Intel® Open Path Guiding Library

This is release v0.7.1 of Intel® Open PGL. For changes and new features, see the changelog. Visit http://www.openpgl.org for more information.

Overview

The Intel® Open Path Guiding Library (Intel® Open PGL) implements a set of representations and training algorithms needed to integrate path guiding into a renderer. Open PGL offers implementations of current state-of-the-art path guiding methods, which increase the sampling quality and, therefore, the efficiency of a renderer. The goal of Open PGL is to provide implementations that are well tested and robust enough to be used in a production environment.

The representation of the guiding field is learned during rendering and updated on a per-frame basis using radiance/importance samples generated during rendering. At each vertex of a random path/walk, the guiding field is queried for a local distribution (e.g., incident radiance), guiding local sampling decisions (e.g., directions).

Currently supported path guiding methods include: guiding directional sampling decisions on surfaces and inside volumes based on a learned incident radiance distribution or its product with BSDF components (i.e., cosine lobe) or phase functions (i.e., single lobe HG).

Open PGL offers a C API and a C++ wrapper API for higher-level abstraction. The current implementation is optimized for the latest Intel® processors with support for SSE, AVX, AVX2, and AVX-512 instructions.

<!--, and for ARM processors with support for NEON instructions.-->

Open PGL is part of the Intel® oneAPI Rendering Toolkit and has been released under the permissive Apache 2.0 license.

| | |:------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------:| | Path traced image of a variation of the Nishita Sky Demo scene from Blender Studio (CC0) without and with using Open PGL to guide directional samples (i.e., on surfaces and inside the water volume). |

Disclaimer

The current version of Open PGL is still in a pre v1.0 stage and should be used with caution in any production related environment. The API specification is still in flux and might change with upcoming releases.

Latest Updates

The full version history can be found here

Open PGL 0.7.1

• Bugfixes:
  • Fixing invalidation of the guiding field on initial creation if a cell contains no samples #23.
  • Fixing noisy stdout printouts #19.
  • Improving robustness of the integer arithmetric used during the deterministic multi-threaded building of the spatial subdivision structure.
  • Improving numerical stability of fitting process of the VMM-based guiding models.

Support and Contact

Open PGL is under active development. Though we do our best to guarantee stable release versions, a certain number of bugs, as-yet-missing features, inconsistencies, or any other issues are still possible. Should you find any such issues, please report them immediately via Open PGL’s GitHub Issue Tracker (or, if you should happen to have a fix for it, you can also send us a pull request).

Reference

@misc{openpgl,
   Author = {Herholz, Sebastian and Dittebrandt, Addis},
   Year = {2022},
   Note = {http://www.openpgl.org},
   Title = {Intel{\textsuperscript{\tiny\textregistered}}
 Open Path Guiding Library}
}

Building Open PGL from source

The latest Open PGL sources are always available at the Open PGL GitHub repository. The default main branch should always point to the latest tested bugfix release.

Prerequisites

Open PGL currently supports Linux, Windows and MacOS. In addition, before building Open PGL you need the following prerequisites:

• You can clone the latest Open PGL sources via:

  git clone https://github.com/RenderKit/openpgl.git


• To build Open PGL you need CMake, any form of C++11 compiler (we recommend using GCC, but also support Clang and MSVC), and standard Linux development tools.

• Open PGL depends on TBB, which is available at the TBB GitHub repository.

• Open PGL depends on OIDN, if the Image-space Guiding Buffer feature is enabled, which is available at the OIDN GitHub repository.

Depending on your Linux distribution, you can install these dependencies using yum or apt-get. Some of these packages might already be installed or might have slightly different names.

CMake Superbuild

For convenience, Open PGL provides a CMake Superbuild script which will pull down Open PGL’s dependencies and build Open PGL itself. The result is an install directory including all dependencies.

Run with:

    mkdir build
    cd build
    cmake ../superbuild
    cmake  --build .

The resulting install directory (or the one set with CMAKE_INSTALL_PREFIX) will have everything in it, with one subdirectory per dependency.

CMake options to note (all have sensible defaults):

• CMAKE_INSTALL_PREFIX: The root directory where everything gets installed to.
• BUILD_JOBS: Sets the number given to make -j for parallel builds.
• BUILD_STATIC: Builds Open PGL as static library (default OFF).
• BUILD_TOOLS: Builds Open PGL’s tools (default OFF).
• BUILD_DEPENDENCIES_ONLY: Only builds Open PGL’s dependencies (default OFF).
• BUILD_TBB: Builds or downloads TBB (default ON).
• BUILD_TBB_FROM_SOURCE: Specifies whether TBB should be built from source or the releases on GitHub should be used. This must be ON when compiling for ARM (default OFF).
• BUILD_OIDN: Builds or downloads Intel’s Open Image Denoise (OIDN) (default ON).
• BUILD_OIDN_FROM_SOURCE: Builds OIDN from source. This must be ON when compiling for ARM. (default ON).
• DOWNLOAD_ISPC: Downloads Intel’s ISPC compiler which is needed to build OIDN (default ON when building OIDN from source).

For the full set of options, run ccmake [<PGL_ROOT>/superbuild].

Standard CMake build

Assuming the above prerequisites are all fulfilled, building Open PGL through CMake is easy:

Create a build directory, and go into it:

    mkdir build
    cd build

Configure the Open PGL build using:

    cmake -DCMAKE_INSTALL_PREFIX=[openpgl_install] ..

• CMake options to note (all have sensible defaults):

  • CMAKE_INSTALL_PREFIX: The root directory where everything gets installed to.

  • OPENPGL_BUILD_STATIC: Builds Open PGL as a static or shared library (default OFF).

  • OPENPGL_ISA_AVX512: Compiles Open PGL with AVX-512 support (default OFF).

  • OPENPGL_ISA_NEON and OPENPGL_ISA_NEON2X: Compiles Open PGL with NEON or double pumped NEON support (default OFF).

  • OPENPGL_LIBRARY_NAME: Specifies the name of the Open PGL library file created. By default the name openpgl is used.

  • OPENPGL_BUILD_STATIC: Builds Open PGL as static library (default OFF).

  • OPENPGL_BUILD_TOOLS: Builds additional tools such as: openpgl_bench and openpgl_debug for benchmarking and debuging guiding caches (default OFF).

  • OPENPGL_EF_RADIANCE_CACHES: Enables the experimental radiance caching feature (default OFF).

  • OPENPGL_EF_IMAGE_SPACE_GUIDING_BUFFER: Enables the experimental image-space guiding buffer feature (default OFF).

  • OPENPGL_DIRECTION_COMPRESSION: Enables the 32Bit compression for directional data stored in pgl_direction (default OFF).

  • OPENPGL_RADIANCE_COMPRESSION: Enables the 32Bit compression for RGB data stored in pgl_spectrum (default OFF).

  • OPENPGL_TBB_ROOT: Location of the TBB installation.

  • OPENPGL_TBB_COMPONENT: The name of the TBB component/library (default tbb).

Build and install Open PGL using:

    cmake build
    cmake install

Including Open PGL into a project

Including into CMake build scripts.

To include Open PGL into a project which is using CMake as a build system, one can simply use the CMake configuration files provided by Open PGL.

To make CMake aware of Open PGL’s CMake configuration scripts the openpgl_DIR has to be set to their location during configuration:

cmake -Dopenpgl_DIR=[openpgl_install]/lib/cmake/openpgl-0.7.1 ..

After that, adding OpenPGL to a CMake project/target is done by first finding Open PGL using find_package() and then adding the openpgl:openpgl targets to the project/target:

# locating Open PGL library and headers
find_package(openpgl REQUIRED)

# setting up project/target
...
add_executable(myProject ...)
...

# adding Open PGL to the project/target
target_include_directories(myProject openpgl::openpgl)

target_link_libraries(myProject openpgl::openpgl)

Including Open PGL API headers

Open PGL offers two types of APIs.

The C API is C99 conform and is the basis for interacting with Open PGL. To use the C API of Open PGL, one only needs to include the following header:

#include <openpgl/openpgl.h>

The C++ API is a header-based wrapper of the C API, which offers a more comfortable, object-oriented way of using Open PGL. To use the C++ API of Open PGL, one only needs to include the following header:

#include <openpgl/cpp/OpenPGL.h>

Open PGL API

The API specification of Open PGL is currently sti
