LiPSBOMaker

LiPSBOMaker is an SBOM generation tool for Linux distributions.

It is a command-line tool that can generate multi-stage SBOMs for Linux packages, including the source stage, release stage, and runtime stage.

中文文档

1. Installation

(1) Using precompiled binary executables from the repository:

• For Windows: Use slp.exe
• For Linux: Use slp

(2) Downloading and compiling from source:

• Ensure that the Go environment is properly configured on your system.

• Navigate to the project root directory and use go build to compile.

• The build process will automatically generate an executable file suitable for the current platform.

(3) Running the tool

LiPSBOMaker is a command-line tool and can be executed using the following commands:

# For Windows:
./slp.exe --help

# For Linux:
./slp --help

Note: In the following usage instructions, "./" is omitted by default.

2. Command Overview

slp version
slp package --lifecycle=["source"/"release"/"installed"] [SOURCE] --output=[Filename]
slp record [SOURCE]
slp --help

3. Commands for Different Requirements

(1) Generate SBOM

Source stage：

#For the RPM source stage, provide the path to the RPM source package.
slp package -l=source "xxx.src.rpm" --output ./rpm-source.json

#For the DEB source package stage (after extracting the source package, move the .dsc file to the main folder, then provide the path of the .dsc file, e.g., /apt-2.7.14build2/apt_2.7.14build2.dsc).
slp package -l=source "xxx/xxx.dsc" --output ./deb-source.json

Release stage：

#For the RPM release stage, provide the path to the RPM binary package.
slp package -l=release "xxx.rpm" --output ./rpm-release.json

#For the DEB release stage, provide the path to the DEB binary package.
slp package -l=release "xxx.deb" --output ./deb-release.json

Usage stage：

Please note that since the parsing of locally installed packages is dependent on the local environment, it is necessary to execute the relevant commands within the command line of the local environment.

#For the RPM usage stage, provide the name of the RPM package to be analyzed. For example, to generate the SBOM for the local bash package, simply use bash.
slp package -l=installed xxx --output ./rpm-installed.json

#For the DEB usage stage, provide the name of the DEB package.
slp package -l=installed xxx --output ./deb-installed.json

(2) Record build environment information

The command to record build environment information has only one parameter, which is either the path to the RPM source package or the path to the .dsc file of the DEB source package.

The recorded build environment information will be saved with the fixed name buildEnv.json in the current directory where the command is executed.

#For the RPM system, provide the path to the RPM source package, for example, ./dnf-4.16.2-3.oe2403.src.rpm.
#For the DEB system, provide the path to the .dsc file of the DEB source package, for example, ./apt_2.7.14build2.dsc.
slp record xxx

4. Best Practices

(1). For the RPM system:

Let's take the dnf package as an example to demonstrate the best practices of using LiPSBOMaker in the RPM system.

① Download the source package.

dnf download --source dnf

get the dnf-4.16.2-6.oe2403.src.rpm source package.

② Generate the SBOM for the DNF source stage.

slp package -l=source ./dnf-4.16.2-6.oe2403.src.rpm --output ./dnf-source-SBOM.json

The dnf source stage SBOM dnf-source-SBOM.json has been generated (it can later be embedded into the dnf source package for distribution).

③ Record the build environment information for the dnf source package during the process of compiling it into a binary package.

The overall process for recording the build environment information is as follows:

• Install the build dependencies for the DNF source package.

• Use the LiPSBOMaker tool to record the build dependencies information used during the DNF build process into the buildEnv.json file.

• Embed the buildEnv.json file into the DNF binary release package and release it together.

• After the user downloads the DNF binary release package, they can use the LiPSBOMaker tool to scan the binary package and generate the SBOM for the binary usage stage. This will supplement the build dependency information used in the source stage.

Next, we will introduce the commands used one by one:

Prepare the build environment:

#Install the necessary build tools.
sudo yum install rpm-build rpmdevtools
#Set up the RPM build environment.
rpmdev-setuptree

Extract the DNF source package, and place the source code and other files into the SOURCES directory, while placing the .spec file into the SPECS directory:

#Extract the DNF source package.
rpm2cpio dnf-4.16.2-6.oe2403.src.rpm | cpio -idmv
cd SPECS

Install the build dependencies required by DNF. Afterward, use LiPSBOMaker to record the detailed build dependencies information. Move the generated buildEnv.json file into the SOURCES directory for later packaging:

#Install the build dependencies.
dnf builddep dnf.spec
slp record dnf-4.16.2-6.oe2403.src.rpm
mv buildEnv.json ./SOURCES

Modify the dnf.spec file to control the build process and embed the buildEnv.json file into the final generated DNF binary package:

#Add the buildEnv.json file to the Source section of the .spec file.
Source1:  buildEnv.json
#Add the command to include the buildEnv.json file in the %install section.
mkdir -p %{buildroot}/usr/share/SBOM/
cp %{SOURCE1} %{buildroot}/usr/share/SBOM/
#Add the following content to the %files section to ensure that the buildEnv.json file is included in the final binary RPM package during the build process:
/usr/share/SBOM/buildEnv.json

Build the RPM package:

rpmbuild -ba dnf.spec

The generated binary package will be stored in the RPMS folder, and you can extract it to verify.

Once confirmed to be correct, the DNF binary package can be released.

④ Generate the SBOM for the DNF release stage.

After downloading the binary release package with the embedded buildEnv.json file, use LiPSBOMaker to generate the SBOM for the binary release stage.

slp package -l=release dnf-4.16.2-6.noarch.rpm --output ./dnf-release-SBOM.json

⑤ Generate the SBOM for the DNF usage stage.

After installing DNF, you can use LiPSBOMaker to generate the SBOM for the binary usage stage.

slp package -l=installed dnf --output ./dnf-installed-SBOM.json

(2) For the DEB system:

Here, we will use the apt package as an example.

① Download the source package.

apt source apt

After executing the command, the following three files will be downloaded locally: apt-2.7.14build2 apt_2.7.14build2.dsc apt_2.7.14build2.tar.xz

② Generate the SBOM for the apt source stage.

Copy the .dsc file to the main directory apt-2.7.14build2:

cp apt_2.7.14build2.dsc ./apt-2.7.14build2

Use LiPSBOMaker to generate the SBOM for the source stage:

slp package -l=source apt-2.7.14build2/apt_2.7.14build2.dsc --output ./apt-source-SBOM.json

③ Record the build information for the apt source package.

apt install dpkg-dev build-essential #Install the necessary tools.
apt-get build-dep apt #Download the build dependencies.
slp record apt_2.7.14build2.dsc #Record the detailed information of the build dependencies.

After obtaining the buildEnv.json file, copy it to the /debian/ folder in the source main directory:

cp buildEnv.json apt-2.7.14build2/debian/

Modify the install file of the source package to include the buildEnv.json file in the generated apt binary package during the packaging process:

#Add the following configuration to the apt-2.7.14build2/debian/apt.install file:
debian/buildEnv.json /usr/share/SBOM/buildEnv.json

Enter the source main directory and begin building the binary package:

cd apt-2.7.14build2
dpkg-buildpackage -us -uc

In the upper directory, you will find the built binary package apt_2.7.14build2_amd64.deb. You can extract this binary package to verify if the file has been successfully embedded:

 dpkg-deb -x apt_2.7.14build2_amd64.deb apt  #Extract the .deb file to the local apt folder.

Once verified, the apt binary package can be released.

④ Generate the SBOM for the apt release stage.

After downloading the apt binary package with the embedded buildEnv.json file, directly use the command to generate the SBOM:

slp package -l=release apt_2.7.14build2_amd64.deb --output ./apt-release-SBOM.json

⑤ Generate the SBOM for the apt usage stage.

After installing apt, you can use LiPSBOMaker to generate the SBOM for the binary usage stage:

slp package -l=installed apt --output ./apt-installed-SBOM.json
