This is the official repository of Continual Graph Learning Benchmark (CGLB), which was published in the datasets and benchmarks track of NeurIPS 2022 (paper link). We will keep maintaining this repository to facilitate the development of continual graph learning, and we appreciate any comment on improving our CGLB!
@inproceedings{zhang2022cglb,
title={CGLB: Benchmark Tasks for Continual Graph Learning},
author={Zhang, Xikun and Song, Dongjin and Tao, Dacheng},
booktitle={Thirty-sixth Conference on Neural Information Processing Systems Datasets and Benchmarks Track},
year={2022}
}
Get Started
This repository contains our CGLB implemented for running on GPU devices. To run in the Windows system, please specify the argument --replace_illegal_char as True to avoid illegal filename characters (details are in <a href="#Pipeline-Usages">Pipeline Usages</a>). To run the code, the following packages are required to be installed:
- python==3.7.10
- scipy==1.5.2
- numpy==1.19.1
- torch==1.7.1
- networkx==2.5
- scikit-learn~=0.23.2
- matplotlib==3.4.1
- ogb==1.3.1
- dgl==0.6.1
- dgllife==0.2.6
For GCGL tasks, the following packages are also required:
- rdkit==2020.09.1.0
Dataset Usages
Importing the Datasets
For importing the N-CGL datasets, use the following command in python:
from CGLB.NCGL.utils import NodeLevelDataset
dataset = NodeLevelDataset('data_name')
where the 'data_name' should be replaced by the name of the selected dataset, which are:
'CoraFull-CL'
'Arxiv-CL'
'Reddit-CL'
'Products-CL'
For importing the G-CGL datasets, use the following command in python:
from CGLB.GCGL.utils import GraphLevelDataset
dataset = GraphLevelDataset('data_name')
where the 'data_name' selections are:
'SIDER-tIL'
'Tox21-tIL'
'Aromaticity-CL'
Data Structures and Formats
An instance of the NodeLevelDataset has multiple attributes and methods. dataset.d_data, dataset.n_cls, and dataset.n_nodes denotes the number of dimensions of the node features, the number of classes of the corresponding dataset, and the number of nodes in the corresponding dataset, respectively. dataset.graph is the entire graph of the corresponding dataset without being divided. The data type of dataset.graph is the DGL graph. dataset.labels contains the label of every node of dataset.graph. dataset.tr_va_te_split is a dictionary containing the splitting of each class for training, validation, and testing.
dataset.get_graph() is a most useful method that returns a subgraph of dataset.graph (for constructing the continual learning task sequence) with the given classes or node indices to retain. There are three keyword arguments for dataset.get_graph() including classes_to_retain, node_ids, and remove_edges. classes_to_retain is used to specify which classes of the dataset.graph to retain in the returned subgraph. node_ids is used to specify specific nodes to retain. If both classes_to_retain and node_ids are specified, their corresponding subgraphs will be separately generated and then combined into one graph. remove_edges is specifically for removing the edges of the subgraph generated from the specified node_ids. One possible usage of this argument is to select and output the nodes to store for the memory-based baseline ER-GNN.
The usage of the G-CGL dataset resembles classic continual learning. An instance of GraphLevelDataset consists of four components. dataset.dataset is the original dataset before being divided. train_set, val_set, test_set are the splittings for training, validation, and testing. For the task-IL datasets SIDER-tIL and Tox21-tIL, the original datasets are multi-label ones, and the splitting is simply splitting the dataset into three parts according to the given ratios. While for the Aromaticity-CL whose original dataset is a multi-class one, the splitting is also done for each class like the N-CGL datasets. As a result, for Aromaticity-CL, each of train_set, val_set, and test_set is a list containing the splitting of each class.
Pipeline Usages
We provide pipelines for training, validating, and evaluating models with both N-CGL and G-CGL tasks under both task-IL and class-IL scenarios. In the following, we provide several examples to demonstrate the usage of the pipelines.
N-CGL
Below is the example to run the 'Bare model' baseline with GCN backbone on the Arxiv-CL dataset under the task-IL scenario.
For both N-CGL and G-CGL experiments, the starting point is the train.py file, and the different configurations (e.g. the baseline, backbone, learning scenario (task-IL or class-IL), whether to include inter-task edges, etc.) are assigned through the keyword arguments of the Argparse module. For example, to run the N-CGL experiments without inter-task edge under the task-IL scenario, the following code is to be used.
python train.py --dataset Arxiv-CL \
--method bare \
--backbone GCN \
--gpu 0 \
--ILmode taskIL \
--inter-task-edges False \
--minibatch False \
For the baselines with tunable hyper-parameters, our framework provide a convenient way to do a grid search over candidate combinations of hyper-parameters. For example, the baseline GEM has two tunable hyper-parameters memory_strength and n_memories. If the candidate memory_strength and n_memories are [0.05,0.5,5] and [10,100,1000], respectively, then the command to validate every possible hyper-parameter combination over the validation and test the chosen optimal model on the testing set is as follows:
python train.py --dataset Arxiv-CL \
--gem_args " 'memory_strength': [0.05,0.5,5]; 'n_memories': [10,100,1000] " \
--method gem \
--backbone GCN \
--gpu 0 \
--ILmode $IL \
--inter-task-edges $inter \
--epochs $n_epochs \
Some rules to note are: 1. The entire argument " 'memory_strength': [0.05,0.5,5]; 'n_memories': [10,100,1000] " requires double quotes '' around it. 2. Semicolon ; is required to separate different parameters. 3. Brackets are used to wrap the hyper-parameter candidates. 4. A comma is used to separate the hyper-parameter candidates.
In the example above, all possible nine (three choices for memory_strength and three choices for n_memories) combinations will be used to set the hyper-parameters.
Since the graphs in N-CGL can be too large to be processed in one batch on most devices, the --minibatch argument could be specified to be True for training with the large graphs in mini-batches.
python train.py --dataset Arxiv-CL \
--method bare \
--backbone GCN \
--gpu 0 \
--ILmode taskIL \
--inter-task-edges False \
--minibatch True \
--batch_size 2000 \
--sample_nbs True \
--n_nbs_sample 10,25
In the above example, besides specifying the --minibatch, the size of each mini-batch is also specified through --batch_size. Moreover, some graphs are extremely dense and will run out the memory even with mini-batch training, which could be addressed through the neighborhood sampling specified via --sample_nbs. And the number of neighbors to sample for each hop is specified through --n_nbs_sample.
There are also other customizable arguments, the full list of which can be found in train.py.
When running the code in the Windows system, the following error OSError: [Errno 22] Invalid argument may be triggered and could be avoided by specifying the argument --replace_illegal_char as True to replace the potential illegal characters with the underscore symbol _. For example,
python train.py --dataset Arxiv-CL \
--method bare \
--backbone GCN \
--gpu 0 \
--ILmode taskIL \
--inter-task-edges False \
--minibatch False \
--replace_illegal_char True
Modifying the train-validation-test Splitting
The splitting can be simply specified via the arguments when running the experiments. In our implemented pipeline, the corresponding arguments are the validation and testing ratios. For example,
python train.py --dataset Arxiv-CL \
--method bare \
--backbone GCN \
--gpu 0 \
--ILmode taskIL \
--inter-task-edges False \
--minibatch False \
--ratio_valid_test 0.4 0.4
The example above set the data ratio for validation and testing as 0.4 and 0.4, and the training ratio is automatically calculated as 0.2.
Implementing New Methods
New continual graph learning methods can also be easily implemented in our highly modularized pipelines.
The newly implemented method should be contained in a Python script file under the directory CGLB/NCGL/Baselines. Suppose we are implementing a method named A, the
