MantaPatch

This repo contains the code of the paper:

Data-driven Synthesis of Smoke Flows with Cnn-based Feature Descriptors, Mengyu Chu and Nils Thuerey.

Install

Install CMake, python, tensorflow (numpy), matplot, sklearn, flann(more details in the very last section)

Clone this repo

git clone https://github.com/RachelCmy/mantaPatch.git

The code is implemented on mantaflow. Here is an installation guide: http://mantaflow.com/install.html
When building mantaflow with CMake, it is necessary to check NUMPY on. It is recommended to check the GUI (depends on Qt) and OPENMP on as well.
eigen(http://eigen.tuxfamily.org/index.php?title=Main_Page) is used in our code. We have one under dependencies folder, and it is used by default on Windows. On Linux, please edit the eigen path in CMakeLists.txt file, at line 481
Related scene files are in folder mantaflow_path/tensorflow/example3_smoke_patch/ or folder mantaflow_path/scenes/
Output files are usually in folder mantaflow_path/tensorflow/data
Note the working folder used below is always mantaflow_path/build/
The manta below stands for the executable file.
- On Windows, it is Release/manta.exe (mantaflow_path/build/Release/manta.exe)
- On Linux, it is ./manta (mantaflow_path/build/manta)

Try Patch Advection

Examples of deformation-limiting patch advection scenes in 3d and 2d:

manta ../scenes/patch_2d.py
# or
manta ../scenes/patch_3d.py

2d is visualized with smile faces and 3d is visualized with meshes( try shift+m ).

Train a patch-descriptor-learning CNN

A Simulation Pair Generation:

 # for 2D
 manta ../tensorflow/example3_smoke_patch/genSimData.py
 # or for 3D
 manta ../tensorflow/example3_smoke_patch/genSimData.py dim 3

It will generate one simulation pair. All data is saved in ../tensorflow/data/sim_????/ folder. 3D simulations will take longer time. It is necessary to generate lots of pairs (with different seeds) to get good training results.

Examples for parameters:

 # example1, input a single number, as random seed,
 # for e.g. the 42 will be used as random seed here.
 manta ../tensorflow/example3_smoke_patch/genSimData.py 42
 # example2, input a parameter-list.
 # Only right names are accepted
 # ( take a look at line 252 in genSimData.py)
 manta ../tensorflow/example3_smoke_patch/genSimData.py npSeed 42 resetN 20 saveppm False

Patch Pairs Generation (Training Data for step 3):
```
 manta ../tensorflow/example3_smoke_patch/genPatchData.py 1000
```
This command will generate the patch pairs from the simulation in data/sim_1000/ All data is saved in ../tensorflow/data/patch_1000/ folder. 1000 can be replaced with any other valid simNo. A special case is simNo == -1
```
 manta ../tensorflow/example3_smoke_patch/genPatchData.py -1
 # or
 manta ../tensorflow/example3_smoke_patch/genPatchData.py simNo -1 savePatchPpm True
```
This command will generate patch pairs from all existed simulations in folders named as data/sim_????/, except for the ones whose patch folders already exist.

Examples for parameter-list:
```
 # Only right names are accepted
 #( take a look at line 128 in genSimData.py)
 manta ../tensorflow/example3_smoke_patch/genPatchData.py \
 simNo 1002 PATCH_SIZE 48 savePatchPpm False
```
Note that the factor between coase and fine are already defined in the simulation pair. PATCH_SIZE is used as the size for high resolution patches, and for coarse ones the size is PATCH_SIZE/factor. And 36 (by default) is recommanded.

If savePatchPpm is true, ppm image files will be outputed with patch uni files. They are very large ( no image compression used ), but can help to visualize patches, with the software djv_view(http://djv.sourceforge.net/).

Train a Saimese CNN: Parameter-list is at line 253 in trainPatchData.py. Parameter data_dirs stands for the training dataset pathes. It should be in a pair of quotes, multiple pathes should be seperated with commas, for e.g.,

 # train a density descriptor first
 manta ../tensorflow/example3_smoke_patch/trainPatchData.py \
 data_dirs "../tensorflow/data/patch_1000/, ../tensorflow/data/patch_1001/"
 # train a curl-of-velocity descriptor as well
 manta ../tensorflow/example3_smoke_patch/trainPatchData.py \
 data_dirs "../tensorflow/data/patch_1000/, ../tensorflow/data/patch_1001/" dataFlag 2
 # make sure that data_dirs path strings end with "/" or "\\" !

Training log, trained models and other files are saved in data/_trainlog_yyyymmdd_hhmmss/ folder

Evaluate the CNN: Parameter-list is at line 207 in RecallEval.py.

For a given evaluation dataset( should be different from the training one), we evaluate the given trained model with the recall over rank curve.

 # evaluate a density descriptor (dataFlag = 1)
 manta ../tensorflow/example3_smoke_patch/RecallEval.py \
 data_dirs "../tensorflow/data/patch_1002/" \
 saved_model ../tensorflow/data/_trainlog_yyyymmdd_hhmmss/model_yyyymmdd_hhmmss.ckpt \
 dataFlag 1
 # evaluate a curl descriptor (dataFlag = 2)
 manta ../tensorflow/example3_smoke_patch/RecallEval.py \
 data_dirs "../tensorflow/data/patch_1002/" \
 saved_model ../tensorflow/data/_trainlog_yyyymmdd_hhmmss/model_yyyymmdd_hhmmss.ckpt \
 dataFlag 2
 # param color could be used to set the color of the recall curve
 # make sure that dataFlag and the saved_model are consistent
 # (both for density or both for curl, and both for 2D or 3D).

Evaluation log, recall curve, descriptors and other files are saved in data/_evaltlog_yyyymmdd_hhmmss/ folder. For parameter saved_model, our trained models are offered in folder mantaflow_path/tensorflow/example3_smoke_patch/models/ Note here, unlike the training code, there is no automatic dataset separation, so a relatively smaller evaluation dataset is supposed to be used.

Prepare a repository

High-resolution Simulation Generation Only: It is possible to reuse the training/evaluation dataset, but it is better to create some even larger-resolution simulations, for e.g.,

 manta ../tensorflow/example3_smoke_patch/genSimData.py doCoarse False res 128 simNo 2000

You can also use specially designed simulations ( a special simNo should be used ), for e.g.,

 # for 2d, the only "special" part is that the random seeds are fixed ( at line 62 )
 manta ../tensorflow/example3_smoke_patch/genSimDataSpecial.py
 # or for 3d, the only "special" part is that the random seeds are fixed ( at line 62 )
 manta ../tensorflow/example3_smoke_patch/genSimDataSpecial.py dim 3
 # high-res in 3D is very slow

The output files should have the same folder structure. Then generate larger patches as well (PATCH_SIZE = 64, 72 or even larger):

 manta ../tensorflow/example3_smoke_patch/genPatchData.py \
 doCoarse False simNo 2000 PATCH_SIZE 64

Use a trained CNN model to extract all descriptors:

 # density des
 # note that PATCH_SIZE should be the same as the trained CNN
 # instead of the repository patch size.
 manta ../tensorflow/example3_smoke_patch/libDesPack.py dataFlag 1 PATCH_SIZE 36
 saved_model ../tensorflow/example3_smoke_patch/models/model_2D/den_cnn.ckpt
 data_dirs "../tensorflow/data/patch_2000/"

 # curl of velocity des
 manta ../tensorflow/example3_smoke_patch/libDesPack.py dataFlag 2 PATCH_SIZE 36
 saved_model ../tensorflow/example3_smoke_patch/models/model_2D/curl_cnn.ckpt
 data_dirs "../tensorflow/data/patch_2000/"

 # or use some other model:
 # saved_model ../tensorflow/data/_trainlog_yyyymmdd_hhmmss/model_yyyymmdd_hhmmss.ckpt
 # set DIM as 3 to work with 3D repository

Output descriptor npz file will be saved in data/_deslog_yyyymmdd_hhmmss/ folder, unless parameter desdataPath is assigned as other output directory. If the parameter updateLib is True (as default), the descriptor file will be copied to the repository folder as well.

Get new high-resolution simulations

A 2D example of smoke synthesis with repository patches using CNN descriptors.
```
 manta ../tensorflow/example3_smoke_patch/patch_2d.py \
 SynCurlFlag True data_dirs "../tensorflow/data/patch_2000/" \
 den_model ../tensorflow/data/_trainlog_yyyymmdd_hhmmss/model_yyyymmdd_hhmmss.ckpt \
 curl_model ../tensorflow/data/_trainlog_yyyymmdd_hhmmss/model_yyyymmdd_hhmmss.ckpt
 # den_model & curl_model, our trained models are used by default (if not given)
```
An extra library, flann, is used to build the kd-tree of the repository. It can be installed with pip, more info: https://github.com/primetang/pyflann

For python3, it is necessary to fix some problems, according to: https://github.com/primetang/pyflann/issues/1 It is important to use the same model as used in the repository (See Prepare a repository) Our repository patches (using our models) are not uploaded with the code. But the 2D version can be downloaded from: https://ge.in.tum.de/download/data/mantaPatchData.7z
```
 wget https://ge.in.tum.de/download/data/mantaPatchData.7z
 7z x man
```
