tforward = 5, tseqn = 6)
str(sdd)
#> 'data.frame': 96 obs. of 5 variables:
#> $ from : Factor w/ 4 levels "State 1","State 2",..: 1 2 3 4 1 2 3 4 1 2 ...
#> $ to : Factor w/ 4 levels "State 1","State 2",..: 1 1 1 1 2 2 2 2 3 3 ...
#> $ p : num 1 0 0 0 0 1 0 0 0 0 ...
#> $ tstart: num 0 0 0 0 0 0 0 0 0 0 ...
#> $ t : num 0 0 0 0 0 0 0 0 0 0 ...
This returns a tidy dataset with all transition probabilities, from and
to every state, over tseqn = 6 equally-spaced time intervals between
time zero and time five. Focussing on transitions from State 1 only:
subset(sdd, sdd$from == "State 1")
#> from to p tstart t
#> 1 State 1 State 1 1.00000000 0 0
#> 5 State 1 State 2 0.00000000 0 0
#> 9 State 1 State 3 0.00000000 0 0
#> 13 State 1 State 4 0.00000000 0 0
#> 17 State 1 State 1 0.85395872 0 1
#> 21 State 1 State 2 0.08836953 0 1
#> 25 State 1 State 3 0.01475543 0 1
#> 29 State 1 State 4 0.04291632 0 1
#> 33 State 1 State 1 0.74313989 0 2
#> 37 State 1 State 2 0.12669585 0 2
#> 41 State 1 State 3 0.04053779 0 2
#> 45 State 1 State 4 0.08962646 0 2
#> 49 State 1 State 1 0.65472323 0 3
#> 53 State 1 State 2 0.14064466 0 3
#> 57 State 1 State 3 0.06380519 0 3
#> 61 State 1 State 4 0.14082692 0 3
#> 65 State 1 State 1 0.58161960 0 4
#> 69 State 1 State 2 0.14256253 0 4
#> 73 State 1 State 3 0.08072247 0 4
#> 77 State 1 State 4 0.19509541 0 4
#> 81 State 1 State 1 0.51965804 0 5
#> 85 State 1 State 2 0.13851775 0 5
#> 89 State 1 State 3 0.09119847 0 5
#> 93 State 1 State 4 0.25062574 0 5
Here we see, for instance, that the probability of still being in State 1, starting from State 1, is (approximately) 85% after one year, 74% after two years, 65% after three years, 58% after four years, and 52% after five years:
subset(sdd, sdd$from == "State 1" & sdd$to == "State 1")
#> from to p tstart t
#> 1 State 1 State 1 1.0000000 0 0
#> 17 State 1 State 1 0.8539587 0 1
#> 33 State 1 State 1 0.7431399 0 2
#> 49 State 1 State 1 0.6547232 0 3
#> 65 State 1 State 1 0.5816196 0 4
#> 81 State 1 State 1 0.5196580 0 5
The package also provides functionality to automatically produce stacked
probabilities plots, for transition probabilities from and to every
state. This is implemented in the stacked.plot.msm() function:
stacked.plot.msm(model = cav.msm, tstart = 0, tforward = 5)
This relies on {ggplot2} functionality
and returns a standard ggplot object, which can of course be further
customised beyond the default settings:
library(ggplot2)
stacked.plot.msm(model = cav.msm, tstart = 0, tforward = 5) +
scale_fill_viridis_d(option = "plasma") +
theme_minimal() +
theme(legend.position = "bottom") +
labs(fill = "To:")
Model with Covariates
We can of course incorporate covariates in a multi-state model and obtain predictions for a specific covariates pattern; let’s demonstrate this by incorporating sex in the model above. First, we fit a second model:
cav.msm.cov <- msm(
formula = state ~ years,
subject = PTNUM,
data = cav,
covariates = ~sex,
qmatrix = twoway4.q,
deathexact = 4
)
cav.msm.cov
#>
#> Call:
#> msm(formula = state ~ years, subject = PTNUM, data = cav, qmatrix = twoway4.q, covariates = ~sex, deathexact = 4)
#>
#> Maximum likelihood estimates
#> Baselines are with covariates set to their means
#>
#> Transition intensities with hazard ratios for each covariate
#> Baseline
#> State 1 - State 1 -0.16938 (-1.894e-01,-1.515e-01)
#> State 1 - State 2 0.12745 ( 1.108e-01, 1.466e-01)
#> State 1 - State 4 0.04193 ( 3.354e-02, 5.241e-02)
#> State 2 - State 1 0.22645 ( 1.686e-01, 3.042e-01)
#> State 2 - State 2 -0.58403 (-1.053e+00,-3.238e-01)
#> State 2 - State 3 0.33693 ( 2.697e-01, 4.209e-01)
#> State 2 - State 4 0.02065 ( 2.196e-09, 1.941e+05)
#> State 3 - State 2 0.13050 ( 7.830e-02, 2.175e-01)
#> State 3 - State 3 -0.44178 (-5.582e-01,-3.497e-01)
#> State 3 - State 4 0.31128 ( 2.425e-01, 3.996e-01)
#> sex
#> State 1 - State 1
#> State 1 - State 2 0.5632779 (3.333e-01,9.518e-01)
#> State 1 - State 4 1.1289701 (6.262e-01,2.035e+00)
#> State 2 - State 1 1.2905854 (4.916e-01,3.388e+00)
#> State 2 - State 2
#> State 2 - State 3 1.0765518 (5.194e-01,2.231e+00)
#> State 2 - State 4 0.0003805 (7.241e-65,1.999e+57)
#> State 3 - State 2 1.0965531 (1.345e-01,8.937e+00)
#> State 3 - State 3
#> State 3 - State 4 2.4135380 (1.176e+00,4.952e+00)
#>
#> -2 * log-likelihood: 3954.777
Then, we can use the same functionality as before to obtain stacked probabilities plots:
stacked.plot.msm(model = cav.msm.cov, tstart = 0, tforward = 5) +
labs(title = "Predictions for average covariates")
By default, this will set all cova
